Note: Please add “-31” before “-F” in the part number when ordering the PC board type 0.9 mm width terminal (ex) HC1-HPL-AC6V-31-F.
5) TM type
Coil voltage
6V AC
12V AC
24V AC
48V AC
100/110V AC
110/120V AC
200/220V AC
6V DC
12V DC
24V DC
48V DC
100/110V DC
1 Form C
Part No.
HC1-HTM-AC6V-F
HC1-HTM-AC12V-F
HC1-HTM-AC24V-F
HC1-HTM-AC48V-F
HC1-HTM-AC100V-F
HC1-HTM-AC120V-F
HC1-HTM-AC200V-F
HC1-HTM-DC6V-F
HC1-HTM-DC12V-F
HC1-HTM-DC24V-F
HC1-HTM-DC48V-F
HC1-HTM-DC100V-F
2 Form C
Part No.
HC2-HTM-AC6V-F
HC2-HTM-AC12V-F
HC2-HTM-AC24V-F
HC2-HTM-AC48V-F
HC2-HTM-AC100V-F
HC2-HTM-AC120V-F
HC2-HTM-AC200V-F
HC2-HTM-DC6V-F
HC2-HTM-DC12V-F
HC2-HTM-DC24V-F
HC2-HTM-DC48V-F
HC2-HTM-DC100V-F
3 Form C
Part No.
HC3-HTM-AC6V-F
HC3-HTM-AC12V-F
HC3-HTM-AC24V-F
HC3-HTM-AC48V-F
HC3-HTM-AC100V-F
HC3-HTM-AC120V-F
HC3-HTM-AC200V-F
HC3-HTM-DC6V-F
HC3-HTM-DC12V-F
HC3-HTM-DC24V-F
HC3-HTM-DC48V-F
HC3-HTM-DC100V-F
4 Form C
Part No.
HC4-HTM-AC6V
HC4-HTM-AC12V
HC4-HTM-AC24V
HC4-HTM-AC48V
HC4-HTM-AC100V
HC4-HTM-AC120V
HC4-HTM-AC200V
HC4-HTM-DC6V
HC4-HTM-DC12V
HC4-HTM-DC24V
HC4-HTM-DC48V
HC4-HTM-DC100V
4 Form C (twin)
Part No.
HC4D-HTM-AC6V
HC4D-HTM-AC12V
HC4D-HTM-AC24V
HC4D-HTM-AC48V
HC4D-HTM-AC100V
HC4D-HTM-AC120V
HC4D-HTM-AC200V
HC4D-HTM-DC6V
HC4D-HTM-DC12V
HC4D-HTM-DC24V
HC4D-HTM-DC48V
HC4D-HTM-DC100V
Standard packing: Carton: 20 pcs.; Case: 200 pcs.
RATING
1. Coil data
1) AC coils (50/60Hz)
Type
Nominal coil
voltage
6V AC
12V AC
24V AC
48V AC
100/110V AC
110/120V AC
200/220V AC
80%V or less of
nominal voltage
(Initial)
30%V or more
of nominal
voltage
(Initial)
Pick-up voltage
(at 20°C
68°F)
Drop-out
voltage
(at 20°C
68°F)
Nominal coil current
[±20%] (at 20°C
68°F)
50Hz
224mA
111mA
56mA
28mA
13.4/14.7mA
12.2/13.5mA
6.7/7.4mA
60Hz
200mA
100mA
50mA
25mA
12/13.2mA
10.9/11.9mA
6/6.6mA
Coil inductance
N.C.
condition
0.078H
0.312H
1.243H
4.974H
23.75H
27.19H
85.98H
N.O.
condition
0.074H
0.295H
1.181H
4.145H
20.63H
25.57H
81.76H
Nominal operating
power
50Hz
1.3VA
1.3VA
1.3VA
1.3VA
1.3VA
1.3VA
1.3VA
60Hz
1.2VA
1.2VA
1.2VA
1.2VA
1.2VA
1.2VA
1.2VA
Max. allowable
voltage
(at 70°C
158°F)
Standard
110%V of
nominal voltage
Notes: 1. The relay operates in a range of 80% to 110% V of the voltage rating, but ideally, in consideration of temporary voltage fluctuations, it should be operated at the
rated voltage. In particular, for AC operation, if the applied voltage drops to 80% V or more below the rated voltage, humming will occur and a large current will flow
leading possibly to coil burnout.
2. The maximum allowable voltage is the maximum voltage fluctuation value for the coil power supply. This value is not a permissible value for continuous operation.
(This value differs depending on the ambient temperature. Please contact us for details.
2) DC coils
Type
Nominal coil
voltage
6V DC
Standard
12V DC
24V DC
48V DC
100/110V DC
80%V or less of
nominal voltage
(Initial)
10%V or more of
nominal voltage
(Initial)
Pick-up voltage
(at 20°C
68°F)
Drop-out voltage
(at 20°C
68°F)
Nominal coil current
[±10%]
(at 20°C
68°F)
150mA
75mA
37mA
18.5mA
10/11mA
Coil resistance
[±10%]
(at 20°C
68°F)
40Ω
160Ω
650Ω
2,600Ω
10,000Ω
Nominal operating
power
0.9W
0.9W
0.9W
0.9W
1.0W
110%V of
nominal voltage
Max. allowable voltage
(at 70°C 158°F)
Notes: 1. The coil resistance for DC operation is the value measured when the coil temperature is 20°C 68°F. Compensate
±0.4%
for every
±1°C
change in temperature.
2. The relay operates in a range of 80% to 110% V of the voltage rating, but ideally, in consideration of temporary voltage fluctuations, it should be operated at the
rated voltage.
3. For use with 200 V DC, connect a 10 KΩ (5W) resistor, in series, to the 100 V DC relay.
4. The maximum allowable impress voltage is the maximum voltage fluctuation value for the coil power supply. This value is not a permissible value for continuous
operation. (This value differs depending on the ambient temperature. Please contact us for details.)
AC (50Hz): 1.3VA, AC (60Hz): 1.2VA, DC: 0.9 to 1.1W
1mA 1V DC
Min. 1,000MΩ (at 500V DC)
Measurement at same location as “Initial breakdown voltage” section.
700 Vrms for 1min. (Detection current: 10mA.)
700 Vrms for 1min. (Detection current: 10mA.)
2,000 Vrms for 1min. (Detection current: 10mA.)
5A
3A
100µA 1V DC
Max. 80°C (By resistive method, nominal voltage)
Max. 20ms (Nominal voltage applied to the coil, excluding contact bounce time.)
Max. 20ms (Nominal voltage applied to the coil, excluding contact bounce time.) (without diode)
Min. 196 m/s
2
(Half-wave pulse of sine wave: 11 ms; detection time: 10µs.)
Min. 980 m/s
2
(Half-wave pulse of sine wave: 6 ms.)
10 to 55 Hz at double amplitude of 1 mm (Detection time: 10µs.)
10 to 55 Hz at double amplitude of 2 mm
Min. 5×10
7
: AC coil type (at 180 cpm); Min. 10
8
: DC coil type (at 180 cpm)
Min. 2×10
5
Min. 10
5
Min. 2×10
5
Min. 2×10
5
Min. 2×10
5
(at 20 cpm)
(at 20 cpm)
(at 20 cpm)
(at 20 cpm)
(at 20 cpm)
Ambient temperature: –50°C to +70°C
–58°F to +158°F
(without LED); –50°C to +60°C
–58°F to +140°F
(with LED)
Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature)
20 cpm (at max. rating)
Approx. 30g
1.06 oz
Mechanical
characteristics
Shock
resistance
Vibration
resistance
Mechanical
Functional
Destructive
Functional
Destructive
Expected life
Electrical (resistive load)
Conditions for operation,
transport and storage*
3
Max. Operating speed
Conditions
Unit weight
Notes: In accordance with the Electrical Appliance and Material Safety Law, you cannot exceed a voltage of 150V AC when using the 4 Form C type. For more information,
please inquire.
*1 This value can change due to the switching frequency, environmental conditions and desired reliability level, therefore it is recommended to check this with the
actual load.
*2 For the AC coil types, the operate/release time will differ depending on the phase.
*3 The upper operation ambient temperature limit is the maximum temperature that can satisfy the coil temperature rise value.
Refer to 6. Conditions for operation, transport and storage mentioned in AMBIENT ENVIRONMENT.
