REMEC
Double Balanced Mixer
Multi-Octave Band
Electrical Specifications
Parameter
SSB Conversion
loss:
(2) (3)
Isolation
LO to RF:
LO to IF:
RF to IF:
Input 1-dB
Compression Point:
Input Third Order
Intercept Point:
LO Power:
(1)
RF 2.0-8.0 GHz
LO 2.0-8.0 GHz
IF DC-1500 MHz
:
Conditions
RF(GHz)
2.0-8.0
2.0-8.0
2.0-8.0
LO(GHz)
2.0-8.0
2.0-8.0
2.0-8.0
2.0-8.0
2.0-8.0
2.0-8.0
DC-1500
IF(MHz)
DC-500
DC-1000
DC-1500
Min
Specifications
Typical
5.0 dB
6.0 dB
7.0 dB
33 dB
37 dB
22 dB
+1 dBm
+4 dBm
+8 dBm
+12 dBm
+11 dBm
+14 dBm
+18 dBm
+22 dBm
+7 dBm
+10 dBm
+13 dBm
+18 dBm
Max
7.0 dB
8.0 dB
9.5 dB
MM4xSMx-10
MM4xSMx-14
LO Power
3 = +7 dBm
4 = +10 dBm
6 = +13 dBm
7 = +18 dBm
2.0-8.0
2.0-8.0
2.0-8.0
2.0-8.0
DC-1500
(4)
2.0-8.0
2.0-8.0
DC-1500
MM43
MM44
MM46
MM47
MM43
MM44
MM46
MM47
MM43
MM44
MM46
MM47
D = No Cover
H = With Cover
Notes:
1. Specifications are guaranteed when tested as a downconverter in a 50 Ohm system at +25°C with
the nominal LO power. Specifications indicated as typical are not guaranteed.
2. Noise figure is typically within ±0.5 dB of conversion loss for IF frequencies greater than 10 MHz.
3. Conversion loss typically degrades less than 0.5 dB at +100°C and improves less than 0.5 dB at -55°C.
4. Usable LO drives are up to 2 dB below and 3 dB above nominal.
5. See Application Note M112, for aid in selecting the outline and for mounting and installation information.
MM4xSMD-10
Outline: SMMC5A: AS SHOWN
SMMC5B: RF & LO REVERSED
Typical
Performance
at 25°C
MM4xSMx-10: AS SHOWN
MM4xSMx-14: RF & LO REVERSED
MM4xSMH-10
Outline: SMMT5A: AS SHOWN
SMMT5B: RF & LO REVERSED
NOTE: See PC board footprint - FP2 on page 3-64
All dimensions are in inches and [mm].
Specifications subject to change without notice.
3-23
1590 Buckeye Drive - Milpitas, CA 95035 - TEL: 408-432-9898 - FAX: 408-432-1551 - components@remec.com - www.remec.com
