Dat a She et, DS 1, M arc h 2001
Q-SMINT IX
2B1Q
Second
Gen.
Modular ISDN NT
(Intelligent
eXtended)
PEF 81912/81913 Version 1.3
®
W ir ed
Communica ti o ns
N e v e r
s t o p
t h i n k i n g .
Edition March 2001
Published by Infineon Technologies AG,
St.-Martin-Strasse 53,
D-81541 München, Germany
©
Infineon Technologies AG 2001.
All Rights Reserved.
Attention please!
The information herein is given to describe certain components and shall not be considered as warranted
characteristics.
Terms of delivery and rights to technical change reserved.
We hereby disclaim any and all warranties, including but not limited to warranties of non-infringement, regarding
circuits, descriptions and charts stated herein.
Infineon Technologies is an approved CECC manufacturer.
Information
For further information on technology, delivery terms and conditions and prices please contact your nearest
Infineon Technologies Office in Germany or our Infineon Technologies Representatives worldwide (see address
list).
Warnings
Due to technical requirements components may contain dangerous substances. For information on the types in
question please contact your nearest Infineon Technologies Office.
Infineon Technologies Components may only be used in life-support devices or systems with the express written
approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure
of that life-support device or system, or to affect the safety or effectiveness of that device or system. Life support
devices or systems are intended to be implanted in the human body, or to support and/or maintain and sustain
and/or protect human life. If they fail, it is reasonable to assume that the health of the user or other persons may
be endangered.
Dat a She et, DS 1, M arc h 2001
Q-SMINT IX
2B1Q
Second
Gen.
Modular ISDN NT
(Intelligent
eXtended)
PEF 81912/81913 Version 1.3
®
W ir ed
Communica ti o ns
N e v e r
s t o p
t h i n k i n g .
PEF 81912/81913
Revision History:
Previous Version:
Page
All
March 2001
Preliminary Data Sheet 10.00
DS 1
Subjects (major changes since last revision)
Editorial changes, addition of notes for clarification etc.
Table 1,
Introduced new versions 81913 with extended performance of the U-interface
Chapter 1.3
Chapter
2.1.1.1
Chapter
2.3.2
Figure 12
Chapter
2.5.5.2
Chapter
2.5.5.3
Chapter
2.6.2.1
Chapter
2.6.3.1
Chapter 4
SCI: header description: added to sequences 43
H
, 41
H
and 49
H
: ’ Generally, it can
be used for any register access to the address range 00
H
-7D
H
.’
IOM-2 handler: removed ’U-transceiver (U)’ from listing of functional units with
programmable time slot and data port.
Figure ’Data Access via CDAx0 and CDAx1 register pairs’ corrected: input swap has
influence on the input enable (EN_I0,1), too
C/I commands: removed ’unconditional command’ from description C/I-command
’DR’
LT-S state machine: C/I=command AIL removed (no valid input to the LT-S state
machine)
HDLC: removed from description RBC: ’(bytes, which are ready for next read
access)’ and ’(blocks, which have been already read)’.
HDLC: Possible Error Conditions:
added behavioral description in case of an XPR interrupt
Detailed register description:
• U-transceiver Mode Evaluation Timing: clarified description
• register ID: reset value of version 1.3 is 01
H
(not 00
H
)
• RSTA.SA1,0: clarified note
• CIX1.CODX1: bits 5-0 of C/I-channel 1 (not 7-2)
• IOM_CR:TIC_DIS: added for clarification: ’This means that the timeslots TIC, A/
B, S/G and BAC are not available any more.’
Chapter 5.1
Absolute Maximum Ratings: Maximum Voltage on VDD: 4.2V (before: 4.6V)
Chapter 5.1
Refined references for ESD requirements:’ ...(CDM), EIA/JESD22-A114B (HBM) ---’
Chapter 5.2
Input/output leakage current set to 10µA (before: 1µA)
Table 43
U-transceiver characteristics: enhanced S/N+D for 81913 and threshold level for
81912 and 81913 distinguished
PEF 81912/81913
Revision History:
Previous Version:
Page
Chapter
5.6.2
Chapter
5.6.3
Chapter
5.6.3
Chapter
5.6.5
March 2001
Preliminary Data Sheet 10.00
DS 1
Subjects (major changes since last revision)
AC-Timing SCI/parallel µC interface: enhanced timing specifications
Added restriction for control interval t
RI
Parameters of the UVD/POR Circuit:
defined reduced range of hysteresis: min. 30mV/max. 90mV
relaxed upper limit of Detection Threshold to 2.92V (before: 2.9V)
defined max. rising VDD for power-on
Register summary U-transceiver 4B3T:
Reset value of MASKU is FF
H
(not 00
H
)
Chapter
7.2.5
Chapter 7.3
External circuitry for T-SMINT updated
For questions on technology, delivery and prices please contact the Infineon
Technologies Offices in Germany or the Infineon Technologies Companies and
Representatives worldwide: see our webpage at http://www.infineon.com
