FDLL457 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> FDLL457

FDLL457: DescriptionRectifier Diode, 1 Element, 0.2A, 60V V(RRM), Silicon, LL-34, 2 PIN; CategoryDiscrete semiconductor diode; File Size321KB，10 Pages; ManufacturerFairchild; Websitehttp://www.fairchildsemi.com/

Download Datasheet Parametric Compare View All

FDLL457 Overview

Rectifier Diode, 1 Element, 0.2A, 60V V(RRM), Silicon, LL-34, 2 PIN

FDLL457 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Fairchild
package instruction	O-LELF-R2
Contacts	2
Reach Compliance Code	unknown
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1 V
JESD-30 code	O-LELF-R2
JESD-609 code	e0
Maximum non-repetitive peak forward current	4 A
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Maximum output current	0.2 A
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	0.5 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	60 V
surface mount	YES
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	WRAP AROUND
Terminal location	END
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

FDLL457 Related Products

	FDLL457	AV55-150G-014.0M	MEB-474G0100DB1073	FDLL456	FDLL456A	FDLL458	FDLL458A	FDLL459	FDLL459A	1N456
Description	Rectifier Diode, 1 Element, 0.2A, 60V V(RRM), Silicon, LL-34, 2 PIN	ACMOS Output Clock Oscillator, 14MHz Min, 100MHz Max, 14MHz Nom, ROHS COMPLIANT, HERMETIC SEALED, DIP-14/4	CAPACITOR, METALLIZED FILM, POLYESTER, 100V, 0.47uF, THROUGH HOLE MOUNT, RADIAL LEADED	Rectifier Diode, 1 Element, 0.2A, 25V V(RRM), Silicon, LL-34, 2 PIN	Rectifier Diode, 1 Element, 0.2A, 25V V(RRM), Silicon, LL-34, 2 PIN	Rectifier Diode, 1 Element, 0.2A, 125V V(RRM), Silicon, LL-34, 2 PIN	Rectifier Diode, 1 Element, 0.2A, 125V V(RRM), Silicon, LL-34, 2 PIN	Rectifier Diode, 1 Element, 0.2A, 175V V(RRM), Silicon, LL-34, 2 PIN	Rectifier Diode, 1 Element, 0.2A, 175V V(RRM), Silicon, LL-34, 2 PIN	Rectifier Diode, 1 Element, 0.2A, 25V V(RRM), Silicon, DO-35, GLASS PACKAGE-2
package instruction	O-LELF-R2	DIP4/14,.3	,	O-LELF-R2	O-LELF-R2	O-LELF-R2	O-LELF-R2	O-LELF-R2	O-LELF-R2	GLASS PACKAGE-2
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Number of terminals	2	4	2	2	2	2	2	2	2	2
Maximum operating temperature	175 °C	70 °C	85 °C	175 °C	175 °C	175 °C	175 °C	175 °C	175 °C	200 °C
surface mount	YES	YES	NO	YES	YES	YES	YES	YES	YES	NO
Is it Rohs certified?	incompatible	conform to	-	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
Maker	Fairchild	-	-	Fairchild	Fairchild	Fairchild	Fairchild	Fairchild	Fairchild	Fairchild
Contacts	2	-	-	2	2	2	2	2	2	2
ECCN code	EAR99	-	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Shell connection	ISOLATED	-	-	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED
Configuration	SINGLE	-	-	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	-	-	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	-	-	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	1 V	-	-	1 V	1 V	1 V	1 V	1 V	1 V	1 V
JESD-30 code	O-LELF-R2	-	-	O-LELF-R2	O-LELF-R2	O-LELF-R2	O-LELF-R2	O-LELF-R2	O-LELF-R2	O-LALF-W2
JESD-609 code	e0	-	e3	e0	e0	e0	e0	e0	e0	e0
Maximum non-repetitive peak forward current	4 A	-	-	4 A	4 A	4 A	4 A	4 A	4 A	0.7 A
Number of components	1	-	-	1	1	1	1	1	1	1
Maximum output current	0.2 A	-	-	0.2 A	0.2 A	0.2 A	0.2 A	0.2 A	0.2 A	0.2 A
Package body material	GLASS	METAL	-	GLASS	GLASS	GLASS	GLASS	GLASS	GLASS	GLASS
Package shape	ROUND	-	RECTANGULAR PACKAGE	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND
Package form	LONG FORM	-	-	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	-	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Maximum power dissipation	0.5 W	-	-	0.5 W	0.5 W	0.5 W	0.5 W	0.5 W	0.5 W	0.5 W
Certification status	Not Qualified	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	60 V	-	-	25 V	25 V	125 V	125 V	175 V	175 V	25 V
Terminal surface	Tin/Lead (Sn/Pb)	-	TIN	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	WRAP AROUND	-	-	WRAP AROUND	WRAP AROUND	WRAP AROUND	WRAP AROUND	WRAP AROUND	WRAP AROUND	WIRE
Terminal location	END	-	-	END	END	END	END	END	END	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED	-	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
