T-1 (3mm) CYLINDRICAL LED LAMP
W1334IT
HIGH EFFICIENCY RED
Features
!
WIDE
!
LOW
Description
The High Efficiency Red source color devices are made
with Gallium Arsenide Phosphide on Gallium Phosphide
Orange Light Emitting Diode.
VIEWING ANGLE.
POWER CONSUMPTION.
AND RUGGED.
!
RELIABLE
!
LONG
LIFE-SOLID STATE RELIABILITY.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO:DSAD0876
APPROVED: J.LU
REV NO: V.1
CHECKED:Allen Liu
DATE:APR/04/2003
DRAWN: F.Y.YUAN
PAGE: 1 OF 3
Selection Guide
P ar t N o .
Dic e
L en s Ty p e
Iv (m c d )
@ 10 m A
Min .
W1334IT
HIGH EFFICIENCY RED (GaAsP/GaP)
RED TRANSPARENT
3
Ty p .
5
V i ew i n g
An g l e
2
θ 1 / 2
130
°
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
A
=25°C
°
Sy m b o l
λ
peak
λ
D
∆λ
1/2
C
V
F
I
R
P ar am et er
Peak Wavelength
Dominate Wavelength
D ev i c e
High Efficiency Red
High Efficiency Red
Ty p .
627
625
45
15
2.0
2.5
10
Max .
Un its
nm
nm
nm
pF
V
uA
Tes t Co n d it io n s
I
F
=20mA
I
F
=20mA
I
F
=20mA
V
F
=0V;f=1MHz
I
F
=20mA
V
R
= 5V
Spectral Line Half-width High Efficiency Red
Capacitance
Forward Voltage
Reverse Current
High Efficiency Red
High Efficiency Red
High Efficiency Red
Absolute Maximum Ratings at T
A
=25°C
°
P ar am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating /Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
H i g h E f f i c i en c y R ed
105
30
160
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Un its
mW
mA
mA
V
SPEC NO:DSAD0876
APPROVED: J.LU
REV NO: V.1
CHECKED:Allen Liu
DATE:APR/04/2003
DRAWN: F.Y.YUAN
PAGE: 2 OF 3
