SBC2A SERIES
HDLV
Family
Description
The SBC2A is a 2-amp, low-cost, non-isolated DC-DC converter. The
SIP form factor and high power density minimize the board area
required for power. It uses an industry-standard pin-out, but also has
a much lower height of only 0.48 inches.
Features
• 2-amp Output Current
• 88 % Efficiency
• Low 0.48" Profile
• Non-isolated Output
• Remote Sense
• Remote Enable
• High-temperature
Operation
• Low cost
Input
Voltage
Current
Common Specifications
Min
3.0
Nom
3.3
Max
3.6
4
Units
Vdc
A
Notes
Output
Voltage
4.85
Current
Voltage Setpoint Accuracy
Line Regulation
Load Regulation
Dynamic Response
1 to 2 A load
2 to 1 A load
Trim Range
Temperature Regulation
General
MTBF
Operating Temperature
Storage Temperature
Switching Frequency
-10
5
±2
±0.1
±0.3
100
150
100
150
5.15
2
±3
Vdc
A
%V
out
%V
out
%V
out
mV
∆i
/∆ t = 0.1 A/µs
µs
mV
∆i/∆
t = 0.1 A/µs
µs
+10
%V
out
±0.02 %V
out
/°C
1,000
0
-40
230
70
125
k Hrs
°C
°C
kHz
Full Power, 400 LFM
Asia-Pacific:
TEL +886- (0)2 25624117 • FAX +886- (0)2 25624116
Europe:
TEL +41-41 768 5555 • FAX +41-41 768 5510
The Americas:
TEL +1-951 781 5500 • FAX +1-951 781-5700
Reliable Electronic Solutions
www.bourns.com
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
SBC2A SERIES
HDLV
Family
SBC2A-3S5
Nominal Output Output
Input
Voltage Current
(V)
(V)
(A)
3.3
5
2
Electrical Specifications
Ripple
(mV pp)
typ
100
Efficiency
(%)
typ
88
Standard Options
Add option designators to the end of the part number. Example; SBC2A-3S5-Z
Option Description
Z
-40 °C Operation
Output Decoupling
Although not specifically required for proper/specified operation of the SBC2A, external decoupling capacitors may be
employed to reduce noise and interaction with adjacent circuits. Output decoupling can be achieved by placing 0.1/µf
ceramic caps at the load.
Input Decoupling
Local input decoupling is recommended to reduce the apparent source impedance to SBC2A module.
C
2
C
1
0.1 µf, X7R ceramic
100 µf, 10 V, low ESR tantalum (AVX TPS series or Kemet T495 series).
Fault Protection
The SBC2A module does not provide short-circuit protection. To assure safety, place a fuse on the input line.
0.35
(8.9)
0.48
(12.2)
1
0.14
(3.6)
0.012 (0.3)
typ pin thickness
Pin
1,2
0.135 ±0.015
3
(3.43 ±0.38)
4-8
pin length
3
0.2 (5.1)
1.2 (30.5)
Pin
9-12
13,14
15
2.5 (63.5)
Trim Up
R
trim
= (100-15V
out
)/(V
out
-5)
V
out
+
4
13 x 0.1
(13 x 2.54)
15
0.020 (0.5)
typ pin width
SNS
TRIM
V
out
-
R
trim
LOAD
Description
No Connect
Trim
V
in
Description
Ground
V
out
Remote Sense
inches (mm)
0.xx
±0.01 inches
0.xxx ±0.005 inches
Trim Down
R
trim
= 25(V
out
-4)/(5-V
out
)
SBC2A
V
in
100µf/
10V
0.1∝f/
X7R
4
5
6
7
8
V
in
V
in
V
in
V
in
V
in
3
Trim
V
out
13
V
out
14
Remote 15
Sense
9 10 11 12
V
out
V
out
+
SNS
TRIM
V
out
-
R
trim
LOAD
REV. 01/05
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
