Note3: no suffix for CTRL function with Positive Logic (1=ON, 0=OFF) and trim pin
add suffix “N” for CTRL function with Negative Logic (0=ON, 1=OFF) and trim pin
Note4: add suffix -HC for premounted Heat-sink and clips
www.recom-power.com
REV.: 3/2017
PD-1
Package
(4)
Control Logic
(3)
RP60-G
DC/DC Converter
Specifications
measured at Ta = 25°C, nominal input voltage, full load otherwise noted
BASIC CHARACTERISTICS
Parameter
Input Voltage Range
Series
Condition
nom. Vin= 24V
nom. Vin= 48V
Vin = 24V
DC-DC ON
DC-DC OFF
DC-DC ON
DC-DC OFF
Min.
18VDC
36VDC
Typ.
24VDC
48VDC
15VDC
Max.
36VDC
75VDC
17VDC
34VDC
Under Voltage Lockout (UVLO)
Vin = 48V
Input Filter
Input Reflected Ripple Current
(5)
Input Surge Voltage
Start-up time
Operating Frequency Range
Ripple and Noise
32VDC
Pi-Type
20mAp-p
50VDC
100VDC
20ms
20ms
270kHz
300kHz
75mVp-p
100mVp-p
Open or 3.0V < Vr < 12V
Short or 0V < Vr < 1.2V
Short or 0V < Vr < 1.2V
Open or 3.0V < Vr < 12V
4mA
-0.5mA
1.0mA
330kHz
nominal Vin and full load
Vin= 24V, 100ms max.
Vin= 48V, 100ms max.
constant resistive load
Power up
Remote ON/OFF
measured by 20MHz bandwidth, 3.3Vout, 5Vout
with 1µF MLCC on output 12Vout, 15Vout
Positive Logic
DC-DC ON
DC-DC OFF
DC-DC ON
DC-DC OFF
DC-DC OFF
DC-DC ON
Remote ON/OFF
(6)
Negative Logic
Input current of Remote pin (CTRL)
Notes:
Note5: No minimum loading on the output is required to maintain specified regulation. Operation
under no-load condition will not damage these devices.
Note6: The ON/OFF control pin voltage is referenced to the -Vin pin.
RP60-2405SGW
95
90
85
80
75
70
65
60
55
50
45
40
10
20
Efficiency vs. Output Current
92
91
90
89
88
Efficiency vs. Input Voltage
Efficiency [%]
Efficiency [%]
18Vin
24Vin
36Vin
30
40
50
60
70
80
90
100
87
86
85
18
20
22
24
26
28
30
32
34
36
Output Current [%]
Input Voltage [VDC]
continued on next page
PD-2
REV.: 3/2017
www.recom-power.com
RP60-G
DC/DC Converter
Specifications
measured at Ta = 25°C, nominal input voltage, full load otherwise noted
RP60-4805SGW
95
90
85
80
75
70
65
60
55
50
45
40
10
20
30
40
50
60
70
80
36Vin
48Vin
75Vin
90
100
Series
Efficiency vs. Input Voltage
95
90
85
Efficiency vs. Output Current
Efficiency [%]
Efficiency [%]
80
75
70
65
60
36
40
44
48
52
56
60
64
68
72
75
Output Current [%]
Input Voltage [VDC]
REGULATIONS
Parameter
Output Voltage Accuracy
Voltage Adjustability
(7)
Line Voltage Regulation
Load Voltage Regulation
Transient Response recovery time
(8)
Condition
full load and nominal input
low line, high line at full load
25% load step change
Value
±1.0%
±10%
±0.2%
±0.5%
250µs typ.
Notes:
Note7: Maximum output deviation is 10% inclusive of remote sense and trim. If remote sense is
not being used, the +sense should be connected to its corresponding +OUTPUT and
likewise the -sense should be connected to its corresponding –OUTPUT.
Note8: No minimum loading on the output is required to maintain specified regulation. Operation
under no-load condition will not damage these devices.
External Output Trimming
Output Voltage Trimming
Single output Powerline converters offer the feature of trimming the output voltage over a certain range around the nominal value by using external
trim resistors. No general equation can be given for calculating the trim resistors, but the following trimtables give typical values for chosing these
trimming resistors. If voltages between the given trim points are required, extrapolate between the two nearest given values to work out the resistor
required or use a variable resistor to set the output voltage. Output can be externally trimmed by using the method shown below.
Trim up
7
RU
8
6
8
Trim down
RD
RP60-xx3.3SG
Trim up
Vout =
R
U
=
Trim down
Vout =
R
D
=
1
3.333
57.93
1
3.267
69.47
2
3.366
26.16
2
3.234
31.23
3
3.399
15.58
3
3.201
18.49
4
3.432
10.28
4
3.168
12.12
5
3.465
7.11
5
3.135
8.29
6
3.498
4.99
6
3.102
5.74
7
3.531
3.48
7
3.069
3.92
8
3.564
2.34
8
3.036
2.56
9
3.597
1.46
9
3.003
1.50
10
3.63
0.75
10
2.97
0.65
%
Volts
kOhms
%
Volts
kOhms
continued on next page
www.recom-power.com
REV.: 3/2017
PD-3
RP60-G
DC/DC Converter
Specifications
measured at Ta = 25°C, nominal input voltage, full load otherwise noted
RP60-xx05SG
Trim up
Vout =
R
U
=
Trim down
Vout =
R
D
=
1
5.05
36.57
1
4.95
45.53
2
5.10
16.58
2
4.90
20.61
3
5.15
9.92
3
4.85
12.31
4
5.20
6.58
4
4.80
8.15
5
5.25
4.59
5
4.75
5.66
6
5.30
3.25
6
4.70
4.00
7
5.35
2.30
7
4.65
2.81
8
5.4
1.59
8
4.60
1.92
9
5.45
1.03
9
4.55
1.23
10
5.50
0.59
10
4.50
0.68
%
Volts
kOhms
%
Volts
kOhms
Series
RP60-xx12SG
Trim up
Vout =
R
U
=
Trim down
Vout =
R
D
=
1
12.12
367.91
1
11.88
460.99
2
12.24
165.95
2
11.76
207.95
3
12.36
98.64
3
11.64
123.60
4
12.48
64.98
4
11.52
81.42
5
12.60
44.78
5
11.40
56.12
6
12.72
31.32
6
11.28
39.25
7
12.84
21.70
7
11.16
27.20
8
12.96
14.49
8
11.04
18.16
9
13.08
8.88
9
10.92
11.13
10
13.20
4.39
10
10.8
5.51
%
Volts
kOhms
%
Volts
kOhms
RP60-xx15SG
Trim up
Vout =
R
U
=
Trim down
Vout =
R
D
=
1
15.15
404.18
1
14.85
499.82
2
15.3
180.59
2
14.70
223.41
3
15.45
106.06
3
14.55
131.27
4
15.60
68.80
4
14.40
85.20
5
15.75
46.44
5
14.25
57.56
6
15.90
31.53
6
14.10
39.14
7
16.05
20.88
7
13.95
25.97
8
16.20
12.90
8
13.80
16.10
9
16.35
6.69
9
13.65
8.42
10
16.50
1.72
10
13.50
2.282
%
Volts
kOhms
%
Volts
kOhms
PROTECTIONS
Parameter
Short Circuit Protection (SCP)
3.3Vout
5Vout
Zener Diode Clamp
12Vout
15Vout
% of Iout rated
I/P to O/P
I/P to O/P to case
500VDC
Notes:
Note9: This power module is not internally fused. An input line fuse must always be used.
PD-4
REV.: 3/2017
www.recom-power.com
Condition
Value
continuous, automatic recovery
3.7VDC - 5.4VDC
5.6VDC - 7.0VDC
13.8VDC - 17.5VDC
16.8VDC - 20.5VDC
120°C typ.
150% max.
1.6kVDC/1 minute
1.6kVDC/1 minute
1GΩ min.
1500pF max.
Over Voltage Protection (OVP)
Over Temperature Protection (OTP)
Over Load Protection (OLP)
Isolation Voltage
Isolation Resistance
Isolation Capacitance
RP60-G
DC/DC Converter
Specifications
measured at Ta = 25°C, nominal input voltage, full load otherwise noted
ENVIRONMENTAL
Parameter
Operating Temperature Range
Maximum Case Temperature
Temperature Coefficient
Thermal Impedance
Operating Humidity
Thermal Shock
Vibration
MTBF
MIL-HDBK-217F
Bellcore TR-NWT-000332
(10)
natural convection (20LFM) without Heat-sink
natural convection (20LFM) with Heat-sink
Series
Condition
without derating
with derating
Value
-40°C to +50°C
-40°C to +110°C
+110°C max.
±0.02%/°C max.
10.5°C/Watt
8.4°C/Watt
5% - 95% RH
MIL-STD-810F
MIL-STD-810F
408.9 x 10
3
hours
1093 x 10
3
hours
Derating Graph
(11)
RP60-483.3SG
100
80
60
40
20
0
-40
100
80
60
40
20
0
-40
RP60-483.3SG with Heat-sink
Output Power [%]
-20
0
20
40
Ambient Temperature [°C]
50
60
80
100 120
110
Output Power [%]
-20
0
20
40
Ambient Temperature [°C]
60
63
80
100 120
110
Notes:
Note10: BELLCORE TR-NWT-000332. Case l: 50% Stress, Temperature at 40°C (Ground fixed and controlled environment).
Note11: Derating graphs are valid only for the shown part numbers. If you need detailed derating-information about a part-
number not shown here please contact our technical support service at techsupportAT@recom-power.com.
