l VDS 5x3.2mm 3.3V VCXO
Page 1 of 2
Model: FVXO-l C53 SERIES RoHS Compliant / Pb Free
Rev. 9/6/2006 Preliminary
http://www.foxonline.com/need_a_sample.htm
Low Cost, Low Jitter, Fast Delivery
5.15 Max
#6
#5
#4
MODEl SEl ECTION Gu IDE
F VX O - l C 5 3 b R - 155.520000
L = LVDS
C = Ceramic
5 = 5x3.2mm
3 = 3.3V
Frequency
Blank = -20~+70ºC
R = -40~+85ºC
B = ±50PPM APR
X
PRESS
O
3.35 Max
Pin 1 Designator
(FOX Head or Dot)
#1
#2
#3
1.4 Max
2.54
• El ECTRICAl CHARACTERISTICS
Frequency Range (F
o
)
Absolute Pull Range (APR)
1
Storage Temperature Range (T
stg
)
Supply Voltage (V
dd
)
Control Voltage (V
c
)
Input Current
(I
dd
)
Output Symmetry (50% Vp-p Level)
Rise Time
(T
r
) (20% ~ 80% Vp-p)
Fall Time
(T
f
) (80% ~ 20% Vp-p)
Differential Output Voltage (V
od
)
Output Offset Voltage
(V
os
)
Differential Output Swing (Vp-p)
Output Load
Start-up Time
(T
s
)
Output Enable / Disable Time
2
Linearity
Modulation Bandwidth
Maximum Soldering Temp / Time
Moisture Sensitivity Level (MSL)
Termination Finish
1
1.2
PARAMETERS
1.000
MHz
~ 1.100
GHz
± 50 PPM Min
-55ºC ~ +125ºC
3.3V ± 5%
1.65V ± 1.5V
100mA
45% ~ 55%
400pS
400pS
0.250V ~ 0.450V
1.125V Typ.
0.35Vp-p Min
100 Ohms Typ.
10mS
100nS
±10%
10kHz Min
260ºC / 10 Seconds
1
Au
MAX
(unless otherwise noted)
0.64 Typ.
Recommended
Solder Pad Layout
2.54
2.1
1.27
0.8
All dimensions are in millimeters.
Actual Marking Depicted
#1) Vc
#2) E/D
#3) GND
Pin Connections
#4) Out 1
#5) Out 2
#6) V
dd
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load
change, aging, shock, and vibration.
2
An internal pullup resistor from pin 2 to pin 6 allows active output if pin 2 is left open.
- If you have specific jitter or phase noise requirements please contact Fox Technical
Support for availability.
- A 0.01µF bypass capacitor should be placed between
V
dd
(Pin 6) and GND
(Pin 3) to minimize power supply line noise.
- The above specifications, having been carefully prepared and checked, is believed
to be accurate at the time of publication; however, no responsibility is assumed by Fox
Electronics for inaccuracies.
Recommended Circuit:
.01uF
Vc
E/D
#1
#2
#6
#5
V
DD
Output 2
100 Ohms
#3
#4
Output 1
US 6,664,860, US 5,960,403, US 5,952,890; US 5,960,405; US 6,188,290;
Foreign Patents: R.S.A. 98/0866, R.O.C. 120851; Singapore 67081, 67082; EP 0958652
China ZL 98802217.6, Malaysia MY-118540-A, Philippines 1-1998-000245
US and Foreign Patents Pending
X
PRESS
O® Fox Electronics
Patent Numbers:
• ENAbl E / DISAbl E Fu NCTION
2
(Pin 2)
OUTPUT (Pin 4, Pin 5)
OPEN
ACTIVE
'1' Level V
ih
≥
70%
V
dd
ACTIVE
'0' Level V
il
≤
30%
V
dd
High Z
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282 |
Taiwan
Tel: +888.2.22073427 Fax +886.2.22073486
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
l VDS 5x3.2mm 3.3V VCXO
Page 2 of 2
Model: FVXO-l C53 SERIES RoHS Compliant / Pb Free
Rev. 9/6/2006 Preliminary
http://www.foxonline.com/need_a_sample.htm
Low Cost, Low Jitter, Fast Delivery
• TAPE SPECIFICATIONS
(millimeters)
MODEl
FVXO-LC53
• REEl SPECIFICATIONS
(millimeters)
G H
I
J
K
l
M
b
C D E
F
STD Reel QTY
MODEl
A
FVXO-LC53
2.0
∅13 ∅21 ∅80 ∅255
17.5 2.0
2,000
∅1.5
4.0 8.0 7.5 16.0 2.15
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282 |
Taiwan
Tel: +888.2.22073427 Fax +886.2.22073486
|
Japan
Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
