APPLICATION
TOOLING
Crimping tools and machines
Strip-crimp applicator
for side feeding terminals
MKS-SC
Crimping tools and machines
The arrow mark indocates the press that is applicable to the applicator.
Crimping applicator
for end-feeding terminals
MK-L
Semi-automatic press
Semi-automatic crimping machines (presses)
contact a wire to a chain terminal each time a
footswitch is pressed.
Crimping applicator
for side-feeding terminals
MKS-L
Crimping applicator
for end-feeding flag terminals
MKF-L
AP-K2N
Compact crimping applicator
for side-feeding terminals
MKS-LS
• Dimensions:
(W
×
L
×
H)280
×
480
×
505mm
• Weight:
Approx. 90kg(198lb)
• Power source:
100V AC, Single-phase 50/60Hz
• Pressure output:
14.7kN[1,500kg(3307lb)]
• Dies:
Applicator replacement
1
2
Hand
tools
Crimping tools
Hand tools
for chain terminals
for loose piece terminals
Hand tools
for loose piece terminals
Extraction tool
Crimping tools
Extraction and Insertion tools
Insertion tool
YRS
series
YC
series
YRM
series
YRF
series
YRK
series
YRK-EX
series
Terminals and parts model
number in alphabetical order
Dimensions:
(W
×
L) 59
×
224mm
Dimensions:
(W
×
L) 70
×
296mm
Dimensions:
(W
×
L) 59
×
224mm
Dimensions:
(W
×
L) 70
×
295mm
80
×
305mm
Dimensions:
(W
×
L
×
D)
75
×
314
×
25mm
Dimensions:
(W
×
L
×
D)
75
×
314
×
25mm
Crimping tools
It is the manual tool that is convenience to terminate very small quantity of contacts for prototype or maintenance.
It is composed of two crimping dies for the conductor and insulation, and can be crimp easily.
YRK and YRK-EX can be used for mass-production.
Note: (1) These tools are for prototype tooling or repair.
(2) YC tool has two crimping sections (A and B). YRS tool has also two crimping sections by inverting upper dies.
Be sure to check applicable wires before use. Since the dies are fixed, the crimping height cannot be adjusted. Therefore, some of the
applicable wires described in this catalog may not be crimped properly.
Before use, check for proper crimping (such as tensile strength, terminal/contact deformation).
(3) These tools are not applicable to 2-wire crimping.
(4) When hand crimping board-in terminals (SAN, SCN, SDN, SGN, SIN, SJN, SZN), care should be taken not to contaminate the solder tails of
the terminals, as with greasy or oily fingers. If a solder problem arises, some cleaning of the tips of the terminal is advisable.
(5) WC and JUC hand tools are provided by J.S.T.(U.K.) LTD. and contact them about the details of these hand tools.
Extraction tool is used to extract
contacts improperly inserted in the housing.
Insertion tool allows contacts be inserted
in the housing.
This tool greatly increases efficiency especially
when thin wires are used.
YRS series
JK-SP/SS2***
J-SP/SS1***
J-SP/SS2***
LFO-1.0-250N
LFO-2.5-250N
MD-SP12**
MD-SP22**
RA-SC1290
RF-SC22**
RPJ-SP/SS2331
SAA-21(T)-**
SAA-50(T)-**
SAA-51(T)-**
SAB-51(T)-**
SACH-003G-P0.2
SACH-002GU-P0.3
SAN-002T-0.8A
SAN-002T-0.8K
SBH-001T-P0.5
SBHL-002T-P0.5
SBHM-001T-P0.5
SBHS-002T-P0.5A
SBHS-002T-P0.5A
SBHSM-002T-P0.5
SBHT-002T-P0.5
SBN-001T-1.0
SCN-001T-1.0K
SCN-001T-P1.0
SCS-41T-2.3
SCSN-41T-P2.3
SCZH-002T-P0.5
Note: Contact JST for wire range.
