Fuseholders and fuse carriers may be ordered separately.
0709
BU-SB09620
Page 1 of 2
Data Sheet 2119
Dimensions - in (mm)
Terminal Options
Screwdriver Type Carrier
3
Solder/
⁄
16˝
Quick-Connect
Rt. Angle
Carrier Options
1
⁄
4
˝ Quick-Connect
Rt. Angle
⁄
4
˝ x
1
⁄
4
˝
(“I” Equals Inches)
1
Maximum
Panel
Thickness
Common Dimensional Data:
(Screwdriver Slotted)
1.75˝ (44.5mm)
NOTE: Plus In-Line Terminal
0.17"
(4.37mm)
In-Line
In-Line
5 x 20mm
(“M” Equals Metric)
Screwdriver
Screwdriver
0.34"
(8.7mm)
0.33"
(8.3mm)
0.47"
(11.9mm)
0.45"
(11.5mm)
1.58"
(40.03mm)
0.30˝
7.62mm
Low Profile
Rear Hex Nut
0.41"
(10.31mm)
HTB-32I-R
HTB-34I-R
HTB-36I-R
HTB-38I-R
3
—
HTB-3
1.34"
(34.13mm)
HTB-32M-R
HTB-34M-R
HTB-36M-R
HTB-38M-R
—
3
HTB-52I-R
0.125˝
3.18mm
HTB-54I-R
HTB-56I-R
HTB-58I-R
3
—
High Profile
Rear Hex Nut
0.17"
(4.37mm)
HTB-5
1.59"
(40.08mm)
HTB-52M-R
HTB-54M-R
HTB-56M-R
HTB-58M-R
—
3
HTB-92I-R
0.125˝
3.18mm
HTB-94I-R
HTB-96I-R
HTB-98I-R
3
—
Low-Profile
Snap-In
HTB-9
HTB-92M-R
HTB-94M-R
HTB-96M-R
HTB-98M-R
—
3
Fuseholders and fuse carriers may be ordered separately.
Ordering Information
FUSE CARRIER ONLY
HTB-
S
P
Packing
(Blank)
– Std.
BK/
– Bulk
Product
Symbol
Fuse Carrier
I —
1
/
4
˝
x 1
1
/
4
˝
M —
5 x 20mm
Rear Terminal Configuration
2 —
Solder /
3
/
16
˝
Quick-Connect
(In-Line)
4 —
Solder /
3
/
16
˝
Quick-Connect
(Right Angle)
6 —
1
/
4
˝
Quick-Connect (In-Line)
8 —
1
/
4
˝
Quick-Connect (Right Angle)
Splash Proof
Cap with O-Ring
(Optional on Knob
Holders Only)
Body Configuration and Mounting
Knob Holders
2 —
Low Profile (Rear Panel Hex-Nut)
4 —
High Profile
*
6 —
(Front Panel Hex-Nut)
8 —
Low Profile (Snap-In)
Screwdriver Slotted Holders
3 —
Low Profile
5 —
High Profile
9 —
Low Profile (Snap-In)
Packaging
(Blank)
– Std.
BK/
– Bulk
-R
RoHS
Compliant
Product
Symbol
FT —
Knob Type
(For 20, 40, 60,
and 80 Series
Only)
ST —
Screwdriver
Slotted (For 30,
50, and 90 Series
Only)
Fuse Carrier
I —
1
/
4
˝
x
1
1
/
4
˝
M —
5mm x 20mm
*Profile varies with panel thickness. Holder installs thru rear of panel.
Packaging
Packaging Code Prefix
Blank
BK
Description
10 fuse holders packed into a carton
100 fuse holders packed into a cardboard shelf package
The only controlled copy of this Data Sheet is the electronic read-only version located on the Cooper Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin is
intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Cooper Bussmann reserves the right, without notice, to change
design or construction of any products and to discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice, any technical information contained
in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
Life Support Policy: Cooper Bussmann does not authorize the use of any of its products for use in life support devices or systems without the express written approval of an officer of the Company. Life support
systems are devices which support or sustain life, and whose failure to perform, when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in
