F-213-1
(4,19 mm) .165"
PMSD, PMSDT, PMSS, PMSST SERIES
PMSST–05–24–SP–03.50–D–LUS
PMSD–03–18–SP−03.50−D−LUS
DISCRETE WIRE JUMPERCABLE ASSEMBLY
POWER CABLE
SPECIFICATIONS
For complete specifications
see www.samtec.com?PMSD,
www.samtec.com?PMSDT,
www.samtec.com?PMSS or
www.samtec.com?PMSST
Insulator Material:
Valox 457
Contact Material:
Phosphor Bronze
Plating:
Sn over 50µ"
(1,27 µm) Ni
Operating Temp Range:
-35°C to +105°C (PVC)
®
-55°C to +125°C (*Teflon )
Voltage Rating:
22 & 24 AWG =
300 VAC/424 VDC (PVC)
16, 18 & 20 AWG =
600 VAC/848 VDC (PVC)
24 AWG =
®
300 VAC/424 VDC (*Teflon )
Wire:
16 to 24 AWG
RoHS Compliant:
Yes
CURRENT RATING
(PER CONTACT)
AMBIENT PMSD/ PMSDT/
TEMP
IPBT
IPBT
20°C
12.1A
12A
40°C
10.5A
10.5A
60°C
8.7A
8.7A
75°C
7A
7A
6 POS.
6 POS.
(2x3)
(2x3)
16 AWG 18 AWG
POWERED POWERED
Mates with:
IPBT
Plastic latch
Wire range
from 16-24
AWG
• Individually
shrouded contacts
• Plastic latches
Single or
Double end
option
TYPE
PINS
PER ROW
WIRE
GAUGE
LEAD
STYLE
ASSEMBLED
LENGTH
END
OPTION
LATCH
OPTION
PMSD
= Double Row
PVC Cable
–02, –03,
–04, –05,
–16
–18
–206
(20 AWG/
600 volts)
–SP
= Standard
Power
–“XX.XX”
= Wire
Length
in Inches
(88,90 mm)
03.50" min.
–S
= Single End
–D
= Double End
(Latch required)
PMSDT
= Double Row
*Teflon
®
Cable
(24 AWG only)
APPLICATION
SPECIFIC OPTION
• Color coded cables
(*Teflon
®
N/A).
• Other sizes/pin counts.
• 20 AWG/300 Volts
Call Samtec.
*DuPont
™
Teflon
®
is a
registered trademark of the
E.I. du Pont de Nemours
and Company or its affiliates.
–22
–24
No. of Positions
x (4,19) .165
+ (1,02) .040
05
02 01
(4,19) .165
PMSS
= Single Row
PVC Cable
–LUS
= Plastic Latch up,
straight
(7,95)
.313
PMSST
= Single Row
*Teflon
®
Cable
(24 AWG only)
(5,41)
.213
–LDS
Assembled
Length
± (3,18)
.125
= Plastic Latch down,
straight
PMSS/PMSST
No. of Positions
x (4,19) .165
+ (1,02) .040
(4,19)
.165
05
02 01
–LUX*
= Plastic Latch up,
crossed
–LDX*
(12,14)
.478
Note:
For wiring option
information refer to drawing
on web.
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
= Plastic Latch down,
crossed
*(PMSD/PMSDT only)
–D–LUS
10
06
PMSD/PMSDT
WWW.SAMTEC.COM
