F-213-1
TW–08–09–F–T–250–100
TW–16–06–L–D–500–100
(2,00 mm) .0787"
TM
TW–20–03–T–Q–400–085
TW SERIES
THROUGH-HOLE BOARD STACKERS
SPECIFICATIONS
For complete specifications
see www.samtec.com?TW-TH
Insulator Material:
Black Liquid
Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50µ" (1,27 µm) Ni
Current Rating:
3A per contact @ 80°C ambient
Operating Temp Range:
-55°C to +105°C with Tin;
-55°C to +125°C with Gold
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
Mates with:
CLT, SQT, SQW, ESQT,
TLE, SMM, MMS, TCSD
Specify stacker
height in (0,13 mm)
.005" increments
ALSO AVAILABLE
Choice of
one through
six rows
Paste In Hole (PIH) processing.
Contact Samtec ASP Group.
(2,00 mm)
.0787 pitch
Note:
For added mechanical
stability, Samtec recommends
mechanical board spacers be
used in applications with gold or
selective gold plated connectors.
Contact ipg@samtec.com for
more information.
Note:
This Series is
non-standard, non-returnable.
TW
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
below.
PLATING
OPTION
ROW
OPTION
STACKER
HEIGHT
TAIL
SPEC
–F
= Gold flash
on post,
Matte Tin on tail
–S
= Single
Row
02 thru 50
–“XXX”
= Tail Length
in inches
(0,13 mm) .005"
increments
Example: -150
Example: –250
= (3,81 mm)
= (6,35 mm)
.150"
.250"
LEAD
STYLE
OAL
(8,20) .323
(9,60) .377
(13,60) .535
(14,10) .555
(15,10) .594
(17,10) .673
(19,10) .751
(21,10) .830
(11,60) .456
(15,60) .614
(10,08) .397
(28,19) 1.110
Also Available
2 mm Shunt
See 2SN Series.
–L
= 10µ" (0,25 µm)
Gold on post,
Matte Tin on tail
–D
= Double
Row
= Stacker
Height
in inches
(0,13 mm)
.005"
increments
–“XXX”
–T
= Triple
Row
Surface
Mount
See previous page.
300
04
–T
= Matte Tin
Note:
Other Gold
No. of
plating options
rows
available.
x
(2,00)
Contact Samtec.
.0787
–“XXX”
= Polarized
Position
(Specify
position to
be removed)
(2,00)
.0787
TYP
–Q
= Four
Row
Low
Profile
See TMM Series.
01
–5
= Five
Row
–S, –D*, –Q
Right
Angle
See TMM Series.
POST
–T, –5, –6
(0,51) .020 SQ
295
–6
= Six
Row
STACKER
(1,27)
HEIGHT
See
OAL
.050
MIN
Chart
*
*
ROW OPTION
–01
–02
–03
–04
–05
–06
–07
–08
–09
–10
–11
–12
Shrouded
Double
Row
See ZLTMM
Series.
*
Style –08 & –12 = S & D only
STACKER HEIGHT
(3,05) .120 MIN
(4,06) .160 MIN
TAIL
(0,00) .000 MIN
(2,00) .0787
–S, –D*, & –Q
–T, –5, –6
will not have standoffs.
–S, –D*, –Q
–T, –5, –6
*
–D with stacker height greater than (4,06mm) .160"
WWW.SAMTEC.COM
