WD2511AJT01 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> WD2511AJT01

Preview

WD2511AJT01: DescriptionMulti Protocol Controller, MOS, PQCC68; CategoryThe embedded processor and controller Microcontrollers and processors; File Size4MB，64 Pages; ManufacturerWestern Digital Corp.

Download Datasheet Parametric Compare View All

WD2511AJT01 Overview

Multi Protocol Controller, MOS, PQCC68

WD2511AJT01 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Western Digital Corp.
Reach Compliance Code	unknown
JESD-30 code	S-PQCC-J68
JESD-609 code	e0
Number of terminals	68
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Encapsulate equivalent code	LDCC68,1.0SQ
Package shape	SQUARE
Package form	CHIP CARRIER
power supply	5,12 V
Certification status	Not Qualified
Maximum slew rate	330 mA
surface mount	YES
technology	MOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
uPs/uCs/peripheral integrated circuit type	SERIAL IO/COMMUNICATION CONTROLLER, MULTI PROTOCOL

Preview

Download Datasheet

View All

WD2511AJT01 Related Products

	WD2511AJT01	WD2511AAN01	WD2511AAN05	WD2511AJT11	WD2511AJT05
Description	Multi Protocol Controller, MOS, PQCC68	Multi Protocol Controller, MOS, CDIP48	Multi Protocol Controller, MOS, CDIP48	Multi Protocol Controller, MOS, PQCC68	Multi Protocol Controller, MOS, PQCC68
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible
Maker	Western Digital Corp.	Western Digital Corp.	Western Digital Corp.	Western Digital Corp.	Western Digital Corp.
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown
JESD-30 code	S-PQCC-J68	R-XDIP-T48	R-XDIP-T48	S-PQCC-J68	S-PQCC-J68
JESD-609 code	e0	e0	e0	e0	e0
Number of terminals	68	48	48	68	68
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C
Package body material	PLASTIC/EPOXY	CERAMIC	CERAMIC	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QCCJ	DIP	DIP	QCCJ	QCCJ
Encapsulate equivalent code	LDCC68,1.0SQ	DIP48,.6	DIP48,.6	LDCC68,1.0SQ	LDCC68,1.0SQ
Package shape	SQUARE	RECTANGULAR	RECTANGULAR	SQUARE	SQUARE
Package form	CHIP CARRIER	IN-LINE	IN-LINE	CHIP CARRIER	CHIP CARRIER
power supply	5,12 V	5,12 V	5,12 V	5,12 V	5,12 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum slew rate	330 mA	330 mA	330 mA	330 mA	330 mA
surface mount	YES	NO	NO	YES	YES
technology	MOS	MOS	MOS	MOS	MOS
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	J BEND	THROUGH-HOLE	THROUGH-HOLE	J BEND	J BEND
Terminal pitch	1.27 mm	2.54 mm	2.54 mm	1.27 mm	1.27 mm
Terminal location	QUAD	DUAL	DUAL	QUAD	QUAD
uPs/uCs/peripheral integrated circuit type	SERIAL IO/COMMUNICATION CONTROLLER, MULTI PROTOCOL	SERIAL IO/COMMUNICATION CONTROLLER, MULTI PROTOCOL	SERIAL IO/COMMUNICATION CONTROLLER, MULTI PROTOCOL	SERIAL IO/COMMUNICATION CONTROLLER, MULTI PROTOCOL	SERIAL IO/COMMUNICATION CONTROLLER, MULTI PROTOCOL

Recommended Resources

75kW asynchronous motor synchronized operation trigger circuit

One of the thermostatic control circuits using 555 time base integrated circuit

TDA2822M power amplifier circuit diagram

LT1111 working principle diagram (a)

LA4100, LA4102, LA4112 typical application circuits

24v/3V voltage stabilizing circuit
