Document 333-1
SMT Power Inductors - LPO6610 Series
This series has been specially de-
signed for applications requiring a very
small footprint and the lowest pos-
sible height: notebook computers,
PDAs, PC Cards, mobile phones and
other handheld products.
Despite their low profile (1 mm) these
inductors offer excellent current han-
dling – up to 2.1 A. They are available in 16 inductance
values from 1.2 to 330 µH.
Coilcraft
Designer’s Kit C367
contains samples of all
values shown. To order, contact Coilcraft or purchase
on-line at
http://order.coilcraft.com.
Part number
1
LPO6610-122ML_
LPO6610-152ML_
LPO6610-222ML_
LPO6610-332ML_
LPO6610-472ML_
LPO6610-682ML_
LPO6610-103ML_
LPO6610-153ML_
LPO6610-223ML_
LPO6610-333ML_
LPO6610-473ML_
LPO6610-683ML_
LPO6610-104ML_
LPO6610-154ML_
LPO6610-224ML_
LPO6610-334ML_
L
2
DCR
±20% max
(µH) (Ohms)
1.2
0.08
1.5
0.10
2.2
0.12
3.3
0.16
4.7
0.20
6.8
0.32
10
0.41
15
0.55
22
0.85
33
1.3
47
1.8
68
2.5
100
3.5
150
5.0
220
7.0
330
15.0
SRF
typ
(MHz)
190
140
115
90
88
66
55
42
38
29
22
18
14
12
10
8
1. When ordering, please specify
termination
and
packaging
codes:
Isat
3
(A)
2.1
1.9
1.6
1.3
1.1
0.90
0.80
0.65
0.50
0.40
0.35
0.30
0.25
0.18
0.16
0.13
Irms
4
(A)
1.7
1.5
1.4
1.2
1.1
0.85
0.75
0.60
0.52
0.42
0.36
0.30
0.26
0.21
0.18
0.13
LPO6610-334MLC
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit.
Special order: T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (1000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
2. Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc.
3. DC current at which the inductance drops 10% (typ) from its value
without current.
4. Current that causes a 40°C temperature rise from 25°C ambient.
5.
Ambient temperature range:
–40°C to +85°C with
Irms
current
+85°C to +125°C with derated current
6.
Storage temperature range:
Component: –55°C to +85°C
Packaging: –55°C to +80°C
7.
Resistance to soldering heat:
Three reflows at >217°C for 90 seconds
(+260°C ±5°C for 20 – 40 seconds), allowing parts to cool to room
temperature between.
8. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 333-1
Revised 04/24/07
© Coilcraft, Inc. 2007
