STANDARD POWER INDUCTORS - SURFACE MOUNT
SMT35A
SMT35ALF
*
PART
NUMBER
SMT35A-220
SMT35A-820
SMT35A-121
SMT35A-181
SMT35A-501
SMT35A-801
SMT35A-102
SMT35A-152
SMT35A-202
SMT35A-252
SMT35A-332
SMT35A-502
SMT35A-682
SMT35A-103
SMT35A-153
SMT35A-203
SMT35A-303
TRADITIONAL
Pb
COMPLIANT
RoHS
Wirewound,Toroidal, Dual Wound
L µH
@ 100kHZ
0.22
0.82
1.2
1.8
5.0
8.0
10
15
20
25
33
50
68
100
150
200
300
PARALLEL RATINGS
DCR
SATURATION
OHMS
CURRENT
NOM
A DC
0.0028
0.0039
0.0050
0.0077
0.0180
0.0270
0.0400
0.0460
0.0670
0.0950
0.1380
0.2060
0.2930
0.5960
0.7220
0.8140
1.0060
18.80
12.50
9.38
7.50
4.69
3.75
3.13
2.68
2.34
2.08
1.79
1.50
1.29
1.04
0.85
0.75
0.60
CURRENT
RATING
A DC
10.90
9.40
8.22
6.74
4.34
3.50
2.89
2.69
2.24
1.89
1.56
1.28
1.07
0.75
0.68
0.64
0.58
L µH
@ 100kHZ
0.88
3.28
4.80
7.20
20
32
40
60
80
100
132
200
272
400
600
800
1200
SERIES RATINGS
DCR
SATURATION CURRENT
OHMS
CURRENT
RATING
NOM
A DC
A DC
0.0113
0.0155
0.0200
0.0298
0.0717
0.1110
0.1610
0.1870
0.2690
0.3800
0.5560
0.8230
1.17
2.38
2.89
3.26
4.03
9.38
6.25
4.69
3.75
2.34
1.88
1.56
1.34
1.17
1.04
0.89
0.75
0.65
0.52
0.43
0.38
0.30
5.47
4.68
4.11
3.37
2.17
1.75
1.45
1.35
1.12
0.94
0.78
0.64
0.54
0.38
0.34
0.32
0.29
All part numbers provide 25% tolerance on inductance
Custom designs are available to meet your specific requirements; please contact factory
*Add “LF” suffix for RoHS requirement. Example: SMT35A-220LF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
NOTES:
TOP VIEW
0.380
DOT TO
1
(9.65)
INDICATE
PIN 1
SQ MAX
2
GOWANDA
SMT35A
-XXX
3
0.510
(13.0) MAX
4
0.235 (5.97)
MAX
SIDE VIEW
RECOMMENDED FOOTPRINT
1
0.392
(9.96)
0.145
(3.68) SQ
0.392
(9.96)
4
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 40°C temperature
rise at an ambient temperature of 85°C
• Saturation Current is the approximate value
that will reduce the initial inductance by 30%
TAPE AND REEL SPECS:
2
3
in. (mm)
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
800
12 mm
24 mm
13 in.
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
013114
