Power Inductors - Shielded
ctparts.com
CTCDRH104 Series
From 1.0 µH to 470 µH
Part
Number
CTCDRH104_-1R0M
CTCDRH104_-1R5M
CTCDRH104_-2R2M
CTCDRH104_-3R3M
CTCDRH104_-4R7M
CTCDRH104_-6R8M
CTCDRH104_-100M
CTCDRH104_-120M
CTCDRH104_-150M
CTCDRH104_-180M
CTCDRH104_-220M
CTCDRH104_-270M
CTCDRH104_-330M
CTCDRH104_-390M
CTCDRH104_-470M
CTCDRH104_-560M
CTCDRH104_-680M
CTCDRH104_-820M
CTCDRH104_-101M
CTCDRH104_-121M
CTCDRH104_-151M
CTCDRH104_-181M
CTCDRH104_-221M
CTCDRH104_-271M
CTCDRH104_-331M
CTCDRH104_-391M
CTCDRH104_-471M
Not shown at actual size.
SPECIFICATIONS
Parts are only available in ±20% inductance tolerance.
CTCDRH104F
Please specify “F” for RoHS Compliant
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(Ω)
.014
.017
.024
.029
.032
.044
.050
.054
.069
.084
.094
0.11
0.15
0.17
0.21
0.23
0.29
0.36
0.41
0.45
0.64
0.84
0.86
1.07
1.37
1.55
1.74
Rated
DC
(A)
8.50
8.00
7.50
7.00
6.00
5.00
2.40
2.25
2.00
1.80
1.65
1.45
1.35
1.20
1.10
1.00
0.93
0.84
0.76
0.70
0.63
0.57
0.52
0.47
0.43
0.39
0.36
Inductance
(µH)
1.0
1.5
2.2
3.3
4.7
6.8
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
Compliant
Available
RoHS
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
VTR power supplies, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters
Inductance Tolerance:
±20%
Testing:
Inductance is tested on an HP4285A at 100kHz
Packaging:
Tape & Reel
Marking:
Marked with inductance code
Rated DC:
Maximum allowable DC current is that which causes a
25% inductance reduction from the initial value, or coil temperature
to rise by 40°C, whichever is smaller. (Reference ambient
temperature 25°C).
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
9.2
0.362
B
Max.
10.1
0.398
C
Max.
5.0
0.197
D
Typ.
2.0
0.079
E
Typ.
8.3
0.327
F
Typ.
5.3
0.209
A
C
B
XXX
Inductance Code
D
RECOMMENDED LAND PATTERN
Unit: mm
2.5
S
F
E
F
2.3
5.0
2.3
06.05.06
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
