BXA40 SERIES
Triple output
• Meets telecom power supply interface standard
ETS300-132-2
• EN60950, CSA950 and UL1950 safety approvals
• EN61000-4-2, -3, -4, -5, -6 immunity compliant
• Fixed frequency operation at 400kHz
• MTBF in excess of 500,000 hours
• Basic insulation system with 1500V isolation
• Pin-compatible with NFC40 Series
The BXA40 Series providing up to 40 Watts, comprising 4 different models, has been
conceived as an applications-specific range of DC/DC converters, specifically addressing
telecommunications, industrial electronics, test equipment, mobile telecommunications
and distributed power applications. The series offers two wide input voltage ranges, 18-
36VDC and 36-75VDC, and is available with 5/±12V and 5/±15V triple outputs. The
BXA40 series is designed to meet ETSI telecoms interface standard ETS300-132-2. With
safety approval to IEC950 and basic insulation, the 48VDC models are ideal for
telecommunications applications. The 24V models are particularly suited to industrial and
test equipment applications, featuring EN61000-4-2, -3, -4, -5 and -6 immunity
compliance. Other features include low output ripple, overvoltage protection, short circuit
protection and remote enable.
[ 2 YEAR WARRANTY ]
SPECIFICATION
OUTPUT SPECIFICATIONS
Line regulation
(See Note 2)
Load regulation
(See Note 3)
Load cross regulation
(See Note 4)
Ripple and noise
(20MHz bandwidth)
All specifications are typical at nominal input, full load at 25°C unless otherwise stated
EMC CHARACTERISTICS
±0.5%
±2.0%
±1.0%
±3.0% typ.,
±5.0% max.
Conducted emissions
Radiated emissions
ESD air
ESD contact
Surge
Fast transients
Radiated immunity
Conducted immunity
EN55022, FCC part 15,
(See Notes 6, 9)
EN55022, FCC part 15
EN61000-4-2, level 3
EN61000-4-2, level 4
EN61000-4-5, level 3
EN61000-4-4, level 3
EN61000-4-3, level 3
EN61000-4-6, level 3
Level B
Perf.
Perf.
Perf.
Perf.
Perf.
Perf.
Level A
criteria 1
criteria 1
criteria 1
criteria 1
criteria 1
criteria 1
Main output
Auxiliary output
Main output
Auxiliary output
Main output
Aux. output
Main output
Auxiliary output
±1.0%
±3.0% typ., ±5.0% max.
50mV pk-pk
20mV rms
100mV pk-pk
20mV rms
±0.02%/°C
GENERAL SPECIFICATIONS
Efficiency
Isolation voltage
Switching frequency
Approvals and
standards (pending)
Case material
Material flammability
Weight
MTBF
Size
MIL-HDBK-217F
Input/output
Basic insulation, input/case
Fixed
See table
1500VDC
1500VDC
Temperature coefficient
Overvoltage protection
transorbs fitted
Short circuit protection
(See Note 5)
Transient response
Voltage accuracy
Minimum Load
Main output
Auxiliary outputs
Main output
Auxiliary output
25% to 100% load
Main output
Auxiliary output
Main output
Auxiliary outputs
6.8V (nom.)
16/20V (nom.)
11A
5A
4.0%
±1.0%
±3.0%
0.6A
0.03A/0.04A
400kHz (typical)
EN60950, UL1950
CSA C22.2 No. 950
Aluminum substrate
with plastic case
UL94V-0
85g typ. (3.0oz)
500,000 hours
INPUT SPECIFICATIONS
Input voltage range
Reverse voltage
protection
Max. input rise and
fall time
Start-up time
Remote ON/OFF
Logic compatibility
ON
OFF
24Vin nominal
48Vin nominal
External fuse
48V
18 to 36VDC
36 to 75VDC
(See Note 7)
5V/ms
ETS300-132
30ms typ.
CMOS/TTL
Open-circuit
<1VDC
2.2 x 2.2 x 0.5 inches
55.9 x 55.9 x 12.7 mm
ENVIRONMENTAL SPECIFICATIONS
Thermal performance
Baseplate operating
temperature
Non-operating
-40°C to +105°C
-55°C to +105°C
8.5°C/W
7.2°C/W
Thermal impedance
(See Note 8)
No air flow, no heatsink
No air flow, with heatsink
Data Sheet © Artesyn Technologies® 2000
The information and specifications contained in this data sheet are believed to be correct at
time of publication. However, Artesyn Technologies accepts no responsibility for
consequences arising from printing errors or inaccuracies. Specifications are subject to
change without notice. No rights under any patent accompany the sale of any such product(s)
or information contained herein.
PAGE 140
DC/DC CONVERTERS
|
40W DC/DC
40 Watt
Wide input DC/DC converters
INPUT
VOLTAGE
18-36VDC
18-36VDC
36-75VDC
36-75VDC
Notes
1
2
3
Nominal line, at no load.
Nominal line to high line, nominal line to low line.
Load regulation:
Main output (V1): 25 to 100% with 25% to 100% balanced on auxiliaries.
Auxiliary outputs (V2 and V3): 25% to 100% balanced on all outputs.
4 Cross regulation:
Main output 100% load, auxiliary 100%, other auxiliary 25% to 100%.
Auxiliary outputs (V2 and V3): main output 100% load, auxiliary 100%,
other auxiliary 25% to 100% or main output 25%, auxiliary 25%, other
auxiliary 25% to 100%.
5 Short circuit protection,
≤
1 minute on auxiliary outputs.
6 For EMI compliance to EN55022 level B please consult factory for details.
For EMI compliance to EN55022 level A, refer to BXA40 Design Note 101.
7 Reverse voltage protection, refer to BXA40 Design Note 101.
8 The maximum operating ambient temperature, without derating depends
on internal power dissipation and module efficiency and cooling method.
Download BXA40 Design Note 101 which provides detailed thermal
calculations and design-in hints from the Artesyn website.
9 An external filter capacitor is necessary for safe operation of the 24V input
models. It is also suggested that an external filter capacitor be used on
the 48V input models. A 4µF (or greater) film capacitor such as: ITW
Paktron Capstick series, part number 405K100CS4 4µF/100V is
recommended, if filtering is not used. See BXA40 Design Note 101.
10 Units with the suffix ‘-M’ at the end of the model number are offered as
standard with metric threaded inserts (M3). To order units with imperial
threaded inserts (4-40 UNC) please remove the suffix ‘-M’ from the model
number. These inserts are used for bolting the unit to a PCB and/or fixing
heatsinks.
11 A top mounted heatsink kit is available for the BXA40. The heatsink may
be oriented parallel to or perpendicular to the direction of the pins, thus
providing optimum flexibility for cooling requirements. The order number
for the top mounted heatsink kit with metric screws is ‘NFC40-HTSK-T’.
The order number for the top mounted heatsink kit with imperial screws is
‘NFC40-HTSK-T-I’.
0.15
(3.82)
OUTPUT
VOLTAGE
5V/±12V
5V/±15V
5V/±12V
5V/±15V
OUTPUT
CURRENT (MAX.)
6A/±0.4A
6A/±0.3A
6A/±0.4A
6A/±0.3A
INPUT
CURRENT
50mA
50mA
30mA
30mA
(1)
TYPICAL
EFFICIENCY
83%
83%
83%
83%
MODEL NUMBER
(10)
BXA40-24T05-12-M
BXA40-24T05-15-M
BXA40-48T05-12-M
BXA40-48T05-15-M
PIN CONNECTIONS
PIN NUMBER
1
2
3
4
5
6
7
8
9
TRIPLE OUTPUT
+ Input
– Input
Control
+ Output (V2)
Common
- Output (V3)
+ Output (V1)
- Output (V1)
No Connection
International Safety Standard Approvals
VDE0805/EN60950/IEC950 File No. 14501-3336-7009
Licence No. 6296
UL1950 File No. E174104
CSA C22.2 No. 950 File No. LR41062C
5
1.90
(48.26)
1.25
(31.76)
0.60
(15.24)
0.2
(5.08)
0.019
(0.50)
3
1.02 (0.043)
Diameter Typ.
2
1
Metric (Suffix '-M'):
M3 Tap Thru. 4 places or
Imperial (No '-M' suffix) 4-
40 UNC (Optional)
0.256 (6.50) Diameter
Stand-off (4 Places)
9
8
7
6
5
4
0.2
(5.08)
1.80
(45.72)
1.90
(48.26)
2.20
±0.02
(55.90
±0.50)
0.50
(12.70)
0.15
(3.90)
0.3
(7.62)
0.1
(2.54)
0.05
(1.27)
0.15
(3.82)
0.6
(15.24)
0.8
0.5
(20.32)
(12.70)
2.20
±0.02
(55.90
±0.50)
BOTTOM VIEW
DS_BXA40T_20000101.PDF
ALL DIMENSIONS IN INCHES (mm)
TOLERANCE :
±
0.004 (0.1)
(Unless otherwise specified)
Please consult our website for the following items:
http://www.artesyn.com
Design Note
PAGE 141
Embedded System
