Cannon, VEAM, BIW
A Historical Achievement of Technology Leadership
Defining and Championing Innovation
Showcasing a portfolio of creativity, ITT’s “Engineered For Life” execution embraces products which have
become ubiquitous in a broad collection of markets including: Military/Aerospace, Civil Aircraft, Industrial
Instrumentation, Medical, Oil & Gas, Energy, Transportation, Telecom/Handset, Computer, Consumer, and
Automotive.
ITT’s rich interconnect history embraces contributions to both technological breakthroughs and social movements.
With one of the industry’s broadest product offerings, ITT’s interconnect products have supported:
•
•
•
•
•
•
•
Every Free World space mission, bringing the universe to our doorstep.
Motion picture, radio, and television equipment, serving laughter and entertainment to millions.
Commercial and military communications systems, linking the voices of the world.
Computerized tools, reshaping the information highway.
Aircraft, rapid transit, and automobiles, mobilizing our expanding society.
Oil and natural gas production, powering the world’s economies.
Agricultural equipment, attacking the roots of world hunger.
www.ittcannon.com
ITT Interconnect Solutions
ITT Interconnect Solutions is a division of the
multi-national ITT Corporation, a $2.5 billion dollar global
enterprise representing the brands Cannon, VEAM,
and BIW. Our connector portfolio remains the most
extensive in the industry offering the most reliable and
cost effective range of interconnect solutions. These
innovations have enabled ITT to provide products and
technologies to such markets as:
•
•
•
•
•
•
•
Automotive
Computer/Consumer
Industrial/Instrumentation
Military/Aerospace
Oil Fields
Telecom/Handset
Transportation
robotics, computerized precision tooling, Kaizen
Project Management, Six Sigma tools, and testing,
give ITT the most optimized global manufacturing
footprint in the interconnect industry.
The Custom Difference
As the industry leader in harsh environment
interconnect applications, ITT’s world class engineering
teams will work directly with our customers to design
and develop cost effective solutions for their applications.
In many cases we may modify one of our standard
designs to ensure a highly reliable solution where timing
is critical. Yet, in those cases where a complete custom
interconnect solution is required, ITT will work with
our customer’s Engineers to design an interconnect
solution which will be cost effective yet highly reliable.
As professional consultants, our Engineering teams will
provide a thorough systems and mechanical analysis
of any proposed solution. These analyses provide our
customers with sophisticated electrical signal and
mechanical characterizations to determine the best
solution for their application.
When you specify a Cannon, VEAM or BIW connector,
you can rely on a product designed, developed, and
manufactured to the highest quality and reliability
standards. This tradition of excellence is based on ITT’s
corporate culture of operating its businesses under the
principles of Six Sigma. At ITT, Six Sigma is not just a
quality philosophy but a complete corporate culture that
drives the entire business. Our Value Based Management
and Value Based Product Development systems are two
cornerstones that allow for the development of both
leadership and product engineering principles, ensuring
the correct industry leading products are developed to
the accepted market driven lead times. These principles
have allowed ITT to become the market leader in all of
our business portfolios.
RoHS Compliance Information
ITT has implemented a strict parts control plan for
all ITT electronics plants worldwide that allows the
Cannon, VEAM, and BIW connector product portfolios
to meet the requirements of European Union Directive
2002/95/EC better know as the Reduction of
Hazardous Substances initiative. As appropriate, specific
Cannon, VEAM, and BIW products may be ordered
with an R prefix number which insures our customers
will receive RoHS compliant parts for their commercial
electronics applications and equipment. Since most
RoHS hazardous substances center around specific
metal plating and lead solder coatings, ITT’s products
for RoHS compliance are available in the following
plating finishes: black zincelectroless nickel, stainless
steel, Anodize over aluminum and Gold plating. It should
be noted that gold plating would be recommended
as the replacement for tin-lead solder when ordering
board mount connectors.
Six Sigma Manufacturing
ITT operates manufacturing facilities in the United States,
Germany, Italy, Mexico, China, Japan and the UK, all of
which have particular product area strengths allowing
ITT to offer a truly global footprint to our customers.
Our facilities are world class and accommodate full
vertical integration utilizing the latest manufacturing
technologies including: automated and robotic machining
centers, Super Market manufacturing cells, Kanban pull
systems, and automated electrical, mechanical, and
optical test and inspection equipment. The combination
of our manufacturing strength and our advanced
manufacturing facilities allows ITT to offer products at
market driven prices. Our capabilities, especially in
Cannon ZIF Connectors
DL
Table of Contents
Introduction
. . . . . . . . . . . . . . . . . 10
• Plastic Body
• 60, 96, 156, or 260 Contact Cavities
• Single Hand Actuation
• Crimp or Square Post Contacts
Product Specifications. . . . . . . . . . . 11
How to Order . . . . . . . . . . . . . . . . . 12
Layout Information . . . . . . . . . . . 13-16
DLM
Introduction
. . . . . . . . . . . . . . . . . 21
• Metal Body
• EMI/RFI Shielding
• 60, 96, 156, 260 or 360 Contact Cavities
• Single Hand Actuation
• Crimp, Square Post or PC/RC Contacts
Product Specifications. . . . . . . . . . . 22
How to Order . . . . . . . . . . . . . . . . . 23
Layout Information . . . . . . . . . . . 24-28
DLP
Introduction
. . . . . . . . . . . . . . . . . 29
• Metal Body
• EMI/RFI Shielding
• Modular Landed Contact System
(DLP-272- 34 Contacts/Module
DLP-408 - 68 Contacts/Module)
• Single Hand Actuation
Product Specifications. . . . . . . . . . . 29
How to Order . . . . . . . . . . . . . . . . . 30
Layout Information . . . . . . . . . . . 31-32
www.ittcannon.com
4
Cannon ZIF Connectors
QLC
• Metal Body
• EMI / RFI Shielding
• 260 Contacts
• Small form factor. For portable equipment
Table of Contents
Introduction
. . . . . . . . . . . . . . . . . 33
Product Specifications
. . . . . . . . . 33
Layout Information
. . . . . . . . . . . 34
Accessories
Introduction
. . . . . . . . . . . . . . . . . 35
• Cannon offers a large selection of
accessories to meet a variety of
application requirements
• Allows customization using standard
components
Selection Guide . . . . . . . . . . . . . . . . 35
Junction Shells, Plastic. . . . . . . . . . . 36
Backshells, Metal. . . . . . . . . . . . . . . 38
Actuating Handles. . . . . . . . . . . . . . 39
Protective Covering . . . . . . . . . . . . . 40
Polarizing Posts . . . . . . . . . . . . . . . . 41
Shells (EMI/RFI) . . . . . . . . . . . . . . . . 42
Contacts
Introduction
. . . . . . . . . . . . . . . . . 43
• Crimp and Buss contacts are available
loose or reeled
• Accommodates wire sizes #42-#18AWG
• Customer installed. Field
installable/removable
Buss Contacts . . . . . . . . . . . . . . . . . 44
Crimp Contacts-Loose / Reeled . . . . 45
Tools and Assembly
Introduction
. . . . . . . . . . . . . . . . . 46
• Cannon offers hand crimp tooling for
low volume applications
• Contact extraction tools
• Automatic tooling can be leased for
large volume applications
Hand Crimp Tools . . . . . . . . . . . . . . 46
Extraction Tools. . . . . . . . . . . . . . . . 47
Assembly Instructions . . . . . . . . . 48-50
Lease Automatic Tooling. . . . . . . 51-52
PCB Hole Pattern and Pad Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53-60
Panel Cutouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61-67
Contact Cavity Arrangements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64-66
www.ittcannon.com
5
