Production specification
Zener Diodes
Features
High reliability
Voltage range 3.3 V to 100 V
Fits onto 5 mm SMD footpads
Wave and reflow solderable Glass passivated junction
Case: SMA molded plastic
Molding compound, UL flammability classification rating 94V-0
Terminals: Solder plated, solderable per MIL- STD-202,Method 208
Polarity: Color band denotes cathode end
BZG05C--SERIES
Mechanical Data
Absolute Maximum Ratings
(@T
A
= 25°C unless otherwise specified)
Parameter
Power dissipation
Non repetitive peak surge power
dissipation
Junction temperature
Storage temperature range
Test condition
R
thJA
< 30 K/W, T
amb
= 60 °C P
diss
3 W
R
thJA
< 100 K/W, T
amb
= 25 °C
tp = 100
μs
sq.pulse, T
j
= 25 °C
prior to surge
Symbol
P
diss
P
diss
P
ZSM
T
j
Value
3
1.25
60
150
Unit
W
W
W
°C
Thermal Characteristics
Parameter
Junction lead
mounted on epoxy-glass hard
tissue, Fig. 1a
Junction ambient
mounted on epoxy-glass hard
tissue, Fig. 1b
mounted on Al-oxid-ceramic
(Al2O3), Fig. 1b
Test condition
Symbol
R
thJL
R
thJA
RthJA
R
thJA
Value
30
150
125
100
Unit
K/W
K/W
K/W
K/W
Electrical Characteristics
Parameter
Forward voltage
Test condition
I
F
= 0.2 A
Symbo
V
F
Min
Typ
Max
1.2
Unit
V
ZDP0023A
Rev.B
www.gmesemi.com
Production specification
Zener Diodes
Device
Type
BZG05C3V3
BZG05C3V6
BZG05C3V9
BZG05C4V3
BZG05C4V7
BZG05C5V1
BZG05C5V6
BZG05C6V2
BZG05C6V8
BZG05C7V5
BZG05C8V2
BZG05C9V1
BZG05C10
BZG05C11
BZG05C12
BZG05C13
BZG05C15
BZG05C16
BZG05C18
BZG05C20
BZG05C22
BZG05C24
BZG05C27
BZG05C30
BZG05C33
BZG05C36
BZG05C39
BZG05C43
BZG05C47
BZG05C51
BZG05C56
BZG05C62
BZG05C68
BZG05C75
BZG05C82
BZG05C91
BZG05C100
marking
code
ZG3.3
ZG3.6
ZG3.9
ZG4.3
ZG4.7
ZG5.1
ZG5.6
ZG6.2
ZG6.8
ZG7.5
ZG8.2
ZG9.1
ZG10
ZG11
ZG12
ZG13
ZG15
ZG16
ZG18
ZG20
ZG22
ZG24
ZG27
ZG30
ZG33
ZG36
ZG39
ZG43
ZG47
ZG51
ZG56
ZG62
ZG68
ZG75
ZG82
ZG91
ZG100
Min
3.1
3.4
3.7
4.0
4.4
4.8
5.2
5.8
6.4
7.0
7.7
8.5
9.4
10.4
11.4
12.4
13.8
15.3
16.8
18.8
20.8
22.8
25.1
28
31
34
37
40
44
48
52
58
64
70
77
85
95
Zener Voltage Range(Note 1)
V
Z
(V)
typ
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
105
Max
3.5
3.8
4.1
4.6
5
5.4
6.0
6.6
7.2
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
25.6
28.9
32
35
38
41
46
50
54
60
66
72
79
87
96
100
@I
ZT
mA
80
60
60
50
45
45
45
35
35
35
25
25
25
20
20
20
15
15
15
10
10
10
8.0
8.0
8.0
8.0
6.0
6.0
4.0
4.0
4.0
4.0
4.0
4.0
2.7
2.7
2.7
BZG05C--SERIES
Electrical Characteristics
(@T
A
= 25°C unless otherwise specified)
Leakage Current
I
R
@ V
R
μA
40
20
10
3.0
3.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
V
1.0
1.0
1.0
1.0
1.0
1.5
2.0
3.0
4.0
4.5
6.2
6.8
7.0
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
