MB9BF117TPMC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> MB9BF117TPMC

MB9BF117TPMC: DescriptionRISC Microcontroller, 32-Bit, FLASH, CORTEX-M3 CPU, 144MHz, CMOS, PQFP176, 24 X 24 MM, 1.70 MM HEIGHT, 0.50 MM PITCH, LEAD FREE, PLASTIC, LQFP-176; CategoryThe embedded processor and controller Microcontrollers and processors; File Size1MB，116 Pages; ManufacturerFUJITSU; Websitehttp://edevice.fujitsu.com/fmd/en/index.html

Download Datasheet Parametric Compare View All

MB9BF117TPMC Overview

RISC Microcontroller, 32-Bit, FLASH, CORTEX-M3 CPU, 144MHz, CMOS, PQFP176, 24 X 24 MM, 1.70 MM HEIGHT, 0.50 MM PITCH, LEAD FREE, PLASTIC, LQFP-176

MB9BF117TPMC Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	FUJITSU
package instruction	LFQFP, QFP176,1.0SQ,20
Reach Compliance Code	compliant
ECCN code	3A001.A.3
Has ADC	YES
Address bus width
bit size	32
CPU series	CORTEX-M3
maximum clock frequency	144 MHz
DAC channel	NO
DMA channel	YES
External data bus width
JESD-30 code	S-PQFP-G176
length	24 mm
Number of I/O lines	154
Number of terminals	176
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	NO
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Encapsulate equivalent code	QFP176,1.0SQ,20
Package shape	SQUARE
Package form	FLATPACK
power supply	3/5 V
Certification status	Not Qualified
RAM (bytes)	98304
rom(word)	786432
ROM programmability	FLASH
Maximum seat height	1.7 mm
speed	144 MHz
Maximum slew rate	180 mA
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
width	24 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC

Preview

Download Datasheet

View All

FUJITSU SEMICONDUCTOR

DATA SHEET

DS706-00016-0v01-E

32-bit ARM

Cortex

-M3 based Microcontroller

MB9B110T Series

MB9BF116S/T, MB9BF117S/T, MB9BF118S/T

DESCRIPTION

The MB9B110T Series are a highly integrated 32-bit microcontrollers dedicated for embedded controllers

with high-performance and competitive cost.

These series are based on the ARM Cortex-M3 Processor with on-chip Flash memory and SRAM, and has

peripheral functions such as Motor Control Timers, ADCs and Communication Interfaces (UART, SIO, I

LIN).

The products which are described in this data sheet are placed into TYPE2 product categories in "FM3

FAMILY MB9Axxx/MB9Bxxx Series PERIPHERAL MANUAL".

Note:

ARM and Cortex are the trademarks of ARM Limited in the EU and other countries.

2011.9

MB9BF117TPMC Related Products

	MB9BF117TPMC	MB9BF118SPMC	MB9BF118TPMC	MB9BF117SPMC
Description	RISC Microcontroller, 32-Bit, FLASH, CORTEX-M3 CPU, 144MHz, CMOS, PQFP176, 24 X 24 MM, 1.70 MM HEIGHT, 0.50 MM PITCH, LEAD FREE, PLASTIC, LQFP-176	RISC Microcontroller, 32-Bit, FLASH, CORTEX-M3 CPU, 144MHz, CMOS, PQFP144, 20 X 20 MM, 1.70 MM HEIGHT, 0.50 MM PITCH, LEAD FREE, PLASTIC, LQFP-144	RISC Microcontroller, 32-Bit, FLASH, CORTEX-M3 CPU, 144MHz, CMOS, PQFP176, 24 X 24 MM, 1.70 MM HEIGHT, 0.50 MM PITCH, LEAD FREE, PLASTIC, LQFP-176	RISC Microcontroller, 32-Bit, FLASH, CORTEX-M3 CPU, 144MHz, CMOS, PQFP144, 20 X 20 MM, 1.70 MM HEIGHT, 0.50 MM PITCH, LEAD FREE, PLASTIC, LQFP-144
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible
package instruction	LFQFP, QFP176,1.0SQ,20	LFQFP, QFP144,.87SQ,20	LFQFP, QFP176,1.0SQ,20	LFQFP, QFP144,.87SQ,20
Reach Compliance Code	compliant	compliant	compliant	compli
ECCN code	3A001.A.3	3A001.A.3	3A001.A.3	3A001.A.3
Has ADC	YES	YES	YES	YES
bit size	32	32	32	32
CPU series	CORTEX-M3	CORTEX-M3	CORTEX-M3	CORTEX-M3
maximum clock frequency	144 MHz	144 MHz	144 MHz	144 MHz
DAC channel	NO	NO	NO	NO
DMA channel	YES	YES	YES	YES
JESD-30 code	S-PQFP-G176	S-PQFP-G144	S-PQFP-G176	S-PQFP-G144
length	24 mm	20 mm	24 mm	20 mm
Number of I/O lines	154	122	154	122
Number of terminals	176	144	176	144
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C
PWM channel	NO	NO	NO	NO
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LFQFP	LFQFP	LFQFP	LFQFP
Encapsulate equivalent code	QFP176,1.0SQ,20	QFP144,.87SQ,20	QFP176,1.0SQ,20	QFP144,.87SQ,20
Package shape	SQUARE	SQUARE	SQUARE	SQUARE
Package form	FLATPACK	FLATPACK	FLATPACK	FLATPACK
power supply	3/5 V	3/5 V	3/5 V	3/5 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
RAM (bytes)	98304	131072	131072	98304
rom(word)	786432	1048576	1048576	786432
ROM programmability	FLASH	FLASH	FLASH	FLASH
Maximum seat height	1.7 mm	1.7 mm	1.7 mm	1.7 mm
speed	144 MHz	144 MHz	144 MHz	144 MHz
Maximum slew rate	180 mA	180 mA	180 mA	180 mA
surface mount	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	0.5 mm	0.5 mm	0.5 mm	0.5 mm
Terminal location	QUAD	QUAD	QUAD	QUAD
width	24 mm	20 mm	24 mm	20 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC
Maker	FUJITSU	FUJITSU	-	FUJITSU
