SMA Male to BNC Male Cable Using LMR-195 Coax
TECHNICAL DATA SHEET
SMA Male to BNC Male Cable Using LMR-195 Coax
Configuration
Connector 1
Connector 1 Specification
Connector 2
Connector 2 Specification
Cable Type
SMA Male
MIL-STD-348A
BNC Male
MIL-STD-348A
LMR-195
PE3C0051
Electrical Specifications
Impedance, Ohms
50
Mechanical Specifications
Cable Assembly
Cable Type
Temperature
Temperature Operating Range, deg C
Temperature Storage Range, deg C
Diameter, in [mm]
.
LMR-195
-40 to +85
-70 to +85
0.571 [14.5]
0.062 [28.12]
Black
0.5 [12.7]
2 [50.8]
2
PE (F)
PE
0.195 [4.95]
Weight, lbs [g]
Cable Color
One Time Minimum Bend Radius, in [mm]
Repeated Minimum Bend Radius, in [mm]
Cable
No of Shields
Dielectric Type
Jacket Material
Jacket Diameter, in [mm]
Connector 1
Type
Configuration
Inner Conductor Material and Plating
Inner Conductor Plating Specification
Coupling Nut Material and Plating
Coupling Nut Plating Specification
Hex Size, in
Torque, in-lbs [Nm]
Body Material and Plating
Body Plating Specification
Dielectric Type
SMA Male
Straight
Brass, Gold
50µ in. minimum
Brass, Nickel
100µ in. minimum
5/16
5 [0.57]
Brass, Nickel
100µ in. minimum
Teflon
Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications:
SMA Male to BNC Male Cable Using LMR-195 Coax PE3C0051
PE3C0051 REV
1
SMA Male to BNC Male Cable Using LMR-195 Coax
TECHNICAL DATA SHEET
Connector 2
Type
Configuration
Inner Conductor Material and Plating
Inner Conductor Plating Specification
Body Material and Plating
Body Plating Specification
Dielectric Type
BNC Male
Straight
Brass, Gold
30µ in. minimum
Brass, Nickel
100µ in. minimum
Teflon
PE3C0051
Compliance Certifications
(visit www.Pasternack.com for current document)
Plotted and Other Data
Notes:
Values at 25 °C, sea level
URL:
http://www.pasternack.com/sma-male-bnc-male-lmr195-cable-assembly-pe3c0051-p.aspx
SMA Male to BNC Male Cable Using LMR-195 Coax from Pasternack Enterprises has same day shipment for domestic and
International orders. Our RF, microwave and fiber optic products maintain a 99% availability and are part of the broadest
selection in the industry.
