10,000 pieces on 7'' reel, 4000 pieces on 7'' reel and 500 pieces on prototype reel. Consult ATC for other options.
The above part number refers to a 600L Series (case size L) 10 pF capacitor, J tolerance (±5%), 200 WVDC, with T termination (Tin Plated over Nickel Barrier,
RoHS Compliant), Tape and Reel packaging.
ATC accepts orders for our parts using designations
with
or
without
the
“ATC” prefix. Both methods of defining the part number are equivalent, i.e.,
part numbers referenced with the “ATC” prefix are interchangeable to parts
referenced without the “ATC” prefix. Customers are free to use either in
specifying or procuring parts from American Technical Ceramics.
For additional information and catalogs contact your ATC representative
or call direct at (+1-631) 622-4700.
Consult factory for 500 piece reels for prototyping.
Consult factory for additional performance data.
A M E R I C A N
ATC North America
+1-631-622-4700
•
sales@atceramics.com
T E C H N I C A L
C E R A M I C S
ATC Asia
86-755-2396-8759
•
sales@atceramics-asia.com
ATC Europe
+46 8 6800410
•
sales@atceramics-europe.com
2
w
w
w
.
a
t
c
e
r
a
m
i
c
s
.
c
o
m
ATC 600L Series Ultra-Low ESR, High Q, NPO RF & Microwave Capacitors
600L ESR vs. Frequency
1
ESR (Ohms)
0.1
27 pF
15 pF
8.2
3.3 pF
1.0 pF
(Typical)
0.01
100
1000
10000
Frequency (MHz)
600L Resonant Frequency Data
Frequency (GHz)
)
0.1
1.0
10.0
100.0
Capacitance (pF)
ATC 600L Series Data Sheet Test Condition Description
Capacitors mounted in series microstrip configuration on 10-mil thick Rogers RO4350
®
softboard,
22-mils wide 1/2 oz. Cu traces.
FSR
= lowest frequency at which S11 response, referenced at capacitor edge, crosses real axis on Smith Chart.
FPR
= lowest frequency at which there is a notch in S21 magnitude response.
A M E R I C A N
ATC North America
+1-631-622-4700
•
sales@atceramics.com
T E C H N I C A L
C E R A M I C S
ATC Asia
86-755-2396-8759
•
sales@atceramics-asia.com
ATC Europe
+46 8 6800410
•
sales@atceramics-europe.com
w
w
w
.
a
t
c
e
r
a
m
i
c
s
.
c
o
m
3
softboard,
ATC 600L Series Ultra-Low ESR, High Q, NPO RF & Microwave Capacitors
Outline Dimensions
Y
W
L
T
L (0402)
L: .040 ± .004 (1.02 ± 0.1)
W: .020 ± .004 (.51 ± 0.1)
T: .024 max. (0.60 max.)
Y: .010 ± .006 (0.25 ± 0.15)
Inches (mm)
Suggested Mounting Pad Dimensions
W
L
Case Sizes L, S and F
Case Size
0402 (1005)
A Min.
.0275
(0.70)
.0393
(1.00)
.0590
(1.50)
B Min.
.0354
(0.90)
.0433
(1.10)
.0512
(1.30)
C Min.
.0157
(0.40)
.0236
(0.60)
.0236
(0.60)
D Min.
.0866
(2.20)
.110
(2.80)
.1259
(3.20)
Inches (mm)
T
B
B
0603 (1608)
A
C
0805 (2012)
D
Design Kits
Each Kit contains a selection of standard capacitor values for circuit prototyping.
Kit #
Kit
36T
Item #
DK0036T
Description
600L Series Ultra-low ESR,
High Q Microwave Capacitors
16 different values, 15 pcs. min. per value
Cap. Value
Range (pF)
0.1 to 2.0
Cap. Values
(pF)
0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9,
1.0, 1.1, 1.2, 1.5
1.6, 1.8, 2.0
1.0, 1.2, 1.5, 1.8, 2.0, 2.2, 2.4, 2.7, 3.0, 3.3
Tol.
(pF)
±0.1
Price
$90.00
±0.25
±0.1
±0.25
±5%
Kit
37T
DK0037T
600L Series Ultra-low ESR,
High Q Microwave Capacitors
16 different values, 15 pcs. min. per value
1.0 to 10
3.9, 4.7, 5.6, 6.8, 8.2
10
$90.00
Kit
38T
DK0038T
600L Series Ultra-low ESR,
High Q Microwave Capacitors
8 different values, 15 pcs. min. per values
10 to 27
10, 12, 15, 18, 20, 22, 24, 27
±5%
$50.00
For Online Kit Orders, Catalog & Application Notes,
Visit: www.atceramics.com
Sales of ATC products are subject to the terms and conditions contained in American Technical Ceramics Corp. Terms and Conditions of Sale
(ATC document #001-992 Rev. B 12/05). Copies of these terms and conditions will be provided upon request. They may also be viewed on ATC's website at
www.atceramics.com/productfinder/default.asp. Click on the link for Terms and Conditions of Sale.
ATC has made every effort to have this information as accurate as possible. However, no responsibility is assumed by ATC for its use, nor for any infringements of rights of
third parties which may result from its use. ATC reserves the right to revise the content or modify its product without prior notice.
