2N3906
PNP General Purpose Transistors
* “G” Lead(Pb)-Free
TO-92
1. EMITTER
2. BASE
3. COLLECTOR
1
2
3
ABSOLUTE MAXIMUM RATINGS (Ta=25 C)
Rating
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base VOltage
Collector Current
Total Device Dissipation T
A
=25 C
Junction Temperature
Storage, Temperature
Symbol
VCEO
VCBO
VEBO
IC
PD
Tj
Tstg
Value
-40
-40
-5.0
-200
0.625
150
-55 to +150
Unit
Vdc
Vdc
Vdc
mAdc
W
C
C
ELECTRICAL CHARACTERISTICS
Characteristics
Collector-Emitter Breakdown Voltage (IC= 1.0 mAdc, IB=0)
Collector-Base Breakdown Voltage (IC= -100 uAdc, IE=0)
Emitter-Base Breakdown Voltage (IE= -100 uAdc, IC=0)
Collector Cutoff Current (VCE= -40 Vdc, I B =0)
Collector Cutoff Current (VCB= -40 Vdc, IE=0)
Emitter Cutoff Current (VEB= -5.0Vdc, I C =0)
Symbol
V(BR)CEO
V(BR)CBO
V(BR)EBO
ICE0
ICBO
IEBO
Min
-40
-40
-5.0
-
-
-
Max
-
-
-
-0.1
-0.1
-0.1
Unit
Vdc
Vdc
Vdc
uAdc
uAdc
uAdc
WEITRON
http://www.weitron.com.tw
2N3906
ELECTRICAL CHARACTERISTICS
(TA=25 C unless otherwise noted) (Countinued)
Characteristics
Symbol
Min
TYP
Max
Unit
ON CHARACTERISTICS
DC Current Gain
(IC= -10 mAdc, VCE=-1.0 Vdc)
DC Current Gain
(IC= -50 mAdc, VCE= 1.0 Vdc)
Collector-Emitter Saturation Voltage
(IC= -50 mAdc, IB= -5 mAdc)
Base-Emitter Saturation Voltage
(IC= -50 mAdc, IB= -5 mAdc)
Current-Gain-Bandwidth Product
(IC= 10 mAdc, VCE= 20 Vdc, f=100MHz)
hFE
(1)
hFE
(2)
VCE(sat)
VBE(sat)
fT
100
60
-
-
250
-
-
-
-
400
-
-0.3
-0.95
-
-
Vdc
Vdc
-
-
MHz
Classification of hFE(1)
Rank
Range
O
100-200
Y
200-300
G
300-400
WEITRON
http://www.weitron.com.tw
2N3906
WEITRON
http://www.weitron.com.tw
2N3906
TO-92 Outline Dimensions
E
unit:mm
TO-92
H
C
J
K
G
Dim
A
B
C
D
E
G
H
J
K
L
Min
Max
3.70
3.30
1.40
1.10
0.55
0.38
0.51
0.36
4.70
4.40
-
3.43
4.70
4.30
1.270TYP
2.44
2.64
14.10
14.50
B
L
WEITRON
http://www.weitron.com.tw
D
A
