Production specification
Schottky Barrier Rectifiers
Features
Metal silicon junction, majority carrier conduction
High surge capability
High temperature soldering guaranteed:
260°C/10 seconds
High current capability, low forward voltage drop
Guarding for over voltage protection
RoHS Compliant
Case: SOD-123FL molded plastic
MBRX120H--MBRX140H
Mechanical Data
Molding compound, UL flammability classification rating 94V-0
Terminals: Matte tin plated leads, solderable perJ-STD-002 and JESD22-B102
Polarity: Color band denotes cathode end
Maximum Ratings
(@T
A
= 25°C unless otherwise specified)
Characteristic
Peak repetitive reverse voltage
RMS reverse voltage
DC blocking voltage
Maximum average forward output current
Peak forward surge current,
8.3ms single half-sine-wave
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
MBRX120H
20
14
20
MBRX130H
30
21
30
1.0
30
MBRX140H
40
28
40
Units
V
V
V
A
A
Thermal Characteristics
Parameter
Typical thermal resistance
(Note 1)
Operating junction temperature range
Storage temperature range
Symbol
R
ΘJA
R
ΘJC
R
ΘJL
T
J
T
STG
MBRX120H
MBRX130H
85
23
15
- 55 ---- + 150
- 55 ---- + 150
°C
°C
°C /W
MBRX140H
Units
Note:
1. Device mounted on PCB with 10 mm x 20 mm x 0.1mm copper pad areas
SKP0006A
www.gmesemi.com
Production specification
Schottky Barrier Rectifiers
MBRX120H--MBRX140H
Electrical Characteristics
(@T
A
= 25°C unless otherwise specified)
Parameter
Maximum instantaneous
forward voltage(Note 1)
Maximum Reverse current
(Note 2)
I
R
Rated V
R
,
@T
J
=25°C
@T
J
=100°C
--
--
250
15
μ
A
mA
Symbol
V
F
Test
I
F
=1.0A
conditions
@T
A
=25°C
Typ.
--
Max.
0.55
Units
V
Note:
1.Pulse test: 300us pulse width, 1 % duty cycle
2.Pulse test: Pulse width 40ms
SKP0006A
www.gmesemi.com
Production specification
Schottky Barrier Rectifiers
Fig.1-Forward Current Derating Curve
I
FSM
,Peak Forward Surge Current (A)
1
Average Current (A)
0.8
0.6
0.4
0.2
0
0
25
50
75
100
125
150
MBRX120H--MBRX140H
Ratings and Characteristic Curves
(T
A
=25°C unless otherwise noted)
Fig.2- Surge Current Derating Curve
30
25
20
15
10
5
0
1
10
Number of Cycles at 60H
Z
100
Ambient Temperature (°C)
Fig.3- Typical Forward Voltage Characteristic
10
Forward Current I
F
(A)
Fig.4- Typical Reverse Characteristic
10000
Tj=25℃
Reverse Current ,I
R
(μ A)
Tj=125℃
1000
100
10
1
0.1
10
20
30
Tj=125℃
1
Tj
=
100
℃
Tj=75℃
Tj=75℃
Tj
=
100
℃
Tj=25℃
40
50
60
70
80
90 100
0.1
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Forward Voltage ,V
F
(V)
Reverse Voltage ,V
R
(%)
SKP0006A
www.gmesemi.com
