7100 Series
DIP Switches, Rocker Style Actuator
Single Pole
Single Throw
Contact Lead Spacing —
.100 x .300 [2.54 x 7.62]
Lead Length —
.140 [3.56]
below mounting surface
Contact Arrangement
A
A
.380
[9.65]
7100 Series
.290
[7.37]
.340
[8.64]
White Dot Identifies Pin 1
Pin 1
Note:
Switches shown in open position.
A
.380
[9.65]
Single Pole
Single Throw
Low Profile
Contact Lead Spacing —
.100 x .300 [2.54 x 7.62]
Lead Length —
.140 [3.56]
below mounting surface
Contact Arrangement
.290
[7.37]
.290
[7.37]
White Dot Identifies Pin 1
.100
± .005
Typ.
[2.54
± 0.13
]
.035
± .005
Dia. Typ.
[0.89
± 0.13
]
Pin 1
Note:
Switches shown in open position.
.300
± .005
[7.62
± 0.13
]
Recommended PC Board Hole Pattern
No. of
Switches
2
3
4
5
6
7
8
9
10
11
12
1
Dim. A
inch
mm
.280
.380
.480
.580
.680
.780
.880
.980
1.080
1.180
1.280
7.11
9.65
12.19
14.73
17.27
19.81
22.35
24.89
27.43
29.97
32.51
SPST Standard Profile
Unsealed
1
Sealed
Part No.
Part No.
2-435640-9
3-435640-0
435640-2
435640-3
435640-4
435640-1
435640-5
435640-6
435640-7
—
3-435640-2
—
—
3-435640-5
3-435640-6
3-435640-7
3-435640-8
3-435640-9
4-435640-0
4-435640-1
—
4-435640-3
SPST Low Profile
Unsealed
1
Tape Sealed
Part No.
Part No.
435668-1
—
435668-3
435668-4
435668-5
—
435668-7
—
435668-9
—
—
2-435668-6
3-435668-3
3-435668-4
3-435668-5
2-435668-5
2-435668-7
2-435668-8
2-435668-9
3-435668-0
3-435668-1
3-435668-2
All switches are bottom sealed.
A17
Catalog 1308390
Issued 9-04
www.tycoelectronics.com
Dimensions are in inches
and millimeters unless otherwise
specified. Values in parentheses
or brackets are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
