Data Sheet
25Amp HOOK Pressfit
Automotive Rectifiers
Mechanical Dimension
HPFR2501~2506 N/ P
DESCRIPTION
HOOK PRESS-FIT
Dimension in mm
Features
Low Cost
Super Cool
Long
life Features
High
Current
Capability
NOTE:
1.HPFR250XP
Positive (Forward), (+)
Cathode To Case,Color
Code Red
2.HPFR250XN
Negative(Reverse),(-):
Anode To Case,
Color Code Black
3.Lead 1.28mm
4. Case Copper and Brass Available pls note
Electrical Characteristics@25C
Average Forward Current, Io at Tc=150C
60HZ, Resistive Or Inductive Load
Peak Reverse Voltage, Repetitive:VRRM
DC Reverse Voltage, VR
Maximum RMS Voltage
Max. Inst Forward Voltage Drop. VF at
80Amp
Peak Forward Surge Current, IFM(surge):
8.3ms. Single Half Sine-Wave
Superimposed On Rated Load (JEDEC method)
Maximum Reverse Current IR At Rated DC
Reverse Voltage. TC= 25C
Maximum Reverse Current IR At Rated DC
Reverse Voltage. TC=100C
Maximum Thermal Resistance, Junction To Case
(single side cooled)
Operating And Storage Temperature Range
Symbol
IF
VRRM
V(DC)
VRMS
VF
IFSM
HPFR2501P HPFR2502P HPFR2504P HPFR2506P
Unit
HPFR2501N HPFR2502N HPFR2504N HPFR2506N
25
100
100
70
200
200
140
1.18
400
400
400
280
600
600
420
V
A
V(DC)
A(DC)
IR
IR
-
R
0JA
Tj; Tstrg
10
500
1.2
-65 to +175
uA
uA
C/W
C
Data Sheet
RATINGS AND CHARACTERISTIC CURVES HPFR2501 THRU HPFR2506
FIG.1 - FORWARD CURRENT DERATING CURVE
25
FIG.2 - MAXIMUM NON-REPETITIVE
PEAK FORWARD SURGE CURRENT
600
PEAK FORWARD SURGE CURRENT,
AMPERES
AVERAGE FORWARD RECTIFIED
CURRENT, AMPERES
Pulse Width 8.3ms
Single Half-Sire-Wave
(JEDEC Method)
20
500
400
15
300
10
200
05
60 Hz Resistive or
Inductive load
0
0
25
50
75
100
125
o
100
0
150
175
1
10
100
CASE TEMPERATURE, C
NUMBER OF CYCLES AT 60Hz
FIG.3 - TYPICAL INSTANTANEOUS
FORWARD CHARACTERISTICS
IINSTANTANEOUS FORWARD CURRENT,
AMPERES
1000
FIG.4 - TYPICAL REVERSE CHARACTERISTICS
1000
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
T
J
=175 C
100
o
100
10
1
10
0.1
T
J
=25 C
o
1
0.2
0.4
0.6
0.8
T
J
=25 C
PULSE WIDTH=300uS
1% DUTY CYCLE
1.0
1.2
1.4
1.6
o
0.01
0
20
40
60
80
100
INSTANTANEOUS FORWARD VOLTAGE,
VOLTS
PERCENT OF RATED PEAK REVERSE VOLTAGE,%
HPFR2501~2506P/N
20Amp HOOK Press-fit
Automotive Rectifiers
