PT3304N: DescriptionSwitching Regulator, SIP-19; CategoryPower/power management The power supply circuit; File Size505KB，2 Pages; ManufacturerPower Trends Inc

Download Datasheet Parametric Compare View All

PT3304N Overview

Switching Regulator, SIP-19

PT3304N Parametric

Parameter Name	Attribute value
Maker	Power Trends Inc
package instruction	SIP-19
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR
Maximum input voltage	60 V
Minimum input voltage	20 V
Nominal input voltage	24 V
JESD-30 code	R-XSMA-T19
Number of functions	1
Number of terminals	19
Maximum operating temperature	65 °C
Minimum operating temperature	-20 °C
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Certification status	Not Qualified
surface mount	NO
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal location	SINGLE

Preview

Download Datasheet

View All

PT3304N Related Products

	PT3304N	PT3301A	PT3303A	PT3303N	PT3304C	PT3302C	PT3304A	PT3302A	PT3303C
Description	Switching Regulator, SIP-19	Switching Regulator, SIP-19	Switching Regulator, SIP-19	Switching Regulator, SIP-19	Switching Regulator, SIP-19	Switching Regulator, SIP-19	Switching Regulator, SIP-19	Switching Regulator, SIP-19	Switching Regulator, SIP-19
Maker	Power Trends Inc	Power Trends Inc	Power Trends Inc	Power Trends Inc	Power Trends Inc	Power Trends Inc	Power Trends Inc	Power Trends Inc	Power Trends Inc
package instruction	SIP-19	SIP-19	SIP-19	SIP-19	SIP-19	SIP-19	SIP-19	SIP-19	SIP-19
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR	SWITCHING REGULATOR
Maximum input voltage	60 V	60 V	60 V	60 V	60 V	60 V	60 V	60 V	60 V
Minimum input voltage	20 V	20 V	20 V	20 V	20 V	20 V	20 V	20 V	20 V
Nominal input voltage	24 V	24 V	24 V	24 V	24 V	24 V	24 V	24 V	24 V
JESD-30 code	R-XSMA-T19	R-XSMA-T19	R-XSMA-T19	R-XSMA-T19	R-XSMA-G19	R-XSMA-G19	R-XSMA-T19	R-XSMA-T19	R-XSMA-G19
Number of functions	1	1	1	1	1	1	1	1	1
Number of terminals	19	19	19	19	19	19	19	19	19
Maximum operating temperature	65 °C	65 °C	65 °C	65 °C	65 °C	65 °C	65 °C	65 °C	65 °C
Minimum operating temperature	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C	-20 °C
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY	MICROELECTRONIC ASSEMBLY
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	NO	NO	NO	YES	YES	NO	NO	YES
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	GULL WING	GULL WING	THROUGH-HOLE	THROUGH-HOLE	GULL WING
Terminal location	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
