BURNDY
Compression
TYPE YS-L
HYLINK™ SPLICE
STANDARD BARREL
COPPER COMPRESSION
UL Listed 90° C,
600 Volts to 35 KV
◆
C-93
Features and Benefits
• Standard barrel length.
◊
Ideal for limited space applications while
providing ample barrel length for proper
crimp.
• Four (4) center conductor stops.
◊
Provides a center wire stop for proper
conductor insertion.
CONDUCTOR
CATALOG
NUMBER
YS8C-L-BOX
YS6C-L BOX
YS5C-L BOX
YS4C-L BOX
YS3C-L
YS2C-L BOX
YS1C-L BOX
YS25-L BOX
YS26-L BOX
YS27-L BOX
YS28-L BOX
YS29-L BOX
YS30-L
YS31-L
YS32-L
YS34-L
YS36-L
YS38-L
YS39-L
YS44-L
***
MM
2
10
––
16
––
25
––
50
––
70
95
––
120
150
185
––
240
300
––
––
500
DIMENSION
MECHANICAL
AWG
8 str.
6 str.
5 str.
4 str.
3 str.
2 str.
1 str.
1/0 str.
2/0 str.
3/0 str.
4/0 str.
250 kcmil
300 kcmil
350 kcmil
400 kcmil
500 kcmil
600 kcmil
700 kcmil
750 kcmil
1000 kcmil
L
1.24
1.75
1.90
1.93
2.05
2.07
2.06
2.08
2.17
2.30
2.32
2.46
2.47
2.60
2.74
3.15
3.22
3.22
3.72
4.28
B
.44
.81
.81
.81
.88
.88
.88
.88
.94
1.00
1.00
1.06
1.06
1.12
1.19
1.38
1.38
1.38
1.62
1.88
Y1MRTC
Y2MR
Y2MR (1)
Y1MRTC (1)
Y2MR (1)
Y1MRTC (1)
Y2MR (2)
Y1MRTC (2)
Y1MRTC (2)
Y2MR (2)
Y1MRTC (2)
Y1MRTC (2)
––
––
––
––
––
––
––
––
––
––
––
––
––
MD7-34R
W8CVT (1)
W5CVT (1)
W4CVT (1)
––
W2CVT (1)
W1CVT (1)
W25VT (2)
W26VT (2)
W27VT (2)
W28VT (2)
W29VT (2)
W30VT (2)
W31VT (2)
W32VT (2)
W34VT (2)
––
––
––
––
MD6
OUR840
X8CRT (1)
X5CRT (1)
X4CRT (1)
––
X2CRT (1)
X1CRT (1)
X25RT (2)
X26RT (2)
X27RT (2)
X28RT (2)
––
––
––
––
––
––
––
––
––
INSTALLATION TOOLING
▲
Y35,
■
Y39, Y750, Y46*
DIE NUMBER
(# CRIMPS)
U8CRT (1)
UCRT (1)
U4CRT (1)
U3CRT (1)
U2CRT (1)
U1CRT-1 (1)
U25RT (1)
U26RT (1)
U27RT (1)
U28RT (1)
U29RT (1)
U30RT (2)
U31RT (2)
U32RT (2)
U34RT (2)
U36RT (2)
U38RT (2)
U39RT (2)
P44RT** (2)
COLOR
CODE
RED
BLUE
GRAY
WHITE
BROWN
GREEN
PINK
BLACK
ORANGE
PURPLE
YELLOW
WHITE
RED
BLUE
BROWN
GREEN
PINK
BLACK
WHITE
▲
DIE INDEX
& EMBOSSMENT
49
7 or 374
8 or 346
9
10
11 or 375
12 or 348
13
14
15
16
17 or 298
18 or 324
19 or 470
20 or 299
22 or 472
400
24
27
WIRE
STRIP
LENGTH
1/2"
7/8"
7/8"
15/16"
15/16"
15/16"
15/16"
1"
1-1/16"
1-1/16"
1-1/8"
1-1/8"
1-3/16"
1-1/4"
1-7/16"
1-7/16"
1-7/16"
1-11/16"
1-15/16"
▲
See tooling section of this catalog for complete tool and die
listings.
* Use PUADP-1 adapter with "U" dies in Y46 HYPRESS™.
** P44RT for use with Y46 HYPRESS™ only. PUADP-1
adaptor not required.
*** The MM
2
conductor sizes listed are the recommendations
for Class 2 conductor.
■
The maximum size for the Y35 is 400 kcmil insulated code
cable.
■
For applications greater than 2000 Volts consult cable
manufacturer for voltage stress relief instuctions.
