PE4545 Overview

SMA Female Right Angle Bulkhead Connector Solder Attachment Thru Hole PCB, .235 inch D Hole

Preview

Download Datasheet

View All

SMA Female Right Angle Bulkhead Connector Solder

Attachment Thru Hole PCB, .235 inch D Hole

TECHNICAL DATA SHEET

Configuration

Connector

Connector Specification

Connector Interface Type

Cable Attachment Method (Shield/Contact)

Body Style

Mount Method

SMA Female

MIL-STD-348A

Thru Hole

Solder

Right Angle

Bulkhead

PE4545

SMA Female Right Angle Bulkhead Connector Solder Attachment Thru Hole PCB, .235 inch D Hole

Electrical Specifications

Frequency Range, GHz

Impedance, Ohms

Maximum VSWR

Maximum Operating Voltage, Volts

Dielectric Withstanding Voltage, Vrms

DC to 12.4

1.23:1

500

1,000

Mechanical Specifications

Temperature

Operating Range, deg C

Size

Length, in [mm]

Width/Dia., in [mm]

Height, in [mm]

Weight, lbs [g]

Connector

Type

Contact Material and Plating

Contact Plating Specification

Body Material and Plating

Body Plating Specification

Dielectric Type

-65 to +165

0.799 [20.29]

0.25 [6]

0.53 [13.46]

0.013 [5.9]

SMA Female

Brass/Beryllium Copper, Gold

50µ in. minimum

Brass, Gold

3µ in. minimum

Teflon

Compliance Certifications

(visit www.Pasternack.com for current document)

RoHS Compliant

Yes

Plotted and Other Data

Notes:

Values at 25 °C, sea level

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications:

SMA Female Right Angle Bulkhead Connector Solder Attachment Thru Hole PCB, .235 inch D

Hole PE4545

PE4545 REV
