The Max value of Input Voltage/Output Voltage is not over 6.5V.
When the pulse width is 50ns or less, the Min value of Input
Voltage/Output Voltage is not lower than -0.8V.
Junction temperature at the storage condition
Caution:
Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated over
the absolute maximum ratings.
Memory Cell Characteristics
(Ta=25ºC, V
CC
=1.6V to 5.5V)
Parameter
Write Cycles
(Note1)
Data Retention
(Note1)
(Note1) Not 100% TESTED
Limit
Min
Typ
1,000,000
-
40
-
Max
-
-
Unit
Times
Years
Recommended Operating Ratings
Parameter
Power Source Voltage
Input Voltage
Symbol
V
CC
V
IN
Rating
1.6 to 5.5
0 to V
CC
Unit
V
DC Characteristics
(Unless otherwise specified, Ta=-40ºC to +85ºC, V
CC
=1.6V to 5.5V)
Parameter
Input High Voltage1
Input Low Voltage1
Input High Voltage2
Input Low Voltage2
Output Low Voltage1
Output Low Voltage2
Input Leakage Current
Output Leakage Current
Supply Current (Write)
Supply Current (Read)
Standby Current
Symbol
V
IH1
V
IL1
V
IH2
V
IL2
V
OL1
V
OL2
I
LI
I
LO
I
CC1
I
CC2
I
SB
Limit
Min
0.7V
CC
-0.3
(Note2)
0.8V
CC
-0.3
(Note2)
-
-
-1
-1
-
-
-
Typ
-
-
-
-
-
-
-
-
-
-
-
Max
V
CC
+1.0
+0.3V
CC
V
CC
+1.0
+0.2V
CC
0.4
0.2
+1
+1
2.0
0.5
2.0
Unit
V
V
V
V
V
V
µA
µA
mA
mA
µA
1.7V≤V
CC
≤5.5V
1.7V≤V
CC
≤5.5V
1.6V≤V
CC
＜1.7V
1.6V≤V
CC
＜1.7V
I
OL
=3.0mA, 2.5V≤V
CC
≤5.5V
(SDA)
I
OL
=0.7mA, 1.6V≤V
CC
＜2.5V
(SDA)
V
IN
=0 to V
CC
V
OUT
=0 to V
CC
(SDA)
V
CC
=5.5V, f
SCL
=400kHz, t
WR
=5ms,
Byte write, Page write
V
CC
=5.5V, f
SCL
=400kHz
Random read, current read, sequential read
V
CC
=5.5V, SDA・SCL=V
CC
A0, A1, A2=GND, WP=GND
Conditions
(Note2) When the pulse width is 50ns or less, it is -0.8V.
