DTM9435_13 Overview

P-Channel 30-V (D-S) MOSFET Halogen-free

Preview

Download Datasheet

View All

P-Channel 30-V (D-S) MOSFET

www.din-tek.jp

DTM9435

PRODUCT SUMMARY

(V)

- 30

DS(on)

(Ω)

0.042 at V

= - 10 V

0.055 at V

= - 6 V

0.060 at V

= - 4.5 V

(A)

- 5.8

- 5.0

- 4.4

FEATURES

•

Halogen-free According to IEC 61249-2-21

Definition

• TrenchFET

Power MOSFET

• Compliant to RoHS Directive 2002/95/EC

SO-8

Top View

P-Channel MOSFET

ABSOLUTE MAXIMUM RATINGS

= 25 °C, unless otherwise noted

Parameter

Drain-Source Voltage

Gate-Source Voltage

Continuous Drain Current (T

= 150 °C)

Pulsed Drain Current

Continuous Source Current (Diode Conduction)

Maximum Power Dissipation

Operating Junction and Storage Temperature Range

= 25 °C

= 70 °C

= 25 °C

= 70 °C

Symbol

, T

stg

- 2.3

2.5

1.6

- 55 to 150

- 5.8

- 4.6

- 30

- 1.1

1.3

0.8

°C

10 s

- 30

± 20

- 4.1

- 3.2

Steady State

Unit

THERMAL RESISTANCE RATINGS

Parameter

Maximum Junction-to-Ambient

Maximum Junction-to-Foot (Drain)

Notes:

a. Surface Mounted on 1" x 1" FR4 board.

≤

10 s

Steady State

Symbol

thJA

thJF

Typical

Maximum

°C/W

Unit
