DTC143 TM/TE/TUA/TCA/TSA
NPN Small Signal Transistor
Small Signal Diode
Features
Built-in bias resistors enable the configuration of an inverter
circuit without connecting external input resistor
(see equivalent circuit).
The bias resistors consist of thin -film resistors with
complete isolation to allow negative biasing of the input.
They also have the advantage of almost completely
eliminating parasitic effects.
Only the on/off conditions need to be set for
operation,marking device design easy.
Green compound (Halogen free) with suffix "G" on
packing code and prefix "G" on date code.
Ordering Information
Package
SOT-723
SOT-523
SOT-323
SOT-23
TO-92S
Part No.
DTC143 TM
DTC143 TE
DTC143 TUA
DTC143 TCA
DTC143 TSA
Packing
8K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
Marking
03
03
03
03
Maximum Ratings and Electrical Characteristics
Rating at 25°C ambient temperature unless otherwise specified.
Value
TUA TCA
200
50
50
5
100
-55 to + 150
Type Number
Power Dissipation
Collector-Emitter Voltage
Emitter-Base Voltage
Emitter-base voltage
Collector Current
Junction and Storage Temperature Range
Symbol
PD
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
C
TJ, T
STG
TM
100
TE
150
TSA
300
Units
mW
V
V
V
mA
°C
Notes:1. Valid provided that electrodes are kept at ambient temperature
Parameter
Collector-base breakdown voltage
Collector-emitter breakdown voltage
Emitter-base breakdown voltage
Collector cut-off current
Emitter cut-off current
DC Current Gain
Input Resistance
Resistance Ratio
Transition Frequency
Symbol
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
V
CE(sat)
h
FE
R
1
f
T
Min
50
50
5
Typ
Max
Condtion
Ic=50µA
Ic=1mA
I
E
=50µA
Unit
V
V
V
μA
μA
V
KΩ
0.5
0.5
0.3
100
3.29
4.7
250
600
6.11
V
CB
=50V
V
EB
=4V
I
C
=5mA,I
B
=0.25mA
V
CE
=5V,I
C
=1mA
V
CE
=10V,I
E
=5mA, f=100MHz
MHz
Version:A12
