ZXT11N15DFTA

Description
Small Signal Bipolar Transistor, 3A I(C), 15V V(BR)CEO, 1-Element, NPN, Silicon, SOT-23, 3 PIN
CategoryDiscrete semiconductor    The transistor
File Size414KB,6 Pages
ManufacturerDiodes Incorporated
Environmental Compliance
Download Datasheet Parametric View All

ZXT11N15DFTA Online Shopping

Suppliers Part Number Price MOQ In stock
ZXT11N15DFTA - - View Buy Now

ZXT11N15DFTA Overview

Small Signal Bipolar Transistor, 3A I(C), 15V V(BR)CEO, 1-Element, NPN, Silicon, SOT-23, 3 PIN

ZXT11N15DFTA Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerDiodes Incorporated
Parts packaging codeSOT-23
package instructionSMALL OUTLINE, R-PDSO-G3
Contacts3
Reach Compliance Codecompliant
ECCN codeEAR99
Factory Lead Time15 weeks
Maximum collector current (IC)3 A
Collector-emitter maximum voltage15 V
ConfigurationSINGLE
Minimum DC current gain (hFE)150
JESD-30 codeR-PDSO-G3
JESD-609 codee3
Humidity sensitivity level1
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
Polarity/channel typeNPN
Maximum power dissipation(Abs)0.806 W
Certification statusNot Qualified
surface mountYES
Terminal surfaceMatte Tin (Sn) - annealed
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperature40
transistor applicationsSWITCHING
Transistor component materialsSILICON
Nominal transition frequency (fT)145 MHz
ZXT11N15DF
SuperSOT4™
15V NPN SILICON LOW SATURATION TRANSISTOR
SUMMARY
V
CEO
=15V; R
SAT
= 37m ; I
C
= 3A
DESCRIPTION
This new 4th generation ultra low saturation transistor utilises the Zetex
matrix structure combined with advanced assembly techniques to give
extremely low on state losses. This makes it ideal for high efficiency, low
voltage switching applications.
FEATURES
Extremely Low Equivalent On Resistance
Extremely Low Saturation Voltage
h
FE
characterised up to 5A
I
C
=3A Continuous Collector Current
SOT23 package
SOT23
APPLICATIONS
DC - DC Converters
Power Management Functions
Power switches
Motor control
E
C
B
REEL SIZE
(inches)
7
13
TAPE WIDTH
(mm)
8mm embossed
8mm embossed
QUANTITY
PER REEL
3000 units
10000 units
Top View
ORDERING INFORMATION
DEVICE
ZXT11N15DFTA
ZXT11N15DFTC
DEVICE MARKING
1N5
ISSUE 1 - DECEMBER 1999
1
