STANDARD COMMON MODE INDUCTORS - SURFACE MOUNT
CMF3SM
CMF3SMLF
*
Wirewound
PART
NUMBER
CMF3-2502SM
CMF3-5002SM
CMF3-1003SM
CMF3-1503SM
CMF3-2003SM
CMF3-3003SM
CMF3-4503SM
CMF3-6503SM
CMF3-1004SM
CMF3-1504SM
CMF3-2504SM
TRADITIONAL
Pb
COMPLIANT
RoHS
L µH
@ 1 kHZ
25
50
100
150
200
300
450
650
1000
1500
2500
DCR
OHMS
MAX
0.010
0.010
0.012
0.012
0.014
0.018
0.022
0.025
0.045
0.080
0.150
CURRENT
RATING
A DC
8.5
8.5
7.7
7.7
7.2
6.3
5.7
5.3
4.0
3.0
2.2
LEAKAGE
L µH
REF
0.4
0.7
1.4
1.7
2.0
3.0
4.8
6.0
9.3
14.5
24.0
All part numbers provide 25% tolerance on inductance
Custom designs are available to meet your specific requirements; please contact factory
*Add “LF” suffix for RoHS requirement. Example: CMF3-2502SMLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
TOP VIEW
DOT TO
INDICATE
PIN 1
1
4
GOWANDA
GOWANDA
CMF3
CMF3
-XXXXSM
-XXXXSM
2
1.058±0.015
(26.87±0.38)
SIDE VIEW
0.250 (6.35) MAX
3
0.423
(10.74)
MAX
0.250
(6.35)MAX
0.87±0.010
(22.10±0.254)
TOP VIEW
DOT TO
INDICATE
PIN 1
1
4
GOWANDA
GOWANDA
CMF3
CMF3
-XXXXSM
-XXXXSM
2
1.058±0.015
(26.87±0.38)
SIDE VIEW
0.250 (6.35) MAX
3
0.423
(10.74)
MAX
0.250
(6.35)MAX
0.87±0.010
(22.10±0.254)
RECOMMENDED FOOT PRINT
1
4
1.063
0.187
0.250
1.063
2
3
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 50°C temperature
rise at an ambient temperature of 75°C
Note: Current is rated in both windings
• Dielectric Withstanding Voltage (DWV) is 1250
Vrms
• Excellent electromagnetic shielding
• Leakage inductance is tested at pins 1-2 with
pins 3-4 shorted or at pins 3-4 with pins 1-2
shorted
• Inductance and DCR is for each side or single
winding
• Windings balanced within 2%
• Applications include reduction of AC line
interference produced by switching power
supplies (the opposing magnetic fluxes in
the core serve to cancel in-phase noise
signals appearing across the AC line) and
noise suppression of DC circuits for switching
regulators
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
190
32 mm
44 mm
13 in.
RECOMMENDED FOOT PRINT
1
4
in. (mm)
1.063
0.187
0.250
1.063
2
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
