PLUGGABLE
PRINTED CIRCUIT
Metric Pin Spacing
a
Tubular Screw Clamp Plug
For plug-in applications where infrequent
wire-to-board connections are made and
a very cost effective pluggable terminal
block is needed.
Multipole assemblies are offered in
modular interlocking design up to 12
poles or single mold construction up to
16 poles. While modular construction
reduces and simplifies inventory, the
single mold design provides maximum
strength.
•
•
•
•
Modular or Single Mold Design
Wire Protector Standard
Housing Material: Polyamide 6.6
Standard Color: Gray
a
AK130
Modular Plug
Pole Spacing 5mm (.197)
Stripping Length 6mm (.236)
Screw Hole Diameter 3.5mm (.138)
Use with STL130, STL132, STL140 Headers
Wire Range
0.5-1.5mm
2
22-14 AWG
22-14 AWG
Current
10A
10A
10A
Cat. No.
30.302
30.303
30.304
30.305
30.306
30.307
30.308
30.309
30.310
30.311
30.312
Length L
mm (in.)
10.00
15.00
20.00
25.00
30.00
35.00
40.00
45.00
50.00
55.00
60.00
( .39)
( .59)
( .79)
( .99)
(1.18)
(1.38)
(1.58)
(1.77)
(1.97)
(2.17)
(2.36)
Voltage
250V
300V
300V
Std. Pk.
100
100
50
50
50
30
30
30
30
20
20
AK132
Single Mold Plug
Pole Spacing 5mm (.197)
Stripping Length 6mm (.236)
Screw Hole Diameter 3.5mm (.138)
Use with STL130, STL132, STL140 Headers
Wire Range
0.5-1.5mm
2
22-14 AWG
22-14 AWG
Type
AK132/2wp
AK132/3wp
AK132/4wp
AK132/5wp
AK132/6wp
AK132/7wp
AK132/8wp
AK132/9wp
AK132/10wp
AK132/11wp
AK132/12wp
AK132/13wp
AK132/14wp
AK132/15wp
AK132/16wp
Current
10A
10A
10A
Cat. No.
30.322
30.323
30.324
30.325
30.326
30.327
30.328
30.329
30.330
30.331
30.332
30.333
30.334
30.335
30.336
Length L
mm (in.)
10.00
15.00
20.00
25.00
30.00
35.00
40.00
45.00
50.00
55.00
60.00
65.00
70.00
( .39)
( .59)
( .79)
( .99)
(1.18)
(1.38)
(1.58)
(1.77)
(1.97)
(2.17)
(2.36)
(2.56)
(2.76)
Voltage
250V
300V
300V
Std. Pk.
100
100
50
50
50
30
30
30
30
20
20
20
20
20
15
Blocks with US (Inch) pin spacing
begin on page 110.
Ratings
IEC/VDE
(File No. E101811)
(File No. LR68503)
Ordering Information
Plug, mm Pole Spacing
No. of
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Type
AK130/2wp
AK130/3wp
AK130/4wp
AK130/5wp
AK130/6wp
AK130/7wp
AK130/8wp
AK130/9wp
AK130/10wp
AK130/11wp
AK130/12wp
75.00 (2.95)
80.00 (3.15)
L
0.7mm
L
®
13.5mm
®
®
13.5mm
®
Dimensions
mm
0.70
2.70
5.00
in.
0.028
0.106
0.197
mm
9.30
10.80
13.50
in.
0.366
0.425
0.531
2.7mm
5mm
10.8mm
5mm
®
9.3mm
2.7mm
®
10.8mm
®
9.3mm
®
STL(Z)130
STL(Z)132
STL(Z)130
STL(Z)132
144
Altech Corp.
®
• 35 Royal Road • Flemington NJ 08822-6000 • Phone (908) 806-9400 • Fax (908) 806-9490
