ZAPD-21-N+: DescriptionCombiner, 500MHz Min, 2000MHz Max, 1dB Insertion Loss-Max, ROHS COMPLIANT, CASE F14; CategoryWireless rf/communication Radio frequency and microwave; File Size129KB，1 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com; Environmental Compliance

Download Datasheet Parametric Compare View All

ZAPD-21-N+ Overview

Combiner, 500MHz Min, 2000MHz Max, 1dB Insertion Loss-Max, ROHS COMPLIANT, CASE F14

ZAPD-21-N+ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mini-Circuits
package instruction	ROHS COMPLIANT, CASE F14
Reach Compliance Code	not_compliant
ECCN code	EAR99
Other features	N, ISOLATION-MIN (DB):18
Characteristic impedance	50 Ω
structure	COAXIAL
Maximum input power (CW)	40 dBm
Maximum insertion loss	1 dB
Maximum operating frequency	2000 MHz
Minimum operating frequency	500 MHz
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
RF/Microwave Device Types	COMBINER
Maximum voltage standing wave ratio	1.31

Preview

Download Datasheet

View All

Power Splitter/Combiner

2 Way-0°

Maximum Ratings

Operating Temperature

Storage Temperature

Power Input (as a splitter)

Internal Dissipation

-55°C to 100°C

10W max.

0.125W max.

Coaxial

ZAPD-21+

ZAPD-21

50Ω

500 to 2000 MHz

Features

• wideband, 500 to 2000 MHz

• low insertion loss, 0.25 dB typ.

• good isolation, 25 dB typ.

• up to 10W power input as splitter

• excellent amplitude unbalance, 0.1 dB typ.

• excellent phase unbalance, 1 deg. typ.

• excellent VSWR, 1.20:1 typ.

• rugged shielded case

N-Type version shown

Connectors

BNC

SMA

N-TYPE

CASE STYLE: F14

Model

Price

ZAPD-21(+)

$59.95

ZAPD-21-S(+)

$64.95

ZAPD-21-N(+)

$64.95

Qty.

(1-9)

Coaxial Connections

SUMPORT

PORT 1

PORT 2

S

1

2

Applications

• UHF

• GPS

• cellular

• PCS/DCS

FREQ.

RANGE

(MHz)

f

L

-f

U

500-2000

+ RoHS compliant in accordance

with EU Directive (2002/95/EC)

The +Sufﬁx identiﬁes RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualiﬁcations.

• communications systems

• instrumentation

Splitter Electrical Speciﬁcations

ISOLATION

(dB)

INSERTION LOSS (dB)

ABOVE 3.0 dB

PHASE

UNBALANCE

(Degrees)

Max.

3

Outline Drawing

AMPLITUDE

UNBALANCE

(dB)

Max.

0.2

Typ. Min

25

18

Typ. Max.

0.25

1.0

Typical Performance Data

Frequency

(MHz)

Insertion Loss

(dB)

S-1

500.00

525.00

575.00

625.00

675.00

3.17

3.18

3.12

3.14

3.08

3.22

3.18

3.21

3.17

3.19

3.23

3.35

3.33

3.31

Amplitude

Unbalance

(dB)

0.03

0.02

0.03

0.04

0.03

0.02

0.04

0.03

0.01

Isolation

(dB)

Phase

Unbalance

(deg.)

0.45

0.48

0.50

0.53

0.60

0.61

0.73

0.77

0.68

0.92

1.15

1.27

1.41

1.42

1.48

VSWR

S

VSWR

1

VSWR

2

S-2

3.14

3.15

3.10

3.12

3.11

3.05

3.19

3.15

3.17

3.14

3.17

3.19

3.31

3.30

3.29

21.12

22.44

25.62

29.70

33.67

30.96

27.43

25.73

25.37

30.28

29.13

24.08

27.44

35.87

33.59

1.31

1.27

1.18

1.10

1.03

1.08

1.17

1.24

1.29

1.21

1.03

1.16

1.22

1.19

1.15

ZAPD-21

ISOLATION

1.16

1.13

1.07

1.02

1.04

1.11

1.17

1.21

1.23

1.15

1.01

1.10

1.16

1.18

1.17

1.14

1.08

1.03

1.02

1.09

1.15

1.19

1.22

1.16

1.03

1.08

1.15

1.17

1.18

Outline Dimensions (

inch

)

mm

A

2.00

50.80

H

.39

9.91

B

2.00

50.80

J

1.00

25.40

C

.75

19.05

K

.50

12.70

D

1.00

25.40

L

1.00

25.40

E

.25

6.35

F

1.500

38.10

G

.125

3.18

wt

grams

170.0

750.00

825.00

900.00

1000.00

1200.00

1400.00

1600.00

1800.00

1900.00

2000.00

ZAPD-21

INSERTION LOSS

3.5

INSERTION LOSS (dB)

S-1(dB)

S-2(dB)

45

ISOLATION (dB)

40

35

30

25

20

500

3.4

3.3

3.2

3.1

3.0

500

800

1100

1400

1700

2000

800

1100

1400

1700

2000

FREQUENCY (MHz)

ZAPD-21

VSWR

1.5

#S-VSWR

#1-VSWR

#2-VSWR

electrical schematic

1.4

VSWR

1.3

1.2

1.1

1.0

500

800

1100

1400

1700

2000

FREQUENCY (MHz)

Distribution Centers

NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010

Mini-Circuits

®

INTERNET

http://www.minicircuits.com

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661

REV. A

M98898

ZAPD-21

HY/TD/CP

060828

Mini-Circuits

ISO 9001 & ISO 14001

Certified
