Coaxial
Power Splitter/Combiner
3 Way-0°
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
ZA3PD-1+
ZA3PD-1
50Ω
-55°C to 100°C
-55°C to 100°C
10W max.
0.375W max.
500 to 1000 MHz
Features
• wideband, 500 to 1000 MHz
• up to 10W power input as splitter
• low insertion loss, 0.3 dB typ.
• rugged, shielded case
SMA version shown
Maximum Ratings
CASE STYLE: CC51
Connectors Model
SMA
ZA3PD-1-S(+)
N-TYPE
ZA3PD-1-N(+)
Price
$89.95
$89.95
Qty.
(1-9)
(1-9)
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
PORT 3
S
1
2
3
Applications
• UHF
• cellular
• communication system
• instrumentation
FREQ.
RANGE
(MHz)
f
L
-f
U
500-1000
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
Electrical Specifications
ISOLATION
(dB)
Typ.
20
Min.
14
INSERTION LOSS (dB)
ABOVE 4.8 dB
Typ.
0.3
Max.
0.6
AMPLITUDE
UNBALANCE
(dB)
Max.
0.4
Outline Drawing
Typical Performance Data
Freq.
(MHz)
S-1
500.00
525.00
550.00
587.50
625.00
662.50
700.00
737.50
775.00
812.50
850.00
900.00
937.50
962.50
1000.00
4.93
4.94
4.95
4.90
4.92
4.92
4.94
5.07
4.96
5.10
5.05
5.15
5.12
5.02
5.09
Total Loss
(dB)
S-2
4.93
4.93
4.92
4.87
4.89
4.88
4.89
5.00
4.86
5.02
4.92
5.02
4.97
4.83
4.90
ZA3PD-1
TOTAL LOSS
1
Amp.
Unbal.
(dB)
S-3
4.93
4.92
4.93
4.89
4.90
4.92
4.93
5.06
4.97
5.12
5.06
5.19
5.16
5.06
5.13
0.00
0.02
0.03
0.03
0.04
0.04
0.05
0.07
0.11
0.10
0.13
0.16
0.19
0.23
0.23
Isolation
(dB)
1-2
25.07
27.33
30.22
36.77
41.08
34.04
30.02
27.72
26.26
25.41
24.90
24.96
25.24
25.47
26.05
Phase VSWR VSWR VSWR VSWR
S
1
2
3
Unbal.
(deg.)
2-3
25.67
28.26
31.79
42.63
40.30
32.18
28.45
26.26
24.77
23.87
23.19
22.94
22.90
22.85
23.01
0.50
0.25
0.40
0.43
0.30
0.41
0.34
0.22
0.29
0.41
0.05
0.53
0.27
0.41
0.69
1.31
1.27
1.20
1.07
1.03
1.07
1.14
1.16
1.25
1.29
1.27
1.36
1.28
1.31
1.34
1.14
1.11
1.11
1.04
1.06
1.04
1.07
1.10
1.07
1.14
1.11
1.14
1.13
1.08
1.13
1.12
1.08
1.08
1.06
1.04
1.07
1.12
1.12
1.14
1.20
1.15
1.23
1.18
1.16
1.22
1.14
1.11
1.11
1.04
1.05
1.03
1.06
1.09
1.07
1.13
1.11
1.14
1.13
1.09
1.13
1-3
21.42
22.75
24.28
27.06
30.93
36.85
41.73
35.61
31.53
29.00
27.30
26.09
25.53
25.28
25.22
Outline Dimensions (
inch
)
mm
A
2.00
50.80
G
.125
3.18
B
2.00
50.80
H
.38
9.65
C
.75
19.05
J
1.00
25.40
D
.938
23.83
K
1.25
31.75
E
.13
3.30
F
1.750
44.45
wt
grams
200.0
1. Total Loss = Insertion Loss + 4.8dB splitter loss.
ZA3PD-1
ISOLATION
1-2 (dB)
1-3 (dB)
2-3 (dB)
5.5
S-1(dB)
TOTAL LOSS (dB)
5.3
5.1
4.9
4.7
4.5
500
S-2(dB)
S-3(dB)
60
ISOLATION (dB)
52
44
36
28
20
500
600
700
800
900
1000
600
700
800
900
1000
FREQUENCY (MHz)
FREQUENCY (MHz)
1.5
1.4
VSWR
1.3
1.2
1.1
1.0
500
ZA3PD-1
VSWR
#S-VSWR
#1-VSWR
electrical schematic
600
700
800
900
1000
FREQUENCY (MHz)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. B
M139182
ZA3PD-1
HY/TD/CP/AM
121023
