ASMC-QxB2-Txxxx
Envisium
TM
0.5W Power PLCC-4
Surface Mount LED Indicator
Data Sheet
Envisium
TM
Envisium
TM
is the premier class of mid-Power LEDs using
TS AlInGaP chip technology. Envisium
TM
LEDs offer unpar-
alleled performance, engineering and design flexibility.
Features
x
Industry Standard PLCC 4 platform (3.2 x 2.8 x 1.9mm)
x
High reliability LED package
x
Mid-Power intensity brightness with optimum flux
performance using TS AllnGaP chip technologies
x
Available in Red Orange and Amber colors
x
High optical efficiency
x
Available in 8mm carrier tape and 7 inch reel
x
Low Thermal Resistance
x
Super wide viewing angle at 120q
x
Longer life time with minimum degradation due to
enhanced silicone resin material
x
JEDEC MSL 2a
Description
The Envisium
TM
0.5W Power PLCC-4 SMT LED is an
extension of Envisium
TM
Power PLCC-4 SMT LEDs. The
package can be driven at high current due to its superior
package design. The product is able to dissipate the heat
more efficiently compared to the Envisium
TM
Power PLCC-
4 SMT LEDs. These LEDs produce higher light output with
better flux performance compared to the Envisium
TM
Power PLCC-4 SMT LED.
The Envisium
TM
0.5W Power PLCC-4 SMT LEDs are
designed for higher reliability, better performance, and
operate under a wide range of environmental conditions.
The performance characteristics of these new mid-power
LEDs make them uniquely suitable for use in harsh condi-
tions such as in automotive applications, and in electron-
ics signs and signals.
To facilitate easy pick and place assembly, the LEDs are
packed in EIA-compliant tape and reel. Every reel is
shipped in single intensity and color bin (except for red),
to provide close uniformity. These LEDs are compatible
with the IR solder reflow process.
Envisium
TM
0.5W Power PLCC-4 SMT LED is available in
red orange & amber colors.
Applications
1. Exterior automotive
- Turn signals
- Side repeaters
- CHSML
- Rear combination lamp
- Side markers
- Truck clearance lamp
2. Electronic signs and signals
- Channel lettering
- Contour lighting
- Indoor variable message sign
3. Office automation, home appliances, industrial
equipment
- Front panel backlighting
- Push button backlighting
- Display backlighting
1
Component Dimensions
0.79 ± 0.3
2.8 ± 0.2
2.2 ± 0.2
A
A
1.9 ± 0.2
0.6 ± 0.3
1.15 ± 0.2
3.6
± 0.2
3.2
± 0.2
I
2.4
0.97
C
CATHODE
MARKING
C
0.7
Note:
1. All Dimensions in millimeters.
2. Lead Polarity as shown in Figure 12.
3. Terminal Finish: Ag plating
4. Encapsulation material: Silicone resin
Figure 1. Package Drawing
Table 1. Device Selection Guide (T
J
= 25 °C)
Luminous Flux,
I
V [1]
(lm)
Color
Amber
Red Orange
Notes:
1.
I
V
is the total luminous flux output as measured with an integrating sphere at mono pulse conditions.
2. Tolerance = ±12%
Part Number
ASMC-QAB2-TAC0E
ASMC-QHB2-TCD0E
Min. Flux (lm)
4.30
7.00
Typ. Flux (lm)
6.60
9.30
Max. Flux (lm)
9.00
11.50
0.56 (TYP.)
0.41 (TYP.)
Test Current (mA)
150
150
Dice Technology
AlInGaP
AlInGaP
Part Numbering System
A S M C
-
Q
X
1
B 2
- T X
2
X
3
X
4
X
5
Packaging
Option
Color Bin Selection
Max.
Flux
Bin
Min.
Flux
Bin
Color
A - Amber
H - Red Orange
2
Table 2. Absolute Maximum Ratings (T
A
= 25
qC)
Parameters
DC Forward Current
[1]
Peak Forward Current
[2]
Power Dissipation
Reverse Voltage
Junction Temperature
Operating Temperature
Storage Temperature
Notes:
1. Derate Linearly as shown in Figure 6.
2. Duty Factor = 10%, Frequency = 1kHz
ASMC-QxB2-Txxxx
150 mA
300 mA
470 mW
5V
125 °C
-40 °C to +100 °C
-40 °C to +100 °C
Table 3. Optical Characteristics (T
J
= 25
qC)
Dominant
Wavelength
O
D [1]
(nm)
Typ.
593.5
619.3
Color
Amber
Red Orange
Part
Number
ASMC-QAB2-Txxxx
ASMC-QHB2-Txxxx
Dice
Technology
AlInGaP
AlInGaP
Viewing Angle
2T
½ [2]
(Degrees)
Typ.
120
120
Luminous
Efficiency
K
e
(lm/W)
Typ.
17
24
Total Flux /
Luminous Intensity
F
V
(lm) / I
V
(cd)
Typ.
6.5
5.0
Notes:
1. The dominant wavelength,
O
D
, is derived from the CIE Chromaticity diagram and represents the color of the device.
2.
T½
is the off-axis angle where the luminous intensity is ½ the peak intensity.
Table 4. Electrical Characteristics (T
J
= 25
qC)
Forward Voltage
V
F
(Volts) @ I
F
= 150 mA
Part Number
ASMC-QxB2-Txxxx
Reverse Voltage
V
R
@ 100PA
Min.
5
Typ.
2.64
Max.
3.10
Thermal Resistance
RT
J-P
(°C/W)
60
3
1.0
0.9
0.8
RELATIVE
INTENSITY
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
380
430
480
530
580
630
WAVELENGTH
-
nm
680
730
780
50
0
0
1
2
3
FORWARD
VOLTAGE
-
V
4
5
AlInGaP Amber
AlInGaP Red
Orange
FORWARD
CURRENT
-
mA
350
300
250
AlInGaP Red
Orange
200
150
100
AlInGaP Amber
Figure 2. Relative Intensity Vs. Wavelength
Figure
3.
Forward Current Vs. Forward Voltage
1.2
RELATIVE LUMINOUS
INTENSITY
(NORMALIZATION AT
150
mA)
1.0
0.8
0.6
0.4
0.2
0
0
RELATIVE LUMINOUS
INTENSITY
(NORMALIZATION AT 25°C)
1.6
1.4
1.2
1
0.8
0.6
0.4
0.2
20
40
60
80
100
120
DC
FORWARD
CURRENT
-
mA
140
160
0
-50
-25
0
25
50
75
JUNCTION
TEMPERATURE -
°C
100
125
Figure
4.
Relative Intensity Vs. Forward Current
Figure
5.
Relative Intensity Vs. Temperature
160
Rθ
JA
= 100°C/W
MAXIMUM
FORWARD
CURRENT
-
mA
120
100
80
60
40
20
0
0
20
40
60
80
AMBIENT
TEMPERATURE
(°C)
100
120
Rθ
JA
= 110°C/W
Rθ
JA
= 130°C/W
MAXIMUM
FORWARD
CURRENT
-
mA
140
160
140
120
100
80
60
40
20
0
0
20
40
60
80
SOLDER POINT
TEMPERATURE
(°C)
100
120
Rθ
JP
=
60°C/W
Figure 6a. Maximum Forward Current Vs. Ambient Temperature.
Derated Based on T
JMAX
= 125°C, RT
J-A
=130 °C/W, 110°C/W and 100°C/W
Figure 6b. Maximum Forward Current Vs. Solder Point Temperature.
Derated Based on T
JMAX
= 125°C, RT
JP
= 60°C/W
4
