LAMINATED TRANSFORMERS
Type EI30 / 15.5
- 2.0VA
AGENCY
APPROVALS
1.
UL 506, File E113449
3.
EN61558
V
DE
Primary
(V)
230
230
230
230
230
230
230
230
230
230
230
230
115
115
115
115
115
115
115
115
115
115
Secondary
(V / mA)
6 / 333
9 / 222
12 / 166
15 / 133
18 / 111
24 / 83
2x6 / 166
2x9 / 111
2x12 / 83
2x15 / 66
2x18 / 55
2x24 / 42
6 / 333
9 / 222
12 / 166
15 / 133
18 / 111
24 / 83
2x6 / 166
2x9 / 111
2x12 / 83
2x15 / 66
2x18 / 55
2x24 / 42
6 / 333
9 / 222
12 / 166
15 / 133
18 / 111
24 / 83
2x6 / 166
2x9 / 111
2x12 / 83
2x15 / 66
2x18 / 55
2x24 / 42
No-Load Schematic
Voltage
(V)
No.
10.50
14.60
20.00
26.00
29.60
37.20
2x8.70
2x14.60
2x19.45
2x24.10
2x29.10
2x36.50
10.50
14.60
20.00
26.00
29.60
37.20
2x8.70
2x14.60
2x19.45
2x24.10
2x29.10
2x36.50
10.50
14.60
20.00
26.00
29.60
37.20
2x8.70
2x14.60
2x19.45
2x24.10
2x29.10
2x36.50
1
1
1
1
1
1
2
2
2
2
2
2
1
1
1
1
1
1
2
2
2
2
2
2
3
3
3
3
3
3
4
4
4
4
4
4
Part
Number
030-7304.0
030-7305.0
030-7306.0
030-7307.0
030-7308.0
030-7309.0
030-7310.0
030-7311.0
030-7312.0
030-7313.0
030-7314.0
030-7315.0
030-7292.0
030-7293.0
030-7294.0
030-7295.0
030-7296.0
030-7297.0
030-7298.0
030-7299.0
030-7300.0
030-7301.0
030-7302.0
030-7303.0
030-6429.0
030-6432.0
030-6435.0
030-6438.0
030-6441.0
030-6447.0
030-6452.0
030-6455.0
030-6458.0
030-6461.0
030-6464.0
030-6470.0
Agency
Approvals
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1
1
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1
1
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1/3*
1
1
Frequency 50/60Hz
Potted under vacuum
Split-bobbin
Temperature class ta 70°C/B
VDE rated as inherently
short-circuit proof
Weight: 0.10kg
Packaging unit: 25 pieces (tube)
Mechanical
32,5
(1.28)
27
(1.06)
3,5
(0.138)
115
115
2x115
2x115
2x115
2x115
2x115
20
(0.80)
6
27,5
(1.08)
7
8
9
10
2x115
2x115
2x115
2x115
2x115
2x115
2x115
5
4
3
2
1
Pin Ø 0,8 mm
(Pin DIA. 0.031)
4x5
(4 x 0.20)
Schematics
No. 1
5
7
No. 2
5
6
7
9
1
9
1
10
*NOTE:
When checking the approval status of this product with VDE, add the prefix
"BV" and the suffix "S" to the orderable Part Number (these letters will also be found
on the part label).
The prefix and suffix are not part of the orderable Part Number.
No. 3
5
4
2
1
9
7
No. 4
5
4
2
1
6
7
9
10
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 769 85538070
•
Taiwan 886 3 4641811
www.pulseeng.com
9
LT2007 (1/08)
