Z16FMC32AG20SG: DescriptionMicrocontroller, 16-Bit, FLASH, 20MHz, CMOS, PQFP64, LEAD FREE, LQFP-64; CategoryThe embedded processor and controller Microcontrollers and processors; File Size2MB，352 Pages; ManufacturerIXYS; Environmental Compliance

Download Datasheet Parametric Compare View All

Z16FMC32AG20SG Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	Z16FMC32AG20SG	-	-	View	Buy Now

Z16FMC32AG20SG Overview

Microcontroller, 16-Bit, FLASH, 20MHz, CMOS, PQFP64, LEAD FREE, LQFP-64

Z16FMC32AG20SG Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	IXYS
Parts packaging code	QFP
package instruction	LEAD FREE, LQFP-64
Contacts	64
Reach Compliance Code	compliant
Has ADC	YES
Address bus width
bit size	16
maximum clock frequency	20 MHz
DAC channel	NO
DMA channel	YES
External data bus width
JESD-30 code	S-PQFP-G64
length	10 mm
Number of I/O lines	46
Number of terminals	64
Maximum operating temperature	70 °C
Minimum operating temperature
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Encapsulate equivalent code	QFP64,.47SQ,20
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH
power supply	3/3.3 V
Certification status	Not Qualified
RAM (bytes)	4096
rom(word)	32768
ROM programmability	FLASH
Maximum seat height	1.6 mm
speed	20 MHz
Maximum slew rate	35 mA
Maximum supply voltage	3.6 V
Minimum supply voltage	2.7 V
Nominal supply voltage	3 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
width	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

Motor Control MCUs

Z16FMC Series

Product Specification

PS028704-0513

PRELIMINARY

www.zilog.com

Z16FMC Series Motor Control MCUs

Product Specification

Table of Contents

Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii

List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv

List of Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ZNEO CPU Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Flash Z16FMC Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Random Access Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Motor Control Peripherals Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-Bit Analog-to-Digital Converter with Programmable Gain Amplifier . . . . . .

Analog Comparator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Operational Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General-Purpose Input/Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Universal Asynchronous Receiver/Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . .

Infrared Encoder/Decoders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Inter-Integrated Circuit Master/Slave Controller . . . . . . . . . . . . . . . . . . . . . . . . .

Enhanced Serial Peripheral Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DMA Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Pulse Width Modulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Standard Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Interrupt Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Crystal Oscillator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Reset Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

On-Chip Debugger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Signal and Pin Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Pin Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Signal Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Pin Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Address Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Internal Nonvolatile Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Internal RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Input/Output Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PS028704-0513

PRELIMINARY

Table of Contents

Z16FMC Series Motor Control MCUs

Product Specification

Input/Output Memory Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ZNEO CPU Control Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Endianness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Bus Widths . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Peripheral Address Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Reset and Stop-Mode Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Reset Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

System Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power-On Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Voltage Brown-Out Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Watchdog Timer Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Pin Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Reset Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

User Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Fault Detect Logic Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Stop-Mode Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Stop-Mode Recovery Using WDT time-out . . . . . . . . . . . . . . . . . . . . . . . . . . .

Stop-Mode Recovery Using a GPIO Port Pin Transition . . . . . . . . . . . . . . . . . .

Reset Status and Control Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Low-Power Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

STOP Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HALT Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Peripheral-Level Power Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Control Option Bit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General-Purpose Input/Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GPIO Port Availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GPIO Alternate Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GPIO Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GPIO Control Register Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Port A–H Input Data Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Port A–H Output Data Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Port A–H Data Direction Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Port A–H High Drive Enable Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Port A–H Alternate Function High and Low Registers . . . . . . . . . . . . . . . . . . .

Port A–H Output Control Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Port A–H Pull-Up Enable Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PS028704-0513

PRELIMINARY

Table of Contents

Z16FMC32AG20SG Related Products

	Z16FMC32AG20SG	Z16FMC28AG20EG	Z16FMC64AG20SG
Description	Microcontroller, 16-Bit, FLASH, 20MHz, CMOS, PQFP64, LEAD FREE, LQFP-64	Microcontroller, 16-Bit, FLASH, 20MHz, CMOS, PQFP64, LEAD FREE, LQFP-64	Microcontroller, 16-Bit, FLASH, 20MHz, CMOS, PQFP64, LEAD FREE, LQFP-64
Is it Rohs certified?	conform to	conform to	conform to
Maker	IXYS	IXYS	IXYS
Parts packaging code	QFP	QFP	QFP
package instruction	LEAD FREE, LQFP-64	LEAD FREE, LQFP-64	LEAD FREE, LQFP-64
Contacts	64	64	64
Reach Compliance Code	compliant	compliant	compliant
Has ADC	YES	YES	YES
bit size	16	16	16
maximum clock frequency	20 MHz	20 MHz	20 MHz
DAC channel	NO	NO	NO
DMA channel	YES	YES	YES
JESD-30 code	S-PQFP-G64	S-PQFP-G64	S-PQFP-G64
length	10 mm	10 mm	10 mm
Number of I/O lines	46	46	46
Number of terminals	64	64	64
Maximum operating temperature	70 °C	105 °C	70 °C
PWM channel	YES	YES	YES
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LFQFP	LFQFP	LFQFP
Encapsulate equivalent code	QFP64,.47SQ,20	QFP64,.47SQ,20	QFP64,.47SQ,20
Package shape	SQUARE	SQUARE	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK, LOW PROFILE, FINE PITCH
power supply	3/3.3 V	3/3.3 V	3/3.3 V
Certification status	Not Qualified	Not Qualified	Not Qualified
RAM (bytes)	4096	4096	4096
rom(word)	32768	131072	65536
ROM programmability	FLASH	FLASH	FLASH
Maximum seat height	1.6 mm	1.6 mm	1.6 mm
speed	20 MHz	20 MHz	20 MHz
Maximum slew rate	35 mA	35 mA	35 mA
Maximum supply voltage	3.6 V	3.6 V	3.6 V
Minimum supply voltage	2.7 V	2.7 V	2.7 V
Nominal supply voltage	3 V	3 V	3 V
surface mount	YES	YES	YES
technology	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	INDUSTRIAL	COMMERCIAL
Terminal form	GULL WING	GULL WING	GULL WING
Terminal pitch	0.5 mm	0.5 mm	0.5 mm
Terminal location	QUAD	QUAD	QUAD
width	10 mm	10 mm	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER
