www.teltron.com
Model
TMS100
X-Band Motion Sensor
Features
TMS100 is X-band Doppler motion sensor to detect
motion. It consists of DR(dielectric resonator)
oscillator, passive diode and patch antennas
and provides most reliable solution in motion
detection.
Applications
Intrusion alarm
Automatic door
Obstruction alarm system
Velocity measurement
Automatic light control-energy saving
System air-conditioner-zone control
Antenna beam pattern
E-axis
H-axis
E-axis
H-axis
Electrical Specifications
Parameters
Frequency
Output Power (EIRP)
Power Supply
Current Consumption
Settling time
CW
Noise
Received Signal
3dB Antenna Beam Width - E-axis
3dB Antenna Beam Width - H-axis
Operating temp.
Storage temp.
Size
Pulse
Operation
Pulse Width
Duty Cycle
Average Current
5
1
2
@5% duty
-20
-30
45 x 40 x 10
81
36
+55
+70
4.75
30
5
Min.
Typ.
10,525±12.5
15
5.25
60
6
10
20
3~80 Hz
max
CW
Max.
Unit
Condition
Over Temp.
Warning : The specifications can be changed without any notice.
202 ITplex 26-41 Gajeongbuk-ro, Yuseong-gu, Daejeon 305-343 Korea
TEL : +82-42-360-2000 FAX : +82-360-2010 e-mail : teltron@teltron.com
Model
TMS100
www.teltron.com
X-Band Motion Sensor
Dimension
Pin Description
#
1
2
3
4
Pin Name
VDD
IF
GND
GND
Explanation
Power, +5V
Output
Ground
Ground
Side view
Front view
(mm)
Application Circuit Example
Block Diagram
TMS100
Tx
Rx
Osc.
Mixer
IF
Warning : To avoid a fatal damage, it should be carefully handled
and installed under ESD protection condition.
202 ITplex 26-41 Gajeongbuk-ro, Yuseong-gu, Daejeon 305-343 Korea
TEL : +82-42-360-2000 FAX : +82-360-2010 e-mail : teltron@teltron.com
