6 dB Fixed Attenuator, N Female To 7/16 DIN Male
Directional Rated To 100 Watts Up To 6 GHz
TECHNICAL DATA SHEET
PE7202-6
6 dB Fixed Attenuator, N Female To 7/16 DIN Male Directional Rated To 100 Watts Up To 6 GHz
Pasternack Enterprises line of 100W Attenuators operate from DC to 6 GHz, and are available in 42 different 7/16 DIN,
N, SMA and TNC in-series and between-series connector combinations. Our 100W Attenuators are manufactured with
Passivated Stainless Steel SMA, TNC and N connectors, and Silver Plated Brass 7/16 DIN connectors. Pasternack
100W Attenuators come in 3 dB, 6 dB, 10 dB, 20 dB, 30 dB, 40 dB, 60 dB values and will operate from -55 to +125
degrees C. Additional connector combinations are available beyond the 42 standard designs, upon request.
•
100W average power and 2,000W peak power handling capability
•
Operate to 6 GHz
•
Temperature range of -55 to +125 degrees C
•
42 in-series and between series combinations
•
7/16 DIN, SMA, N, TNC Male and Female connectors are available
•
Other connector combinations available upon request
Configuration
Design
Connector 1
Connector 2
Body Material and Plating
Fixed, Directional Attenuator
N Female
7/16 DIN Male
Aluminum Heatsink, Black Anodized
Electrical Specifications
Frequency Range, GHz
Impedance, Ohms
Attenuation Value, dB
Maximum Input Power, Watts
Maximum VSWR
Frequency 1
Range, GHz
VSWR
Attenuation Accuracy, dB
Frequency 2
Range, GHz
VSWR
Attenuation Accuracy, dB
Frequency 3
Range, GHz
VSWR
Attenuation Accuracy, dB
DC to 6
50
6
100
1.45:1
DC to 2
1.2:1
± 0.75
2 to 4
1.35:1
± 0.75
4 to 6
1.45:1
±1
Mechanical Specifications
Temperature
Operating Range, deg C
-55 to +125
Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications:
6 dB Fixed Attenuator, N Female To 7/16 DIN Male Directional Rated To 100 Watts Up To
6 GHz PE7202-6
PE7202-6 REV NC
1
6 dB Fixed Attenuator, N Female To 7/16 DIN Male
Directional Rated To 100 Watts Up To 6 GHz
TECHNICAL DATA SHEET
Size
Length, in [mm]
Width, in [mm]
Height, in [mm]
.
PE7202-6
4.9 [124.46]
3.8 [96.52]
2.7 [68.58]
3 [1.36]
Weight, lbs [Kg]
Connector 1
Type
Contact Material and Plating
Body Material and Plating
N Female
Beryllium Copper, Gold
Stainless Steel, Passivated
Connector 2
Type
Contact Material and Plating
Coupling Nut Material and Plating
Body Material and Plating
7/16 DIN Male
Brass, Silver
Brass, Silver
Brass, Silver
Compliance Certifications
(visit www.Pasternack.com for current document)
RoHS Compliant
Yes
Plotted and Other Data
Notes:
Values at 25 °C, sea level
URL:
http://www.pasternack.com/6db-fixed-n-female-7-16-male-100-watts-attenuator-pe7202-6-p.aspx
6 dB Fixed Attenuator, N Female To 7/16 DIN Male Directional Rated To 100 Watts Up To 6 GHz from Pasternack Enterprises
has same day shipment for domestic and International orders. Our RF, microwave and fiber optic products maintain a 99%
availability and are part of the broadest selection in the industry.
