Major League Electronics .100" cl Shrouded Terminal Strip Header
Ordering Information
SHTSHC-1
XX
- D -
XX
-
XXX
-
XX
-
XX
-
XXX
- LF
Pins Per Row
03 - 32
Lead Free
Double
Pin Option
Max. Tail Length
Select nearest Pin
Option greater than
specified 'Desired
Tail Length'
(2.54) .100
(2.92) .115
(3.20) .126
(3.81) .150
(5.08) .200
(7.62) .300
(10.16) .400
(12.70) .500
(15.24) .600
(17.78) .700
(20.32) .800
(22.86) .900
(25.40) 1.000
(27.94) 1.100
(30.48) 1.200
08 = standard option
Pin Length
(10.92) .430
(11.30) .445
(11.58) .456
(12.19) .480
(13.46) .530
(16.00) .630
(18.54) .730
(21.08) .830
(23.62) .930
(26.16) 1.030
(28.70) 1.130
(31.24) 1.230
(33.78) 1.330
(36.32) 1.430
(38.86) 1.530
06
08
10
11
14
16
20
22
24
26
28
30
32
34
36
Polarized Position
001 - 064
Leave blank if not needed
Lock Tight "LT" (Optional)
LT = With
Leave blank if not needed
Two tails per strip are crimped in opposing directions on or near the centerline.
Must have a minimum dimension of .050". Recommended hole size of .040".
Desired Tail length
Please specify
e.g. .100 (2.54) = 100
Mates with:
IDS-1
Insulator:
Plating Options
- 10µ Gold on Contact area/Flash on Tail
G
GT
- 10µ Gold on Contact Area/Matte Tin on Tail
- Matte Tin all Over
T
- Gold Flash Over Entire Pin
F
Polyester UL 94V-0 Nylon-6T
Contact:
Copper Alloy
Insulation resistance: 1000 MOHMS min.
Contact Resistance:
20 mOHMS max.
Current Rating:
Dielectric Withstanding:
Operating Temperature:
3 Amps
600V AC
-40°C to +105°C
Products cut to specific sizes are uncancellable/nonreturnable
Parts are subject to change without notice
SHTSHC-1 SERIES
.100" cl Shrouded Terminal Strip Header
Custom
19 APR 07
4235 Earnings Way, New Albany, Indiana, 47150, USA
1-800-782-3486 (USA/Canada/Mexico)
Tel: 812-944-7244
Fax: 812-944-7268
E-mail: mle@mlelectronics.com
Web: www.mlelectronics.com
