ULE-12/5-D48NML2-C Overview

DC-DC Regulated Power Supply Module

ULE-12/5-D48NML2-C Parametric

Parameter NameAttribute value
MakerMurata
package instruction,
Reach Compliance Codecompliant
ECCN codeEAR99
Analog Integrated Circuits - Other TypesDC-DC REGULATED POWER SUPPLY MODULE

ULE-12/5-D48NML2-C Preview

www.murata-ps.com
ULT Series
Thirty-Second-Brick Isolated DC/DC Converters
with 2:1 Wide Input Range
FEATURES

Input Voltage Range (36V – 75V, 48 Volts,
2:1
nominal)

to 30W output power @ 36 – 48 – 75Vin
Up

efficiency (typical, 5Vout)
89%

Through-hole and optional SMT package

Miniature 1/32 brick open frame package

Positive & Negative Logic On/Off control option

Over-current & Over-temperature protection

output ripple and noise
Low

Strong thermal derating characteristics

Operational Temperature Range –40°C to +85°C

1500V I/O isolation

line/load regulation
Tight

ed to UL/EN/IEC 60950-1, CAN/CSA C22.2
Certifi
No. 60950-1, safety approvals, 2nd Edition
Typical units
PRODUCT OVERVIEW
The ULT Series isolated DC/DC converter repre-
sents the next generation converters in a 1/32
brick package. This converter is the “industry-
standard” 1/32 brick form factor (0.92" x 0.75"
x 0.35"). The product fully complies with RoHS-6
directive.
The thirty-second brick is offered as an open
frame module; mounting options include through-
hole or surface mount (SMT) pinouts. Typical
applications include Optical Networking Equipment,
Wireless Base Station applications, Microwave
Radio communications, and Telecom and Data
Equipment applications.
Modules will supply an output power of up to
30 watts over the input range of 36-75V. The ULT
Series also provides a cost effective approach to
highly efficient systems requiring 12V, 5V, and 3.3V
voltages, eliminating the requirement for a “Bus
Converter” and multiple PoL converters. The ULT
family provides basic insulation with 1500Vdc iso-
lation meeting the requirements of EN60950. The
ULT series modules are DOSA compatible industry
standard 1/32 brick.
F1
+Vin (1)
Barrier
+Vout (8)
External
DC
Power
Source
On/Off
Control
(2)
Controller
and Power
Open = On
Reference and
Error Amplifier
Trim (6)
polarity)
-Vin (3)
-Vout (4)
Figure 1. Connection Diagram
Typical topology is shown. Murata Power
Solutions recommends an external fuse.

For full details go to
www.murata-ps.com/rohs
REG.-Nr. D216
(pending)
www.murata-ps.com/support
MDC_ULT Series.D01
Page 1 of 26
ULT Series
Thirty-Second-Brick Isolated DC/DC Converters
with 2:1 Wide Input Range
PERFORMANCE SPECIFICATIONS SUMMARY AND ORDERING GUIDE
Output
Root Model
ULT-3.3/7.5-D48
ULT-5/5-D48
ULT-12/2.5-D48
V
OUT
(V)
3.3
5
12
I
OUT
Power
(A, max.)
(W)
7.5
5
2.5
24.75
25
30
R/N (mV pk-pk)
Regulation (max.)
V
IN
Nom.
(V)
Typ.
Max.
Line
Load
45
50
70
50
75
120
±0.15%
±0.1%
±0.1%
±0.15%
±0.125%
±0.2%
48
48
48
Input
Range I
IN
, no load
(V)
(mA)
36-75
36-75
36-75
20
20
20
I
IN
, full
load (A)
0.6
0.59
0.68
Efficiency
Min.
84%
87%
90%
Typ.
85.5%
89%
92%
Package
Case (inches)
0.92x0.75x0.35
0.92x0.75x0.35
0.92x.075x0.35
Please refer to the Part Number Structure when ordering.
All specifications are typical at nominal line voltage and full load, +25°C unless
otherwise noted. See detailed specifications. External input capacitors are
33μF electrolytic and three 1μF ceramic. Output ripple is measured with 400μF
capacitance across output pins for the 3.3Vout and 5Vout model. The 12Vout model
is measured with 188μF. Output caps are necessary for our test equipment and may
not be needed for your application.
Regulation specifications describe output voltage deviations from a nominal/midpoint
value to either extreme (50% load step).
PART NUMBER STRUCTURE
ULT
-
3.3
/
7.5
-
D48 N M Lx
-
C
Thirty-second-brick series (Unipolar)
RoHS Hazardous Substance Compliance
(does not claim EU RoHS exemption 7b–lead in solder)
C = RoHS-6
Pin Length Option (Thru-hole only)
Blank = Standard pin length 0.190˝ (4.8mm)
L1 = 0.110˝ (2.79mm)
*
L2 = 0.145˝ (3.68mm)
*
SMT Version Option
Blank = Through-hole mount, no SMT
M = Surface mount (MSL Rating 1)
On/Off Control Logic Option
N = Negative
P = Positive
Nominal Output Voltage
Maximum Rated Output Current
Current in Amps
Input Voltage Range
D48 = 36-75 Volts (48V nominal)
*Minimum
order quantity is
required. Samples available
with standard pin length only.
Note:
Some model number combinations may
not be available. See website or contact
your local Murata sales representative.
www.murata-ps.com/support
MDC_ULT Series.D01
Page 2 of 26
ULT Series
Thirty-Second-Brick Isolated DC/DC Converters
with 2:1 Wide Input Range
FUNCTIONAL SPECIFICATIONS (ULT-3.3/7.5-D48-C)
ABSOLUTE MAXIMUM RATINGS
Conditions
Minimum
Typical/Nominal
Maximum
Units
Input Voltage, Continuous
Input Voltage, Transient
15
Isolation Voltage
1500
Vdc
Input Reverse Polarity
none
Vdc
On/Off Remote Control
5
Vdc
Output Power
25
W
Output Current
Current-limited, no damage, short-circuit protected
7.5
A
Storage Temperature Range
Vin = Zero (no power)
-40
125
°C
Absolute maximums are stress ratings. Exposure of devices to greater than any of these conditions may adversely affect long-term reliability. Proper operation under conditions other than those
listed in the Performance/Functional Specifications Table is not implied or recommended.
INPUT
Conditions
➀ ➂
Full temperature range
Operating or non-operating, 100 mS max.
duration
Input to output tested
None, install external fuse
Power on or off, referred to -Vin
36
80
100
Vdc
Vdc
Operating voltage range
Recommended External Fuse
13
Start-up threshold
Undervoltage lockout (@ ½ load)
11
Turn-On/Turn-Off Hysteresis
Overvoltage shutdown
Reverse Polarity Protection
Internal Filter Type
Input current
Full Load Current Conditions
Low Line Input Currrent
Inrush Transient
Short Circuit input current
No Load input current
Shut-Down Mode input current (Off, UV, OT)
Reflected (back) ripple current
GENERAL and SAFETY
36
Fast blow
Rising input voltage
Falling input voltage
Rising input voltage
None, install external fuse
32.5
31
1.22
48
2
33.3
32.5
1.3
N/A
None
Capacitive
0.6
0.8
0.05
0.04
20
6
30
75
34.5
34
1.32
Vdc
A
Vdc
Vdc
Vdc
Vdc
Vdc
Vin = nominal
Vin = minimum
Vin = 48V
Iout = minimum, unit=ON
Measured at input with specified filter
Vin=48V
Vin=36V
84
83.5
0.62
0.83
0.1
40
10
A
A
A2-Sec.
mA
mA
mA
mA, pk-pk
%
%
Vdc
pF
Efficiency
Isolation
Isolation Voltage, Input to Output
Insulation Safety Rating
Isolation Resistance
Isolation Capacitance
Safety
(certified to the following requirements)
Calculated MTBF
DYNAMIC CHARACTERISTICS
85.5
85.5
1500
basic
10
1700
UL-60950-1, CSA-C22.2 No.60950-1,
IEC/EN60950-1, 2nd edition (pending)
Per Telcordia SR332, issue 1, class 3, ground
fixed, Tambient=+25°C
250
Power On, to Vout regulation band, 100%
Remote ON to Vout Regulated
50-75-50% load step to 1% of Vout
same as above
Yes
TBD
285
5
5
75
±100
320
10
10
150
Hours x 10
3
KHz
mS
mS
μSec
mV
Fixed Switching Frequency
Startup Time
Startup Time
Dynamic Load Response
Dynamic Load Peak Deviation
FEATURES and OPTIONS
Remote On/Off Control
"N" suffix
Negative Logic, ON state
Negative Logic, OFF state
Control Current
"P" suffix
Positive Logic, ON state
Positive Logic, OFF state
Control Current
ON = pin grounded or external voltage
OFF = pin open or external voltage
open collector/drain
ON = pin open or external voltage
OFF = ground pin or external voltage
open collector/drain
-0.7
2.4
<1
2.4
-0.7
<1
0.8
5
Vdc
Vdc
mA
V
V
mA
5
0.8
www.murata-ps.com/support
MDC_ULT Series.D01
Page 3 of 26
ULT Series
Thirty-Second-Brick Isolated DC/DC Converters
with 2:1 Wide Input Range
FUNCTIONAL SPECIFICATIONS (ULT-3.3/7.5-D48-C, CONT.)
OUTPUT
Conditions
Minimum
Typical/Nominal
Maximum
Units
Total Output Power
Voltage
Nominal Output Voltage
Setting Accuracy
Output Trim Range
Overvoltage Protection
Current
Output Current Range
Minimum Load
Current Limit Inception
Short Circuit
Short Circuit Current
Short Circuit Duration (remove short for
recovery)
Short circuit protection method
Regulation
Line Regulation
Load Regulation
Ripple and Noise
12
Temperature Coefficient
Maximum Capacitive Loading
Remote Sense Compliance
MECHANICAL (Through Hole Models)
0
3.2505
-1.5
-20
3.9
0
no minimal load required
98% of Vnom., after warmup
Hiccup technique, autorecovery within ±1.25%
of Vout
Output shorted to ground, no damage
Hiccup current limiting
Vin=min. to max., Vout=nom., full load
Iout=min. to max., Vin=nom.
Tested with eight 47μF ceramic caps in parallel
At all outputs
Low ESR
Vsense = Vout - Vload, sense connected at load
Conditions
➀ ➂
24.75
3.3
25
3.35
1.5
10
4.6
7.5
12.25
0.3
W
Vdc
Vdc
% of Vout
Vdc
A
A
A
At 50% load
User selectable (see trim formulas)
7.5
10.6
8.8
Continuous
Non-latching
±0.15
±0.15
50
5,000
10
Typical/Nominal
Maximum
45
0.02
400
Minimum
% of Vout
% of Vout
mV pk-pk
% of Vout./°C
μF
% of Vout
Units
Outline Dimensions
(Please refer to outline drawing)
Weight
Through Hole Pin Diameter
Through Hole Pin Material
TH Pin Plating Metal and Thickness
ENVIRONMENTAL
LxWxH
Nickel subplate
Gold overplate
See derating curves
Vin = Zero (no power)
External filter is required
-40
-55
120
0.92 x 0.75 x 0.35
23.4x19.05x8.89
0.32
9.07
.04 & .062
1.02 & 1.57
Brass
50
3-5
85
125
140
B
RoHS-6
Inches
mm
Ounces
Grams
Inches
mm
μ-inches
μ-inches
°C
°C
°C
Class
Operating Ambient Temperature Range
Storage Temperature
Thermal Protection/Shutdown
Electromagnetic Interference
Conducted, EN55022/CISPR22
RoHS rating
130
www.murata-ps.com/support
MDC_ULT Series.D01
Page 4 of 26
ULT Series
Thirty-Second-Brick Isolated DC/DC Converters
with 2:1 Wide Input Range
Performance Specification Notes
All specifications are typical unless noted. Ambient temperature =
+25°Celsius, V
IN
is nominal, output current is maximum rated nominal.
External output capacitance consists of 400μF capacitors across output
pins; one 33μF low ESR, and three 1μF external input capacitors. All caps
are low ESR.
Testing must be kept short enough that the converter does not appreciably
heat up during testing. For extended testing, use plenty of airflow. See
derating curves for temperature performance. All models are stable and
regulate within spec without external cacacitance.
Input Ripple Current is tested and specified over a 5-20 MHz bandwidth
and uses a special set of external filters only for the Ripple Current speci-
fications. Input filtering is C
IN
= 33 μF, C
BUS
= 220 μF, L
BUS
= 12 μH. Use
capacitor rated voltages which are twice the maximum expected voltage.
Capacitors must accept high speed AC switching currents.
Note that Maximum Current Derating Curves indicate an average current
at nominal input voltage. At higher temperatures and/or lower airflow, the
converter will tolerate brief full current outputs if the average RMS current
over time does not exceed the Derating curve. All Derating curves are
presented at sea level altitude. Be aware of reduced power dissipation
with increasing density altitude.
Mean Time Before Failure (MTBF) is calculated using the Telcordia (Bel-
core) SR-332 Method 1, Case 3, Issue 1, ground fixed conditions. Operat-
ing temperature = +25°C, full output load, natural air convection.
The output may be shorted to ground indefinitely with no damage. The
Output Short Circuit Current shown in the specifications is an average con-
sisting of very short bursts of full rated current to test whether the output
circuit can be repowered.
The On/Off pin allows the converter to be turned on or off by an external
device such as a switch, a transistor, a logic gate, or an optical isolator.
If the “logic pin” is left floating the measured voltage will be outside the
limit's in the data sheet. Those numbers define the levels needed for the
“control function” to take place and do not represent the voltage that may
be present on the logic pin.
Regulation specifications describe the deviation as the input line voltage
or output load current is varied from a nominal midpoint value to either
extreme (50% load).
Do not exceed maximum power ratings, sense limits or output overvoltage
when adjusting output trim values.
Output overload protection is non-latching. When the output overload
is removed, the output will automatically recover.
All models are fully operational and meet published specifications,
including “cold start” at –40°C.
11
The converter will shut off if the input falls below the undervoltage thresh-
old. It will not restart until the input exceeds the Input Start Up Voltage.
Output noise may be further reduced by installing an external filter. See
the Application Notes. Use only as much output filtering as needed
and no
more.
Larger caps (especially low-ESR ceramic types) may slow transient
response or degrade dynamic performance. Thoroughly test your applica-
tion with all components installed.
If reverse polarity is accidentally applied to the input, always connect an
external fast blow input fuse in series with the +V
IN
input.
Although extremely unlikely, failure of the internal components of this
product may expose external application circuits to dangerous voltages,
currents, temperatures or power levels. Please thoroughly verify all ap-
plications before committing them to service. Be sure to include appropri-
ately rated FUSES (see specifications and Application Notes) to reduce the
risk of failure.
Special care should be exercised so that Input Voltage Transient does not
exceed specified Max 100V/100ms. At normal input a large transient spike
can be generated as a result of distribution inductance and high inrush
current charging input cap on converter. This can be eliminated with 33μF
electrolytic capacitor mounted close to Converter input. The series resis-
tance (500mΩ < ESR < 700mΩ) is essential in this solution.
12
13
14
15
www.murata-ps.com/support
MDC_ULT Series.D01
Page 5 of 26
C++ Language Tutorial
The author of this book is the designer and original implementer of the C++ language. The purpose of writing this book is to help experienced programmers quickly understand the modern C++ language. Th...
arui1999 Download Centre
2009 "Weina Electronics" Cup Infrared Remote Control Alarm
Contestant: r051463438 Here are some pictures. This is the work I made this time. I mainly used the drawing function of 12864 LCD to make the clock interface and the inverse white processing in the me...
幸福的娃 MCU
Detailed parameters of high-power LED lamp beads and selection tips for point light sources
[hide]1. Brightness   The brightness of LED is different, and the price is different.   Lamp cup: Generally the brightness is 60-70 lm;   bulb lamp: Generally the brightness is 80-90 lm.   Note: 1W br...
探路者 LED Zone
A method for developing DSP hardware driver (transferred)
[color=Black]At present, TI's [u]DSP[/u] is widely used. As the functions of DSP become more and more powerful, the types and applications of on-chip peripherals are becoming more and more complex. Tr...
Jacktang Microcontroller MCU
A novel and practical method for equalizing charging of nickel-hydrogen battery packs
It is extremely complicated and even impossible to balance the current of hydrogen-nickel battery packs by voltage detection, and its reliability is also extremely complicated. However, hydrogen-nicke...
zbz0529 Power technology
Can you guys share what protection software you use?
I am currently using Kaspersky firewall and AVG anti-spyware, using Kaspersky anti-virus and AVG anti-trojan....
qufuybj Embedded System

EEWorld
subscription
account

EEWorld
service
account

Automotive
development
circle

Robot
development
community

Index Files: 1030  1382  1850  686  542  21  28  38  14  11
Datasheet   0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
Room 1530, 15th Floor, Building B, No. 18 Zhongguancun Street, Haidian District, Beijing Telephone: (010) 82350740 Postal Code: 100190
Copyright © 2005-2026 EEWORLD.com.cn, Inc. All rights reserved 京ICP证060456号 京ICP备10001474号-1 电信业务审批[2006]字第258号函 京公网安备 11010802033920号
