Catalog 1308242
Issued 3-03
P&B
KBP
series
10 Amp
Dual Coil
Latching Relay
File E29244
Users should thoroughly review the technical data before selecting a product
part number. It is recommended that users also seek out the pertinent approvals
files of the agencies/laboratories and review them to ensure the product meets
the requirements for a given application.
Features
• Dual coil latching relay accepts a momentary impulse to one coil to
latch and a second impulse to the other coil to release.
• Enclosed in a clear polycarbonate dust cover.
• AC or DC coils.
• Contacts up to 5PDT.
• Mounts in 11 or 20-pin octal-type plugs.
Coil Data
Nominal
Voltage
DC
Coils
(to 5 pole)
12
24
48
110
220
Resistance in
Ohms
±10% @ 25°C
52.0
230
850
4560
Nominal
Current
Milliamperes
230
104
56.5
24
Use 110 volt relay with 5000
Ohms, 5 watt resistor in series.
Resistance in
Ohms
±15% @ 25°C
Up to 4 Pole Relays
Nominal
Current
Milliamperes
Nominal
Voltage
Contact Data @ +25°C
Arrangements:
From 2 Form C (DPDT) to 5 Form C (5PDT),
(3PDT each coil).
Ratings:
10 amps @ 120VAC.
Materials: 10 amp models:
Silver-cadmium oxide.
Expected Life:
500,000 operations, mechanical; 50,000 operations
minimum at rated loads.
AC
Coils
24
120
240
24
120
42
1030
4100
For 5 Pole Relays
27
700
210
44
22
325
68
Operate Data @ +25°C
Must-Operate Voltage:
DC:
75% of nominal voltage.
AC:
85% of nominal voltage.
Operate Time:
25 milliseconds excluding bounce.
Initial Dielectric Strength
Between Open Contacts:
500V rms.
Between Adjacent Contacts:
1,000V rms.
Between Contacts and Coil:
1,000V rms.
Environmental Data
Temperature Range:
Storage:
105°C.
Operating:
-45°C to +85°C.
Coil Data @ +25°C
Nominal Power:
DC Coils:
2.7W.
AC Coils:
5.3VA to 4 pole; 7
.8VA to 5 pole.
Maximum Power:
DC coils - 4.0W.
Duty Cycle:
Intermittent.
Initial Insulation Resistance:
100 megohms.
Mechanical Data
Termination:
See terminals table on next page.
Enclosures:
Plastic dust cover standard. Hermetically sealed
metal case available on special order.
Weight:
10.8 oz. (306g) approximately.
Dimensions are shown for
910
reference purposes only.
Dimensions are in inches over
(millimeters) unless otherwise
specified.
Specifications and availability
subject to change.
www.tycoelectronics.com
Technical support:
Refer to inside back cover.
Catalog 1308242
Issued 3-03
P&B
Ordering Information
Typical Part Number
1. Type:
KBP = Enclosed, dual coil latching relay.
2. Contact Arrangement:
11 = 2 Form C (DPDT)
17 = 4 Form C (4PDT)
20 = 5 Form C (5PDT)
3. Coil Input:
A = AC
D = DC
4. Contact Rating:
G = 10 amps @ 120VAC, 80% PF
.
5. Coil Voltage:
12, 24, 48, 110VDC
24, 120, 240VAC
Specify the same latch and release coil voltage for standard KBP
relays. Unlike coils available on special order.
B
KBP
-11
A
G
-24
KB = Open, dual coil latching relay.
Our authorized distributors are more likely to maintain the following items in stock for immediate delivery.
KB-17AG-120
KB-17DG-12
KBP-11AG-120
KBP-11DG-24
KBP-11DG-110
KBP-20AG-120
Outline Dimensions
Dust Cover
27E928 Socket
KB-Open Style
1.781 MAX. TYP
.
(45.24)
2 HOLES
.157 DIA. REF
.
(3.99)
2.205 MAX.
(36.01)
.500
(12.7)
.005 (0.127)
.010 (0.254)
1.812
±
.015
(46.02
±
0.38)
1.375
(34.92)
.165
(4.19)
.156" DIA.
(4) MTG. HOLES
(2 HOLES EACH
FOR END OR
BOTTOM MOUNTING.)
.250
(6.35)
3.56 MAX.
(90.4)
1.187 REF TYP
.
.
(30.15)
1.496 REF
.
(38.00)
1.265
(32.13)
.875 REF TYP
.
.
(22.23)
.44
±
.03
(11.2
±
.8)
.56
±
.03
(14.2
±
.8)
.91 REF
.
(23.1)
1.25
±
.03
(31.8
±
.8)
2.406 MAX.
(61.11)
.031 REF
.
(0.79)
.25
(6.35)
3.22
(81.79)
1.609
(40.87)
Wiring Diagrams (Bottom Views)
1
91
1
91
7
1
5
1
7
8
5 6
4
1
1 11
0 24
2
20
1
9
1
6
1
8
1
5
1
7
4
3
2
5 6 7
7
8
5 6
4
1
1
3
1
6
1
8
1
3
8
9
10
1 11
0 24
2
20
1
9
3
3
1 1
1
Latch
Reset
Reset
Latch
Reset
Latch
KBP11
Note:
Shown with reset coil energized last.
KBP17
KBP20
Dimensions are shown for
reference purposes only.
Dimensions are in inches over
(millimeters) unless otherwise
specified.
Specifications and availability
subject to change.
www.tycoelectronics.com
Technical support:
Refer to inside back cover.
911
