SMC Plug Bulkhead Connector Solder Attachment
Solder Cup Terminal, .177 inch D Hole
TECHNICAL DATA SHEET
SMC Plug Bulkhead Connector Solder Attachment Solder Cup Terminal, .177 inch D Hole
Configuration
Connector
Connector Specification
Connector Interface Type
Cable Attachment Method (Shield/Contact)
Body Style
Mount Method
SMC Plug
MIL-STD-348A
Solder Cup
Solder
Straight
Bulkhead
PE4289
Electrical Specifications
Impedance, Ohms
50
Mechanical Specifications
Size
Length, in [mm]
Width/Dia., in [mm]
.
0.613 [15.57]
0.25 [6]
0.006 [2.72]
SMC Plug
Beryllium Copper, Gold
30µ in. minimum
Brass, Nickel
100µ in. minimum
1/4
3 [0.34]
Brass, Nickel
100µ in. minimum
Teflon
Weight, lbs [g]
Connector
Type
Contact Material and Plating
Contact Plating Specification
Coupling Nut Material and Plating
Coupling Nut Plating Specification
Hex Size, in.
Torque, in-lbs [Nm]
Body Material and Plating
Body Plating Specification
Dielectric Type
Compliance Certifications
(visit www.Pasternack.com for current document)
RoHS Compliant
Yes
Plotted and Other Data
Notes:
Values at 25 °C, sea level
URL:
http://www.pasternack.com/smc-plug-standard-solder-cup-terminal-connector-pe4289-p.aspx
SMC Plug Bulkhead Connector Solder Attachment Solder Cup Terminal, .177 inch D Hole from Pasternack Enterprises has
same day shipment for domestic and International orders. We maintain 99% availability of the industry’s broadest selection of
RF, microwave and fiber optic products.
PE4289 REV
1
