Power Splitter/Combiner
6 Way-0°
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
Coaxial
ZB6PD-17
50Ω
-55°C to 100°C
-55°C to 100°C
600 to 1700 MHz
Features
• wideband, 600 to 1700 MHz
• Low insertion loss, 0.35 dB typ.
• Good isolation, 25 dB typ.
• low insertion loss, 0.5 dB typ.
• Excellent output VSWR, 1.1:1 typ.
• rugged, shielded case
• up to 10W power input as splitter
CASE STYLE: UU586
Connectors Model
SMA
ZB6PD-17-S
Price
$139.95
Qty.
(1-9)
Maximum Ratings
10W max.
0.875W max.
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1,2,3,4,5,6
S
1,2,3,4,5,6
Applications
• VHF
• cellular
• PCN
• instrumentation
FREQ.
RANGE
(MHz)
f
L
-f
U
600-1700
Electrical Specifications
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 7.8 dB
PHASE
UNBALANCE
(Degrees)
AMPLITUDE
UNBALANCE
(dB)
S
Typ. Min.
25
18
Typ. Max.
0.35
0.9
Max.
7
Max.
0.5
Typ. Max.
1.22 1.6
Outline Drawing
VSWR
(:1)
OUT
Typ. Max.
1.15 1.35
Typical Performance Data
Frequency
(MHz)
S-1
600.00
650.00
700.00
750.00
800.00
900.00
1000.00
1100.00
1200.00
1300.00
1400.00
1500.00
1600.00
1650.00
1700.00
8.14
8.11
8.07
8.06
8.06
8.08
8.15
8.22
8.29
8.32
8.36
8.35
8.35
8.35
8.41
Total Loss
1
(dB)
S-2
8.20
8.17
8.14
8.14
8.12
8.14
8.15
8.20
8.25
8.28
8.29
8.27
8.23
8.22
8.26
Amplitude
Unbalance
(dB)
S-3
8.10
8.08
8.05
8.04
8.04
8.07
8.09
8.15
8.22
8.27
8.30
8.29
8.27
8.27
8.33
0.17
0.17
0.16
0.17
0.16
0.15
0.14
0.13
0.14
0.15
0.14
0.14
0.16
0.18
0.21
Isolation
(dB)
1-2
24.86
28.02
33.38
44.76
35.26
27.65
25.55
24.41
23.69
24.22
25.05
23.98
22.24
21.48
20.34
Phase
Unbal.
(deg.)
4-6
21.37
23.34
26.15
30.58
39.02
33.49
27.92
24.97
22.91
22.38
23.06
24.12
25.14
26.38
28.47
0.89
0.98
1.06
1.16
1.26
1.43
1.59
1.77
2.04
2.33
2.56
2.64
2.96
3.05
3.32
VSWR
S
VSWR
1
VSWR
3
1-3
21.42
23.40
26.20
30.67
39.39
32.72
27.64
24.85
22.89
22.40
23.06
24.06
24.92
26.02
27.87
1.40
1.33
1.24
1.17
1.14
1.15
1.13
1.19
1.28
1.28
1.23
1.21
1.14
1.06
1.10
1.03
1.04
1.06
1.08
1.09
1.11
1.12
1.13
1.11
1.07
1.04
1.04
1.11
1.15
1.20
1.03
1.03
1.04
1.06
1.08
1.10
1.11
1.12
1.11
1.09
1.06
1.04
1.08
1.11
1.16
Outline Dimensions (
inch
)
mm
A
3.50
88.90
G
.125
3.18
B
3.00
76.20
H
1.75
44.45
C
.63
16.00
J
.32
8.13
D
.130
3.30
K
.500
12.70
E
3.380
85.85
F
1.50
38.10
wt
grams
180
TOTAL LOSS (dB)
8.6
8.5
8.4
8.3
8.2
8.1
8.0
600
ZB6PD-17
TOTAL LOSS
S-1 (dB)
S-2 (dB)
1. Total Loss = Insertion Loss + 7.8dB splitter loss.
S-3 (dB)
45
ZB6PD-17
ISOLATION
1-2 (dB)
1-3 (dB)
4-6 (dB)
820
1040
1260
1480
1700
ISOLATION (dB)
40
35
30
25
20
600
820
FREQUENCY (MHz)
1040
1260
FREQUENCY (MHz)
1480
1700
ZB6PD-17
VSWR
1.5
#S VSWR
1.4
VSWR
1.3
1.2
1.1
1.0
600
#1 VSWR
#3 VSWR
electrical schematic
820
1040
1260
1480
1700
FREQUENCY (MHz)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. A
M127604
ZB6PD-17
HY/TD/CP
100615
