ZQL-1900MLNW+

Description
Narrow Band Medium Power Amplifier, 1850MHz Min, 1910MHz Max, ROHS COMPLIANT, CASE CW686
CategoryWireless rf/communication    Radio frequency and microwave
File Size280KB,2 Pages
ManufacturerMini-Circuits
Websitehttps://www.minicircuits.com
Environmental Compliance
Download Datasheet Parametric View All

ZQL-1900MLNW+ Overview

Narrow Band Medium Power Amplifier, 1850MHz Min, 1910MHz Max, ROHS COMPLIANT, CASE CW686

ZQL-1900MLNW+ Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerMini-Circuits
package instructionROHS COMPLIANT, CASE CW686
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresSMA
Characteristic impedance50 Ω
structureCOAXIAL
Gain15 dB
Maximum input power (CW)10 dBm
Maximum operating frequency1910 MHz
Minimum operating frequency1850 MHz
Maximum operating temperature70 °C
Minimum operating temperature-40 °C
RF/Microwave Device TypesNARROW BAND MEDIUM POWER
Maximum voltage standing wave ratio1.25
Coaxial
Low Noise Amplifier
50Ω 1800 to 2000 MHz
Features
• Very low noise figure, 1.6 dB max.
• High IP3, +41 dBm typ.
• Rugged, shielded case
ZQL-1900MLNW+
Applications
• PCS
• UMTS
• Mobile satellite service
Connectors
SMA
Case Style: CW686
Model
Price
ZQL-1900MLNW+ $249.00
ea.
+RoHS Compliant
Qty.
(1-9)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
Electrical Specifications
Parameter
Frequency Range
Noise Figure
Gain
Gain Flatness
Output Power at 1dB compression
Output third order intercept point
Input VSWR
Output VSWR
DC Supply Voltage
Supply Current
Open load is not recommended, potentially can cause damage.
With no load derate max input power by 20 dB
Condition (MHz)
1800-2000
1800-2000
1800-2000
1800-2000
1800-2000
1800-2000
1800-2000
1800-2000
1800-2000
Min.
1800
23
Typ.
+25
+41
1.4
1.25
15
Max.
2000
1.6
±2.0
310
Units
MHz
dB
dB
dB
dBm
dBm
:1
:1
V
mA
Outline Drawing
Maximum Ratings
Parameter
Operating Temperature
Storage Temperature
DC Voltage
Input RF Power (no damage)
Ratings
-40°C to 70°C
-55°C to 100°C
+17V
+3 dBm
Permanent damage may occur if any of these limits are exceeded.
Outline Dimensions (
inch
)
mm
A
B
C
1.77 2.42
.55
44.96 61.47 13.97
D
.13
3.30
E
F
G
.12 2.165 1.535
3.05 55.0 39.0
H
.126
3.20
J
.22
5.59
K
L
M
.28
.51
.61
7.11 12.95 15.49
N
.39
9.91
P
wt
0.22 grams
5.59
71.0
Notes
A.
Performance and quality attributes and conditions not expressly stated in this specification document are intended to be excluded and do not form a part of this specification document.
B.
Electrical specifications and performance data contained in this specification document are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
C.
The parts covered by this specification document are subject to Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled
to the rights and benefits contained therein. For a full statement of the Standard Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp
www.minicircuits.com
P.O. Box 35166, Brooklyn, NY 11235-0003 (718) 934-4500 sales@minicircuits.com
Mini-Circuits
®
REV. C
M121747
ZQL-1900MNW+
131008
Page 1 of 2
