Directional Coupler
ZADC-ED10208/1
Frequency
MHz
f
L
- f
U
Coupling
dB
Nom.
Flatness
Mainline Loss
dB
Directivity
dB
VSWR
Power
(:1)
INPUT, W
Typ.
1.30
L
MU
Max. Max
L
M
U
L
M
U
Typ. Max. Typ. Max. Typ. Max. Typ. Min. Typ. Min. Typ. Min.
0.80
20
400-2700 13.0±1.00
L=low range(f
L
to 10f
L
) M=mid range(10f
L
to f
U
/2) U=upper range(f
U
/2 to f
U
)
Notes:
•
For Surface Mount Environmental Specifications, please click
here.
Re-flow soldering information is available in
"Surface Mount"
article.
Case Style - X0
(inch,mm ) weight: 0 grams.
A B C D E F G H J
•
Non-catalog model. Please consult factory for price and delivery.
•
Case style outline drawing:
99-01-587
•
General Quality Control Procedures and Environmental Specifications are given in
Mini-Circuits Guarantees Quality.
Hi-Rel, MIL description are given in
Hi-Rel and MIL
K L M N P Q R S T
•
Prices and Specifications subjects to change without notice.
Tolerance: .x ± .1 .xx ± .03 .xxx ± .015 inch.
FREQ
(MHz)
400.00
440.00
480.00
520.00
560.00
600.00
640.00
680.00
720.00
760.00
800.00
850.00
900.00
960.00
1020.00
1080.00
1140.00
1200.00
1300.00
I. Loss (dB) Coupling (dB)
Directivity (dB)
In-Out
In-CPL
1.05
1.04
0.89
0.90
0.80
0.81
0.74
0.75
0.72
0.68
0.67
0.67
0.66
0.63
0.71
0.62
0.69
0.67
0.68
13.13
13.23
13.16
13.23
13.17
13.23
13.20
13.20
13.20
13.16
13.15
13.17
13.10
13.06
13.10
12.98
13.05
12.98
12.94
14.12
14.84
15.57
16.28
16.97
17.65
18.32
18.99
19.69
20.33
21.04
21.93
22.78
23.89
25.13
26.31
27.71
29.09
31.77
Return Loss (dB)
In
9.16
9.85
Out
8.70
9.39
CPL
9.17
9.80
10.52 10.04 10.38
11.15 10.64 10.92
11.73 11.23 11.41
12.31 11.80 11.87
12.85 12.33 12.29
13.34 12.85 12.67
13.87 13.40 13.05
14.40 13.91 13.40
14.90 14.42 13.71
15.51 15.13 14.11
16.23 15.88 14.54
16.99 16.66 14.99
18.16 17.72 15.56
19.08 18.58 16.05
20.33 19.67 16.65
21.62 20.73 17.20
23.32 22.33 18.12
1400.00
1500.00
1600.00
1700.00
1760.00
1820.00
1880.00
1940.00
2000.00
2100.00
2200.00
2300.00
2400.00
2500.00
2600.00
2700.00
0.70
0.72
0.75
0.74
0.80
0.79
0.84
0.83
0.83
0.88
0.95
1.03
1.04
1.05
1.04
1.06
12.93
12.94
12.98
12.99
12.97
13.02
13.00
13.06
13.10
13.16
13.19
13.21
13.31
13.48
13.70
13.82
34.42
33.94
30.70
27.22
25.29
23.58
22.05
20.65
19.33
17.36
15.52
13.89
12.35
10.95
9.63
8.42
24.75 23.72 19.11
26.21 24.07 20.42
28.58 23.78 22.23
30.69 23.10 24.00
30.48 22.59 24.58
31.06 21.97 24.60
30.55 21.38 24.16
31.95 20.90 23.52
32.99 20.50 22.76
36.24 19.74 21.26
39.09 19.62 19.36
42.94 19.70 17.39
38.75 19.88 15.74
33.13 19.81 14.51
25.95 19.91 13.49
22.14 19.70 12.50
