Coaxial
Power Splitter/Combiner
4 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
10W max.
0.375W max.
ZB4PD1-2000+
ZB4PD1-2000
50Ω
800 to 2000 MHz
Features
• wideband, 800 to 2000 MHz
• good isolation, 25 dB typ.
• excellent output VSWR, 1.1:1 typ.
• up to 10W power input as splitters
SMA version shown
CASE STYLE: UU188
Connectors Model
Price
BNC
ZB4PD1-2000(+)
$94.95
SMA
ZB4PD1-2000-S(+) $94.95
N-TYPE
ZB4PD1-2000-N+ $94.95
Qty.
(1-9)
(1-9)
(1-9)
Coaxial Connections
SUM PORT
PORT 1
PORT 2
PORT 3
PORT 4
S
1
2
3
4
Applications
• cellular
• satellite distribution
• GPS
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Electrical Specifications
FREQ.
RANGE
(MHz)
f
L
-f
U
800-2000
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 6.0 dB
AMPLITUDE
UNBALANCE
(dB)
S
Max.
0.3
Typ.
1.20
VSWR
(:1)
OUT
Max.
1.60
Typ.
1.15
Max.
1.55
Outline Drawing
Typ.
25
Min.
18
Typ.
0.6
Max.
1.2
Typical Performance Data
Freq.
(MHz)
S-1
796.00
868.50
955.50
1042.50
1129.50
1289.00
1376.00
1463.00
1550.00
1637.00
1724.00
1898.00
1970.50
1999.50
2057.50
6.43
6.45
6.53
6.55
6.56
6.56
6.57
6.57
6.60
6.63
6.64
6.72
6.76
6.73
6.85
Insertion Loss
(dB)
S-2
6.36
6.46
6.52
6.56
6.57
6.57
6.58
6.58
6.59
6.64
6.66
6.74
6.77
6.78
6.85
Amp.
Unbal.
(dB)
S-4
6.49
6.47
6.52
6.59
6.57
6.57
6.60
6.60
6.61
6.65
6.68
6.75
6.76
6.77
6.84
0.13
0.02
0.01
0.04
0.03
0.02
0.03
0.03
0.01
0.02
0.03
0.04
0.03
0.05
0.05
Isolation
(dB)
1-2
30.41
38.89
35.98
40.22
36.52
26.36
25.09
24.97
25.83
28.22
32.04
34.64
28.56
26.39
22.86
VSWR
S
3-4
31.33
40.48
34.14
36.51
46.39
29.03
27.07
26.60
27.21
29.53
32.99
38.14
31.50
28.54
24.27
1.16
1.15
1.31
1.37
1.32
1.16
1.11
1.10
1.15
1.19
1.17
1.02
1.08
1.12
1.25
VSWR
1
VSWR
2
VSWR
3
VSWR
4
S-3
6.39
6.48
6.53
6.58
6.60
6.58
6.59
6.58
6.60
6.64
6.65
6.71
6.74
6.75
6.80
2-3
37.43
37.81
33.94
31.76
31.12
32.78
35.33
40.07
45.06
41.29
37.29
34.51
35.21
36.03
37.33
1.16
1.16
1.19
1.22
1.21
1.11
1.04
1.02
1.08
1.12
1.14
1.13
1.13
1.13
1.15
1.15
1.15
1.18
1.21
1.21
1.13
1.07
1.01
1.05
1.09
1.13
1.15
1.17
1.18
1.19
1.15
1.14
1.17
1.20
1.20
1.12
1.07
1.01
1.03
1.07
1.10
1.13
1.16
1.17
1.18
1.13
1.13
1.16
1.18
1.18
1.11
1.07
1.03
1.04
1.05
1.05
1.05
1.06
1.07
1.10
Outline Dimensions (
inch
)
mm
INSERTION LOSS (dB)
ZB4PD1-2000
INSERTION LOSS
ZB4PD1-2000
ISOLATION
80
70
ISOLATION (dB)
60
50
40
30
20
10
0
800
1-2(dB)
2-3(dB)
3-4(dB)
A
3.50
88.90
G
.125
3.18
B
2.13
54.10
H
1.75
44.45
C
.88
22.35
J
.44
11.18
D
.150
3.81
K
.89
22.61
E
3.350
85.09
F
1.06
26.92
wt
grams
260
6.8
S-1(dB)
6.6
6.4
6.2
6.0
800
S-3(dB)
1000
1200
1400
1600
1800
2000
1000
1200
1400
1600
1800
2000
FREQUENCY (MHz)
FREQUENCY (MHz)
ZB4PD1-2000
VSWR
1.60
#S-VSWR
1.40
VSWR
#1-VSWR
#3-VSWR
electrical schematic
1.20
1.00
800
1000
1200
1400
1600
1800
2000
FREQUENCY (MHz)
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
EW
ALL N
minicircuits.com
REV. C
M112977
ZB4PD1-2000
HY/TD/CP/AM
070810
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
